Summary of Contents for Retracta DR482G-05
- Page 1 Owners Manual Model Type Air/Water Hot/Cold Water/Coolant Horticultural Weed pesticide Oil / Grease Quality Hose Reels IMR3-issue 12 Instruction Manual Page 1...
- Page 2 INTRODUCTION Thank you for purchasing the Retracta R3 retractable hose reel. PLEASE READ THIS SAFETY INFORMATION CAREFULLY BEFORE USE. Read and retain this instruction manual to assist you in the operation of your new product. ‘CAUTIONS’ are listed throughout this manual to advise of actions that may cause damage to you’re...
-
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS 1) Use appropriate hardwear to secure and support the reel and bracket to desired location and weight of the fluids. (refer to back page for mounting bracket template) 2) To prevent the reel from pivoting in the overhead position (figure 2). - Page 4 REMOVE / REPLACE TENSION SIDE PLATE (ALL MODELS) Before attempting any maintenance disconnect and turn off supply line, then release the line pressure. 1) Remove screws with 2) Hold hub and remove screws 3) Release spring tension magnetic screwdriver 4) Remove screw and center hub 5) Remove screws.
- Page 5 HOSE REPLACEMENT INSTRUCTIONS (ALL MODELS EXCEPT GREASE) Before attempting any maintenance disconnect and turn off supply line, then release the line pressure. 1) Pull out hose and latch 2) Remove screws 3) Remove screws 4) Remove plate 6) Remove swivel 5) Remove cable tie 7) Remove old hose 8) Fit new hose...
- Page 6 HOSE REPLACEMENT INSTRUCTIONS (GREASE) Before attempting any maintenance disconnect and turn off supply line, then release the line pressure. 1) Pull out hose and latch 2) Remove screws 3) Remove sideplate 4) Remove screws 6) Remove cable tie 5) Remove swivel 7) Remove hose from swivel 8) Remove old hose 9) Fit new hose...
- Page 7 SWIVEL REPLACEMENT SWIVEL SEALS REPLACEMENT (AIR / AIR-WATER / COOLANT) (HORTICULTURAL / WEED PESTICIDE) Before attempting any maintenance disconnect and turn off supply line, then release the line pressure. 1) Pull out hose and latch 2) Remove screws 3) Remove screws 4) Remove plate 5) Remove cable tie 6) Remove circlip...
- Page 8 SWIVEL REPLACEMENT SWIVEL SEALS REPLACEMENT (OIL / HOT WATER) Before attempting any maintenance disconnect and turn off supply line, then release the line pressure. 1) Pull out hose and latch 2) Remove screws 3) Remove screws 4) Remove plate 5) Remove cable tie 6) Remove circlip Swivel O’ring Replacement instructions (use steps 1-7 &...
- Page 9 SWIVEL REPLACEMENT (GREASE) Before attempting any maintenance disconnect and turn off supply line then release line pressure. 2) Remove screws 1) Pull out hose and latch 3) Remove sideplate 4) Remove screws 5) Remove swivel 6) Remove cable tie 7) Remove SB6 swivel 8) Fit new SB6 swivel 13) Fit screws.
- Page 10 RACR ADJUSTMENT CONTROL INSTRUCTIONS (FOR MODELS FITTED WITH RACR) Adjustment Screw 2. Pull hose out and latch when adjustment 1. Lift centre button to unlock then lift out plug screw appears 3. Adjust speed as desired (Clockwise for slower return) 4.
-
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE Hose does nor retract correctly A) Outlet nozzle, gun or tool is too heavy Refer to INCREASE SPRING TENSION on page 3 B) Spring is fatigued and lost tension Reel does not latch A) Incorrect operation Refer to REMOVE/ REPLACE TENSION SIDE PLATE on page 4 B) Latch assembly is broken... -
Page 12: Exploded Diagram
EXPLODED DIAGRAM Note: Outer casing set is supplied with screws, mouth set and lower insert Standard bracket not shown Instruction Manual Page 12... - Page 13 SWIVEL ASSEMBLY PART NUMBERS Air / Air-Water / Coolant High Pressure Hot Water O’Ring seal kit BS115Vs AR / AW / Coolant Swivel Assembly Kit Hose Size BSP Swivel NPT Swivel HP Swivel Assembly kit 3/8" (10mm) RS116AS RS130AS RS85s 1/2"...
-
Page 14: Spare Parts List
SPARE PARTS LIST Generic Parts Item no Description Spare part no Tension hub set R3THs Latch set R3Ls Latching side plate R3LPs Inlet side plate R3IPs Drum assembly R3DAs Mouth set R3Ms Standard Bracket (incl locking plate) BU200 Outer Casing Set - (nominate colour) R3OC-* (replace* with colour) Lower insert (nominate colour) R3LIS-* (replace * with colour) - Page 15 DECLARATION OF CONFORMITY Instruction Manual Page 15...
- Page 16 DECLARATION OF CONFORMITY Instruction Manual Page 16...
- Page 17 DECLARATION OF CONFORMITY Instruction Manual Page 17...
- Page 18 DECLARATION OF CONFORMITY Instruction Manual Page 18...
-
Page 19: Mounting Details
MOUNTING DETAILS BU200 WALL MOUNT BRACKET DIMENSIONS NOTE: Not to scale WEIGHT: 11kg (24lb) - 15kg (33lb) MODEL DEPENDENT Instruction Manual Page 19... - Page 20 BB200 BENCH MOUNT BRACKET MOUNTING DETAILS FITTING LOCKING BRACKET Macnaught Americas (813) 628-5506 | info@macnaughtusa.com NOTE: Not to scale * Read Manual Before Use! Note: This product should be disposed of according to all applicable local and national government environment regulations and guidelines.
