TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
01
050127
ED
DATE
CHANGE NOTE
ED
01
1626 LM REL.2.0 TECHNICAL HANDBOOK
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
R.BRASSAC A.ZERMANI
APPRAISAL AUTHORITY
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
P.OTTOLENGHI
1626LM Rel.2.0
Technical Handbook
3AL 94936 AA AA
C.GIANNI
ORIGINATOR
258
5
9
11
11
11
12
15
16
16
16
17
17
18
19
19
21
21
22
23
24
26
26
27
28
29
29
29
30
30
31
32
258
1
/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1626 LM REL.2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Alcatel 1626 LM REL.2.0

Summary of Contents for Alcatel 1626 LM REL.2.0

  • Page 1: Table Of Contents

    1626 LM REL.2.0 TECHNICAL HANDBOOK TABLE OF CONTENTS LIST OF FIGURES AND TABLES ............
  • Page 2 ............6 GENERAL ON ALCATEL CUSTOMER DOCUMENTATION .
  • Page 3 3.1.3 Optical Fiber Amplification sub–system ........3.1.4 Optical supervisory channel (OSC) sub–system .
  • Page 4 6.3 Maintenance aspects ............6.4 Instruments And Accessories .

  • Page 5: List Of Figures And Tables

    LIST OF FIGURES AND TABLES FIGURES Figure 1. Subrack label ..............Figure 2.
  • Page 6 Figure 47. Example of Master shelf in OADM Repeater configuration (upgrade to +23 dBm is possible) ................Figure 48.
  • Page 7 ........Table 2. Handbooks related to the specific product SW management and local product control Table 3. Handbooks common to Alcatel Network Elements using 1320CT platform ... . .
  • Page 8 3AL 94936 AA AA...

  • Page 9: Handbook Guide

    HANDBOOK GUIDE 3AL 94936 AA AA...
  • Page 10 3AL 94936 AA AA...

  • Page 11: Handbook Structure And Configuration Check

    1 HANDBOOK STRUCTURE AND CONFIGURATION CHECK 1.1 General information ALCATEL makes no warranty of any kind with regards to this manual, and specifically disclaims the implied warranties of merchantability and fitness for a particular purpose. ALCATEL will not be liable for errors contained herein or for damages, whether direct, indirect, consequential, incidental, or special, in connection with the furnishing, performance, or use of this material.

  • Page 12: Product-Release Handbooks

    The list of handbooks given here below is valid on the issue date of this Handbook and can be changed without any obligation for ALCATEL to update it in this Handbook. Some of the handbooks listed here below may not be available on the issue date of this Handbook.

  • Page 13: Table 3. Handbooks Common To Alcatel Network Elements Using 1320Ct Platform

    Table 3. Handbooks common to Alcatel Network Elements using 1320CT platform N.B. 1320CT and Q3CT–P are equivalent terms FACTORY THIS HANDBOOK ANV Part No. Part No. HDBK 1320CT 3.X 3AL 79551 AAAA 957.140.042 N Basic Operator’s Handbook Provides general information and operational procedures common to all 1320CT (Craft terminal) of Alcatel Info–Model Network Elements.

  • Page 14: Table 4. Documentation On Cd-Rom

    Table 4. Documentation on CD–ROM See para.6.5 on page 51 CD–ROM TITLE ANV Part No. FACTORY Part No. 1626 LM Rel. 2.0 CD–ROM–DOC EN 3AL 94937 AAAA –––––––– Contains, in electronic format, the following handbooks: REF. [1] to [4] Also contains the product–release Help–On–Line which provides information regarding Craft Terminal screens and operational procedures, this documentation is provided in HTML fromat.

  • Page 15: Handbook Structure

    1.4 Handbook Structure This handbook has been edited according to the Alcatel standardized “drawing–up guides” complying with such suggestion. This handbook is divided into the following main topics as described in the table of contents: HANDBOOK GUIDE: It contains general information on safety norms, EMC and type of labels that might be affixed to the equipment.

