MARGO SUPPLIES ZON MARK IV SCARE CANNON Instruction Manual

Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

MARGO SUPPLIES
ZON MARK IV SCARE CANNON
ZON MARK IV SCARE CANNON
# 1 0 0 0 - IN S T R U C T IO N M A N UA L
FOR PRODUCT
MANUALS AND VIDEOS,
SCAN THE QR CODE
SCAN ME
DISCLAIMER: THIS PRODUCT WAS DESIGNED AND INTENDED FOR THE SOLE PURPOSE OF WILDLIFE
CONTROL AND MANAGEMENT. THE PROPER AND SAFE USE OF THIS PRODUCT IS THE SOLE
RESPONSIBILITY OF THE OWNER AND/OR OPERATOR. THE SELLER ASSUMES NO RESPONSIBILITY
OR LIABILITY FOR THE IMPROPER AND/OR ILLEGAL USE, RESALE, ANY PHYSICAL INJURY AND/
OR PROPERTY DAMAGE RESULTING FROM DELIBERATE OR ACCIDENTAL DISCHARGE OF THE
PRODUCT, OR MODIFICATIONS MADE TO THE PRODUCT, SELF-SUPPLIED MATERIALS USED ALONG
WITH THE PRODUCT, CARELESS OPERATION OR MAINTENANCE NEGLECT OF THIS PRODUCT.
MARGOSUPPLIES.COM
1 - 8 8 8 -6 5 2 - 1 1 9 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZON MARK IV SCARE CANNON and is the answer not in the manual?

Questions and answers

Related Manuals for MARGO SUPPLIES ZON MARK IV SCARE CANNON

Summary of Contents for MARGO SUPPLIES ZON MARK IV SCARE CANNON

  • Page 1 MARGO SUPPLIES ZON MARK IV SCARE CANNON ZON MARK IV SCARE CANNON # 1 0 0 0 - IN S T R U C T IO N M A N UA L FOR PRODUCT MANUALS AND VIDEOS, SCAN THE QR CODE...

  • Page 2: Tips And Tricks

    CANNON FEATURES ► 120dB blasts scare birds and keep them away. ► One 20lb propane tank will provide approximately 17,000 detonations. ► Stable frame design prevents movement when detonating. ► Operates in strong winds. ► 40 second to 30 minute intervals. ►...

  • Page 3: Safety Information

    ► Never place objects or look directly into ► Replace the gas hose every 2 years. the megaphone. Contact Margo Supplies to order ► Never walk in front of or look into the replacement. barrel. INSTALLATION NOTE: The first few cycles may have low/no volume Attach Yellow Plastic Lid (#Z4-91606) to due to air being in the system.

  • Page 4: Maintenance

    MAINTENANCE IMPORTANT! CANNON SHOULD BE DISCONNECTED FROM GAS WHEN STORED. A full maintenance check should be performed at least once a year. When the cannon is not in use, it should be stored in a dry location - ideally free from rodents.

  • Page 5: Parts List

    PARTS LIST MECHANISM FRAME Z4-91206 Main Body Z4-91106 Outer Megaphone Z4-91216 Joint Pin Z4-91107 Single Megaphone Z4-91226 Diaphragm Gland Z4-91116 Clamping Bolt Z4-91236 Spring Holder Z4-91136 Rear Cover (Brass Electrodes) Z4-91246 Tripper Z4-91136S Rear Cover (Steel Electrodes) Z4-91256 Pull Spring Pin Z4-91146 Iris Cover Z4-91266...

  • Page 6: Troubleshooting

    24mm (15/16’’). Regulator is not tight enough. The cannon is leaking The cannon is leaking Contact Margo Supplies for relacement hose. The hose is damaged. The diaphragm leaks Contact dealer for repairs. along the plate rim. Ignition gives weak spark Check Electrode.
  • Page 7 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Clean the Gas Valve opening with a small piece of Gas Valve Holder wire/pipe/drill bit no more than 0.8mm. (#Z4-91416) is partially or completely blocked. Pull the Hinged Clip (#Z4-91266) vertically a few times. Gas Valve (#Z4-91406) won’t open.
