GALAXY
PRO
630w
User
manual
Manual de usuario

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GALAXY PRO LED 1800E 630W and is the answer not in the manual?

Questions and answers

Related Manuals for Solux GALAXY PRO LED 1800E 630W

Summary of Contents for Solux GALAXY PRO LED 1800E 630W

  • Page 1 GALAXY 630w User manual Manual de usuario...

  • Page 2: Technical Specifications

    PLEASE READ THESE INSTRUCTIONS FIRST BEFORE INSTALLATION Thank you for purchasing the Pro 630W LED ML. This manual describes the mounting and installing of the product and also describes how to use the product. Mounting and installing of the LED fixture may only be executed by certified service personnel. Please read and understand this manual completely before using the product.

  • Page 3: Product Description

    PRODUCT DESCRIPTION The Pro 630W LED ML is an electronic horticultural LED fixture. It drives six LED rails. The Pro 630W LED ML is intended to be used in greenhouses or in climate rooms. In this manual, the Pro 630W LED ML will be referred to as: “the LED fixture”.
  • Page 4 MOUNTING WITH SOLID DECKING MOUNTS Suggested application: ideal for hanging on cross bars in a rack system with solid decking. Hardware included: Solid decking mounts. For proper uniformity and flexibility for adjustments, position the LED fixture with light bars parallel to the length of the rack. Put 4 the 1# hooks on the installation site (between the beams of the shelf) Adjust the position of 4 hooks Must 2 people jointly lift the LED fixture, the second and the fifth light bars are...
  • Page 5 MOUNTING WITH LANCE HANGERS AND ADJUSTABLE KIT Suggested application: Ideal for two-point hanging from areas with high clearance, such as ceilings or other support structures. Put 4 the 2# rings into 4 round holes in the lamp stand. Hang 2 the 3# ropes into the rings. MUST 2 or more people jointly pull up the rope and lift the LED fixture.
  • Page 6 MOUNTING THE POWER SUPPLY ENCLOSURE Hang 2 the 4# ropes into the holes on both sides of the power supply. Fix the rope to the location where it needs to be installed. The input power cord of the LED fixture connects the power supply, which can be used.

  • Page 7: Especificaciones Técnicas

    LEA LAS INSTRUCCIONES ANTES DE LA INSTALACIÓN Muchas gracias por comprar Pro 630W LED ML. Este manual describe el montaje, la instalación y el uso del producto. El montaje y la instalación del dispositivo de luces LED deberán llevarlos a cabo únicamente personal de servicio certificado.

  • Page 8: Descripción Del Producto

    DESCRIPCIÓN DEL PRODUCTO El Pro 630W LED ML es un dispositivo de lu- ces LED electrónico para horticultura. Cuen- ta con seis rieles de luces LED. El Pro 630W LED ML está diseñado para su uso en inver- naderos o en salas climatizadas. En el pre- sente manual, nos referiremos al Pro 630W LED ML como: «el dispositivo de luces LED».
  • Page 9 MONTAJE CON SOPORTES SÓLIDOS Aplicación sugerida: ideal para colgar en barras transversales en un sistema de bastidor con soporte sólido. Material incluido: soportes sólidos. Para conseguir una uniformidad y flexibilidad adecuadas para los ajustes, coloque el dispositivo de luces LED con las barras de luz paralelas a la longitud del bastidor.
  • Page 10 MONTAJE CON COLGADORES DE LANZA Y KIT AJUSTABLE Aplicación sugerida: Ideal para colgadores de dos puntas en áreas de gran claridad, como techos u otras estructuras de soporte. Coloque cuatro anillas del tipo 2 en los cuatro agujeros del soporte de la lámpara. Cuelgue dos cables de tipo 3 de las anillas.
  • Page 11 MONTAJE DE LA CAJA DE LA FUENTE DE ALIMENTACIÓN Cuelgue dos cables del tipo 4 en los agujeros a ambos lados de la fuente de alimentación. Fije el cable al lugar donde debe instalarse. Conecte el cable de alimentación de entrada del dispositivo de luces LED a la fuente de alimentación que vaya a usar.be used.

  • Page 12: Maintenance

    MAINTENANCE There are no serviceable parts inside the luminaire. Opening the luminaire will void warranty. Keep housing clean from dust and dirt with a dry or damp cloth to ensure optimal cooling. When using a damp cloth disconnect from the power first. Check your electrical connections regularly.
