iLive IMIC040 User Manual

Clip-On Microphone and Stand
User's Guide for Model IMIC040 v2618-01
Overview & Features
Microphone can be
adjusted 900
Using the Microphone
This microphone does not require any drivers, it is ready to
use when plugged in. You can use this microphone with any
recording or chat software. To use the microphone connect the
3.5mm audio plug into the 3.5mm audio input/microphone
port on your PC/laptop or any recording device. Note: Make
sure that the correct microphone is selected in your software's
settings.
3.5mm Audio Plug
Microphone Base
Microphone Settings (Windows OS)
When plugged in, the microphone should automatically be
ready to capture audio. Follow the steps below to view and edit
microphone settings Windows OS.
1. Connect the 3.5mm audio plug to the microphone input
of a powered on computer or laptop.
2. On your laptop or PC go to: Start > Settings > System >
Sound.
3. From this menu you can view microphone settings and
test the microphone.
4. Gently tap or speak into the microphone to test that the
microphone is capturing audio.
Microphone Settings (Mac OS)
When plugged in, the microphone should automatically be
ready to capture audio. Follow the steps below to view and
edit microphone settings Mac OS.
Windscreen
Detachable Lapel Clip.
You can use this unit as a lavalier microphone by using the
included lapel clip.
1. Connect the 3.5mm audio plug to the microphone
input of a powered on computer or laptop.
2. On your laptop or PC go to: System preferences >
Sound > Input >
3. From this menu you can view and test the microphone
status.
4. Gently tap the microphone to test that the microphone
is capturing audio.
1. Remove the base from the microphone.
2. Use the clip to fasten the microphone to your collar,
lapel, or tie, as seen in the figure below.
