Summary of Contents for PMM PMM0501
- Page 1 Business and Mission- Critical Solutions Provider X86 BASED EMBEDDED INDUSTRIAL COMPUTER Ethernet - Serial Media Converter anual Model: PMM0501 Document: User Manual Document version: Date: September 2023 www.Pmm-usa.us...
- Page 2 Intel & Atom are trademarks of Intel Corporation PMM is not liable for any consequence that results from violation IBM, PC/AT, PS/2&VGA are trademarks of International Business Machines of regulations pertaining to safe operations or safety codes Corporation Microsoft Windows is a trademark of Microsoft Corp.
-
Page 3: Table Of Contents
Connecting Power ............................7 Connecting a Serial Device ..........................7 Connecting to a Host or the Network ......................7 5. TARGET APPLICATIONS ............................. 7 6. PMM0501 Easy Config ............................8 log In................................8 Home Page ..............................9 Ethernet Configuration ..........................9 Serial Configuration ............................ -
Page 4: Introduction
1. INTRODUCTION This Document is a fully descriptive operational manual for PMM’s Ethernet - Serial Media Converter. Providing the operator with the needed information in terms of instruction and screen layout of the monitors, allowing for easy use. 1.1 Description... -
Page 5: Hardware
2. HARDWARE 2.1 Enclosure Dimensions 2.2 LED Indicators PMM0501 has 2x Green LED Indicators at the front view as following: LED INDICATOR Blinking: Data is being transmitted or received through the port Off: No Data is being transmitted or received through the port... -
Page 6: Technical Specifications
3. PIN Assignments 1. D- (RS485) 1. D+ (RS485) 2. D+ (RS485) 2. Earth 3. Earth 3. D- (RS485) 4. Earth 4. Earth 5. V DC+ (9-56) 6. V DC- (9-56) 7. Earth 8. Earth www.Pmm-usa.us Page 6 of 11... -
Page 7: Hardware Connection
4.1 Connecting Power PMM0501 has two power supply options 10-60V DC or 10-40 V AC, the user has to connect the positive power line (+) to pin no.5 in the top view and the negative line (-) to pin no.6 as illustrated in the pin’s assignments. -
Page 8: Pmm0501 Easy Config
Serial Redirector PMM0501 can be inserted to a serial system in which the slaves connected to one serial port and the masters to another serial port. PMM0501 allows Ethernet master devices to connect with serial slaves and simultaneously provides a serial redirector which allows the serial master to continue controlling the serial slaves. -
Page 9: Home Page
6.2 Home Page This page provides the user with the basic information about the PMM device “Ethernet -Serial Media Converter” such as Model Name, Serial Number, Firmware Version, Current IP Address and Number of Serial ports. 6.3 Ethernet Configuration Ethernet configuration parameters: ... -
Page 10: Serial Configuration
Parity: The parity bit is to determine if the data character being transmitted is correctly received by the remote device. Interface: Serial communication. Interface. Port ID (must be from 1-30). www.Pmm-usa.us Page 10 of 11... -
Page 11: Operation Mode
Click on “Reset MCU” to reset the device in order to operate according to the new updated settings correctly. Click on “Logout” to logout from PMM Easy Config. Note: The user can complete the settings configuration either through the web server as illustrated above or through PMM2003 Easy Config Tool. For more details please refer to PMM2003 Easy Config www.Pmm-usa.us...
