- Page 1 NAE22700 USER MANUAL CAUTION ELECTRICALLY OPERATED PRODUCT Not for children under 16 years of age. As with all electrical products, precautions should be observed during handling to reduce the risk of electric shock.
- Page 2 CONTENTS FCC Statement ( F o r U S A R e g u l a t i o n O n l y ) INTRODUCTION This device complies with Part 15 of the FCC Rules. WARNING Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and PARTS DIAGRAM (2) This device must accept any interference received,...
- Page 3 INTRODUCTION The single thruster NAUTICA Q-CLASS is a full-featured Seascooter that gets you cruising underwater with a top speed of up to 5.3mph (8.5km/h). Easily shift between 3 rotational speeds as you conserve your energy for more bottom time. Use appropriate equipment such as wetsuit, approved life jacket, mask &...
- Page 4 WARNING • A child under 16 years old should never operate this product. • Crushing / Cutting Hazard • The Seascooter is designed for 1 person use. • This is not a life saving device. • Do not attach your body, clothing, other equipment to the DO NOT use it as a buoyancy aid.
- Page 5 The instructions concerning persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge and children playing with the appliance are not applicable. The connector must be removed before the appliance is cleaned and that the appliance inlet must be dried before the appliance is used again. CRUSHING HAZARD: The following action during assembly, disassembly, and transportation of the Seascooter may incur crushing hazards to your fingers or toes: •...
- Page 6 PARTS DIAGRAM Front Grille Foldable Control Handles Release Buttons Camera Mount (Camera not included) Carry Handle Speed Control Battery Start Buttons 10. Battery Charging Base Control Handles (Foldable) 11. Charger Battery Indicator...
- Page 7 BATTERY CAUTION WARNING WARNING Replace the battery immediately if it is damaged. • Use the specified charger only. BATTERY SAFETY • Must be disposed of properly. RE-CHARGE THE BATTERY EVERY • Always store the battery in well ventilated areas where it is out of the reach of children and away AT LEAST from heat and ignition sources.
- Page 8 BATTERY INSTRUCTION CHARGING INSTRUCTION: 1. Always ensure the control handles are folded away before removing the battery (see Fig. 1) 2. ALWAYS ensure that the Seascooter is out of the water, dry and placed in a dry area. 3. Pull the two latches down and remove the battery (see Fig. 2) 4.
- Page 9 GETTING STARTED CAUTION • Never use this seascooter in sandy water condition. Sands will cause damages to the motors and shorten the lifespan of the unit. IMPORTANT INFORMATION: Sand or Grit on Seals Ensure sand/grit does not get on the seals as correct maintenance and care are essential. To remove sand or grit, rinse the seals in fresh water and apply fresh lubricant.
- Page 10 BUILT-IN CARRY HANDLE The Q-CLASS foldable control handles can be folded away to achieve a highly compact storage and travelling size. When not in use and with its control handles folded away the unit features a retractable rubber carry handle that can be easily pulled and pressed back into seascooter body to allow for easy transport and handling.
- Page 11 • Method B: Switch the Seascooter on for approx. 1 minute in fresh water to flush the Seascooter and propeller components clear of any debris Visit our YouTube channels “NAUTICA Seascooters” for video instruction. To clean the Seascooter do not use detergents; only use a damp cloth to wipe the unit clean.
- Page 12 CAMERA ASSEMBLY ATTACHING YOUR CAMERA TO SEASCOOTER MOUNTS (Can be used with GoPro HERO [3, 3+, 4, 5, 6 or 7] cameras, ® or other camera with using the same mount system) Slide your camera to the flat buckle mount as show in below diagram.
- Page 13 TECHNICAL SPECIFICATIONS WEIGHT 8.6 LB / 3.9 KG DEPTH 100 FT / 30 M RUN TIME 65 MINUTES (NORMAL USE) SPEED UP TO 5.3 MPH / 8.5 KM/H GEAR 3 SPEEDS RECHARGE 3 HOURS BATTERY 14.4V / 10 AH SIZED FOR CARRY-ON TRAVEL Unit Dimensions 8.7”...
- Page 14 All corresponding speci cation appear in this manual are correct at the time of printing. For the latest updates and further information on the complete range of the Seascooter™, PLEASE VISIT www.Nauticaseascooters.com This Product is not manufactured by Nautica. For consumer purposes, please contact Sport Dimension Inc. at 1-800-678-7873. (US & CANADA MARKET ONLY) Please visit our website at www.Nauticaseascooters.com to find out your local distributor.
- Page 15 LIMITED WARRANTY for Seascooters with camera mount: • ALWAYS inspect to ensure the product works properly every time before use. Warranty of this product does not cover any damages due to misuse. • Failure to follow the user(s) instructions on packaging and/or user(s) manual may result in damages or loss of your cameras including but not limited to any user’s personal items, all of which are not covered under warranty of this product.
- Page 16 Canada, please contact your Local Distributor for warranty arrangements in your territory. Please visit www.seascooter.net for Distributor / Service Center details. Distributors ONLY warrant NAUTICA Seascooter products purchased from an authorized dealer and with an original purchase receipt. All warranties are limited to a single original owner on the purchase of new and current product from an authorized reseller.