  • Page 16: Handbook Configuration Check

    1.5 Handbook configuration check 1.5.1 List of the editions and modified parts The following table indicates the handbook parts new and modified with respect to the previous edition. Legenda = new part =proposal part = modified part PR =proposal edition Table 6.

  • Page 17: Compliance With European Norms

    2 COMPLIANCE WITH EUROPEAN NORMS. 2.1 Electromagnetic Compatibility (EMC) The CE markings printed on the product denote compliancy with the following Directives: • 89/336/EEC of May 3rd, 1989 (EMC Directives), amended – by the 92/31/EEC Directive issued on April 28th, 1992 –...

  • Page 18: Safety

    2.2 Safety Compliancy to Safety Norms is declared in that the equipment satisfies standardized Norms : • IEC 60950–1 ed. 2001 , for electrical safety • EN 60950–1 ed. 2001 , for electrical safety • EN 60825–1 ed. 1994 + A11 ed. 1996 + A2 ed. 2001 for optical safety •...

  • Page 19: Safety Norms And Labels

    3 SAFETY NORMS AND LABELS 3.1 First aid for electric shock Do not touch the patient with bare hands until the circuit has been opened. Open the circuit by switching off the line switches. If that is not possible, protect yourself with dry material and free the patient from the conductor.
  • Page 20 Mouth to mouth resuscitation method Lay the patient supine with his arms parallel with the body, if the patient is laying on an inclined plane, make sure that his stomach is slightly lower than his chest. Open the patient’s mouth and check that there are no extraneous bodies in his mouth (dentures, chewing–gum etc.), Kneel beside the patient level with his head.

  • Page 21: Safety Rules

    3.2 Safety Rules 3.2.1 General Rules • Before carrying out any installation, turn–on, tests & operation and maintenance operations carefully read the relevant Handbooks and chapters. • Observe safety rules – When equipment is operating nobody is allowed to have access inside on the equipment parts which are protected with Cover Plate Shields removable with tools –...

  • Page 22: Labels Indicating Danger, Forbiddance, Command

    3.2.2 Labels Indicating Danger, Forbiddance, Command It is of utmost importance to follow the instructions printed on the labels affixed to the units and assemblies. The labels are fully compliant with International Norms ISO 3846–1984. The symbols or statements are enclosed in geometric shapes: ISO 3864–1984.

  • Page 23: Dangerous Electrical Voltages

    The symbols presented in para.3.2.3 through 3.2.7 are all the possible symbols that could be present on Alcatel equipment, but are not all necessarily present on the equipment this handbook refers to. 3.2.3 Dangerous Electrical Voltages 3.2.3.1 Labelling The following warning label is affixed next to dangerous voltages (>42.4 Vp; >60 Vdc).

  • Page 24: Harmful Optical Signals

    3.2.4 Harmful Optical Signals 3.2.4.1 Labelling If the assembly or unit is fitted with a LASER, the labels must comply with the IEC 60825–1 and –2 International Norms. The symbol indicates the presence of a LASER beam. Danger level is stated within a rectangular label: If the LASER is a Hazard Level 1 or 1M product, the label depicting the symbol within a triangle is not compulsory.
  • Page 25 3.2.4.2 Optical safety: general rules On handling optical equipments or units or cables always check that laser labels are properly affixed and that the system complies with applicable optical standards. DANGER! Possibility of eyes damage: invisible infrared radiations emitted by the fiber optic transmitters can cause eyes damages.

  • Page 26: Risks Of Explosions

    3.2.5 Risks of Explosions 3.2.5.1 Labelling and safety instructions This risk is present when batteries are used, and it is signalled by the following label: Therefore, slits or apertures are made to let air circulate freely and allow dangerous gasses to down flow (battery–emitted hydrogen).

  • Page 27: Heat-Radiating Mechanical Parts

    3.2.7 Heat–radiating Mechanical Parts 3.2.7.1 Labelling and safety instructions The presence of heat–radiating mechanical parts is indicated by the following warning label in compliancy with IEC 417 Norm, Fig.5041: As stated by IEC 60950 Norm., para.1.4.7 the touchable mechanical parts carrying the above depicted warning label, are those whose temperature exceeds the limits established by the following formula °...

