- Page 1 QUICK START GUIDE U-11 / U-15 / U-22 MODEL CLOUD INTELLIGENT UNINTERRUPTIBLE POWER SUPPLY (UPS) WITH POWER CONDITIONER poewit.com...
-
Page 2: Package Contents
Quick start QUANTITY 2) PRODUCT DESCRIPTION PoEWit UPS, lets users define which devices have priority for consuming battery power. In addition, PoEWit’s UPS battery backup solutions feature state of the art noise filtering and automatic voltage regulators to deliver clean power to audio and video gear. -
Page 3: Installation And Setup
NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2-1. Rear Panel View U-11/U-15 U-22 Fig 1 1. Programmable outlets 2. Non-programmable outlets 3. - Page 4 DISPLAY LOAD LEVEL & LINE MODE OR BATTERY MODE Fig 2 2-3. Install The UPS For safety consideration, the UPS is shipped out from factory without connecting battery wires. Before installing the UPS, please follow below steps to re-connect battery wires first. poewit.com...
- Page 5 Fig 3 • Rack-mount Installation CAUTION – Do NOT use the mounting brackets to lift the unit. The mounting brackets are only for securing the unit to the rack. • Install UPS alone Fig 4 poewit.com...
- Page 6 INSTALLATION AND SETUP • Install UPS and external battery Fig 5 • Tower Installation Install UPS alone Step 1 Step 2 Step 3 Footstand Screw M4x8 Fig 6 poewit.com...
- Page 7 Install UPS and external battery Foot Extend Fig 7 NOTE: When installing the UPS or battery pack with feet, please keep 70mm distance from the edge of the unit. Fig 8 70mm (2 .75 in)7 0mm (2 .75 in) poewit.com...
- Page 8 There are two kinds of outputs: programmable outlets and general outlets. Please connect devices power control the programmable outlets and non-power control devices to the general outlets. Step 3: Communication connection Intelligent slot Fig 9 Connect your broadband connection to the RJ45 port for cloud connectivity. poewit.com...
- Page 9 1 and pin 2) for UPS normal operation. To activate EPO function, remove two screws on EPO port and green connector will be removed. NOTE: The EPO function logic can be set up via LCD setting. Please refer to program 7 in UPS settings for details. poewit.com...
- Page 10 Connect one end of external battery cable to the UPS unit and the other end to the battery box. See the chart below for detailed connection. CAUTION: Connection to external battery pack shall be installed by SERVICE PERSONNEL only. Batter y Pack #1 Batter y Pack #2 Fig 12 poewit.com...
- Page 11 NOTE 1: After installation and initial start-up, set the numbers of the installed battery pack first. Please refer to the details in the “UPS Settings” section. NOTE 2: When 2 or more external battery packs are used, the UPS output rating is derated 20%. poewit.com...
- Page 12 After powering up the UPS, you should be automatically connected to the internet. You are now ready to download and install our App. You can search Poewit in Apple App Store or Google Play to get the App. Note: Your device and mobile phone both must have an internet connection through the same external IP address and must be on the same local subnet.
