Summary of Contents for TWHEELS E-Bike City
- Page 1 E-Bike City User Manual...
-
Page 2: Table Of Contents
Table Of Contents I. Important Notes II. Product Overview III. Product Specifications IV. Adjustment Instructions V. Precaution of Riding VI. Safety Instructions... -
Page 3: Important Notes
I．Important Notes 1. The patterns and text descriptions of this manual are only used as instructions for operation and are not used as the basis for inspection of products. 2. The illustration in this manual may not match the actual product, and the actual sales style shall prevail. 3. -
Page 4: Product Overview
II．Product Overview 1. Saddle 6. Front Fork 2. Battery 7. Rear Wheel 3. Transfer Handle 8. Motor 4. Vehicle Code Engraving Position 9. Rear Light 5. Headlights... -
Page 5: Product Specifications
III. Product Specifications Product Description Bicycle type Electric Bicycle Color Cream & Grey Unit Dimension LxWxH 1950x 650x 1150mm Package Dimension LxWxH 1580x 240x 830mm Tires Size 700C*45C Max Speed 25km/h Max Load 120kg Mileage <100km Load Capacity 120kg Product Net Weight 21.5kg Product Gross Weight 30.6kg... -
Page 6: Adjustment Instructions
Fender Plastic Water-proof level IPX5 Alarm Device Mechanical Dell Throttle Type Twist Throttle Rear Rack & Front Basket Iron IV. Adjustment Instructions A. Adjustment of Front and Rear Brake System: Note: The adjustment method of the front and rear brakes is the same. 1. - Page 7 C. Disc Brake: There is enough clearance between the disc brake and the brake pad (there is no interference between the brake disc and the brake skin when rotating, and the best braking effect is appropriate). Key points of disc brake adjustment: •...
- Page 8 G. Battery Installation: The battery is mainly composed of two pieces, cell and protection board PCM (power battery is generally called a battery management system BMS). The cell is equivalent to the heart of the battery, and the management system is equivalent to the brain of the battery. The cell is mainly composed of positive electrode material, negative electrode material, electrolyte, diaphragm and Shell, while the protection board is mainly composed of a protection chip (or management chip), MOS tube, resistor, capacitor, PCB board, etc.
-
Page 9: Precaution Of Riding
V. Precaution of Riding 1. Inspection of the Power Supply Circuit and Lighting Circuit: • Check whether the power supply circuit, lighting circuit and device are damaged; Turn on the power supply, operate the lighting switch, and check whether the headlights and taillights are on and whether the brightness of the headlights and taillights is normal. •... -
Page 10: Safety Instructions
VI. Safety Instructions For your keen safety, please read and follow the following instructions: User Safety: 1. When using electric bicycles, you should abide by traffic regulations and pay attention to driving safety. 2. It is forbidden for people under 16 years old to drive electric bicycles on the road. 3. - Page 11 Safe Use Method of Charger: 1. It is forbidden to place any items on the charger. 2. It is forbidden to put any liquid or metal into the charger. 3. It is strictly prohibited to disassemble and modify the charger. 4.