  • Page 28: Specific Safety Rules In This Handbook

    3.2.8 Specific safety rules in this handbook Specific safety rules are specified in the following paragraphs: – para. 6.1.1 on page 245 – para. 6.5.1.1 on page 247 – para. 6.5.2.1 on page 248 – para. 6.6.1 on page 249 3AL 94936 AA AA...

  • Page 29: Other Norms And Labels

    4 OTHER NORMS AND LABELS 4.1 Electromagnetic Compatibility The equipment’s EMC norms depend on the type of installation being carried out (cable termination, grounding etc.,) and on the operating conditions (equipment, setting options of the electrical/electronic units, presence of dummy covers, etc.). •...

  • Page 30: General Norms - Turn-On, Tests & Operation

    4.1.2 General Norms – Turn–on, Tests & Operation • Preset the electrical units as required to guarantee EMC compatibility • Check that the equipment is operating with all the shields properly positioned (dummy covers, ESD connector protections, etc.) • To properly use EMC compatible equipment observe the information given 4.1.3 General Norms –...

  • Page 31: Electrostatic Dischargers (Esd)

    4.2 Electrostatic Dischargers (ESD) In case of subracks provided with a front cover, follow the precautionary measures below stated, before removing the cover. Before removing the ESD protections from the monitors, connectors etc., observe the precautionary measures stated. Make sure that the ESD protections have been replaced and after having terminated the maintenance and monitoring operations.

  • Page 32: Suggestions, Notes And Cautions

    4.3 Suggestions, notes and cautions Suggestions and special notes are marked by the following symbol: Suggestion or note..Cautions to avoid possible equipment damage are marked by the following symbol: TITLE... (caution to avoid equipment damage) statement..4.4 Labels affixed to the Equipment This paragraph indicates the positions and the information contained on the identification and serial labels affixed to the equipment.

  • Page 33: Figure 1. Subrack Label

    NOTE : The above reference numbers are detailed on Table 8. on page 32 Figure 1. Subrack label 3AL 94936 AA AA...

  • Page 34: Figure 2. Subrack Label

    NOTE : The above reference numbers are detailed on Table 8. on page 32 Figure 2. Subrack label 3AL 94936 AA AA...

  • Page 35: Figure 3. Subrack Label

    NB.1 NB.1 = The label is present on the support side NOTE : The above reference numbers are detailed on Table 8. on page 32 Figure 3. Subrack label 3AL 94936 AA AA...

  • Page 36: Figure 4. Labels On Units With Standard Cover Plate

    NOTE : The above reference numbers are detailed on Table 8. on page 32 Figure 4. Labels on units with standard cover plate 3AL 94936 AA AA...

  • Page 37: Figure 5. Modules Label

    NOTE : The above reference numbers are detailed on Table 8. on page 32 Figure 5. Modules label 3AL 94936 AA AA...

  • Page 38: Figure 6. Internal Label For Printed Board Assembly

    NB.1 NB.1 = The label is present on the p.c.s. component side NOTE : The above reference numbers are detailed on Table 8. on page 32 Figure 6. Internal label for Printed Board Assembly 3AL 94936 AA AA...

  • Page 39: Figure 7. Back Panels Internal Label

    NB.1 NB. 1 = The label is present on p.c.s. components side or rear side on the empty spaces. NOTE : The above reference numbers are detailed on Table 8. on page 32 Figure 7. Back panels internal label 3AL 94936 AA AA...

  • Page 40: Figure 8. Label Specifying Item Not On Catalogue (P/N. And Serial Number)

    (format 128; Module = 0,166; EN 799; Subset B/C) Figure 8. Label specifying item not on catalogue (P/N. and serial number) ANV ITEM PART NUMBER + space + ICS ALCATEL FACTORY PART NUMBER + SPACE + CS ANV ITEM PART NUMBER + ICS BAR CODE (format ALFA 39 (+ * start, stop);...

  • Page 41: Figure 10. Item Identification Labels - Item On Catalog

    FREQUENCY ACRONYM (Optional) ANV ITEM PART NUMBER Figure 10. Item identification labels – item on catalog EQUIPMENT NAME Figure 11. Label identifying the equipment (example) 3AL 94936 AA AA...
  • Page 42 3AL 94936 AA AA...

  • Page 43: List Of Abbreviations

    Add and Drop Multiplex Authority and Format Identifier Alarm Indication Signal Automatic Laser Shutdown proprietary Alcatel Maintenance Signal; there are two types of AMS: AMSs (for legacy submarine equipment) and AMSt (for legacy terrestrial equipment) Automatic Protection switching APSD Automatic Power ShutDown...
  • Page 44 Dispersion Compensating Unit Download DMUX Demultiplexing DTMF Dual Tone Modulation FrequencyDTV (Decision Threshold voltage) Decision Threshold voltage Digital Video DWDM Dense Wavelength Division Multiplex Equipment Controller ECID Enhanced Card IDentifier Equipment Craft Terminal Embedded Channel Communication ECID Extended Card IDentity EDFA Erbium Doped Fiber Amplifier EEPROM...
  • Page 45 HDLC High Level Data Link Control House Keeping HardWare HardWare Failure International Electrotechnical Commission Interface Integrated Laser Modulator ILOS Input Loss Of Signal INDeterminate Input/Output Internet Protocol IS–IS Intermediate System–to–Intermediate System International Standard Organization ISPB Intra Shelf Parallel Bus ISSB Intra Shelf Serial Bus ITU_T International Telecommunication Union –Telecommunication...
  • Page 46 Network Element Negative Dispersion Chromatic Network Element Synthesis Network Management Layer Network Management System Node Network Interface NSAP Network Service Access Point Network Time Protocol NURG Not URGent Optical Amplifier Card OADM Optical Add and Drop Multiplexer On Board Controller Optical Channel OverHead OCHA...
  • Page 47 Remote Inventory Relative Intensity Noise Receiver Parameter Optimisation Regenerator Section RS–AIS prorietary Alcatel Maintenance Signal, defined as a SDH RS frame, with all ones except Frame Alignment Word and B1 parity RSOH Regenerator Section Overhead SAPI Source Adress Point Identifier...
  • Page 48 Single Mode Fiber SNCP Sub–Network Connection Protection Serial Peripheral Interface Server Signal Failure SoftWare SWDL SoftWare DownLoad SoftWare Product Threshold Crossed Alarm Transmission Control Protocol TCP/IP Transmission Control Protocol/Internet Protocol Time Division Multiplexing Trace Identifier Mismatch TimActDis TIM consequent actions disabled Telecommunication Management Network Termination Point Top Rack Unit...

  • Page 49: General On Alcatel Customer Documentation

    6 GENERAL ON ALCATEL CUSTOMER DOCUMENTATION 6.1 Products, product-releases, versions and Customer Documentation A ”product” is defined by the network hierarchical level where it can be inserted and by the whole of performance and services for which it is meant.

  • Page 50: Handbook Updating

    6.4 Handbook Updating The handbooks associated to the ”product–release” are listed in para. 1.3 on page 12. Each handbook is identified by: – the name of the ”product-release” (and ”version” when the handbook is applicable to the versions starting from it, but not to the previous ones), –...

  • Page 51: Customer Documentation Supplied On Cd-Rom

    CD–ROMs for Network Management products do not contain: • the Installation Guides • the documentation of system optional features that Customers could not buy from Alcatel together with the main applicative SW. – CD–ROMs for Network Elements products do not contain: •...

  • Page 52: Use Of The Cd-Rom

    Whenever a new edition of any of such handbooks/documents is released, a check is made in the Alcatel–Information–System to identify the list of CD–ROMs that must be updated to include the new editions of these handbooks/documents. This causes the planning and creation of a new edition of the CD–ROM.

  • Page 53: Descriptions
