SPECIFICATIONS
SZ-DM-200
Microphone Input . . . . . . . . . -55dB, 600 ohms
Aux Input . . . . . . . . . . . . . . . . -15dB, 27K ohms
Line Inputs . . . . . . . . . . . . . . . -15dB, 27K Ohms
Phone Inputs . . . . . . . . . . . . . -45dB
Master Output . . . . . . . . . . . . +0dB, 600ohms
Headphones Output . . . . . . . +5dB, 32
Frequency Response . . . . . . 20Hz to 20KHz @
Input Power . . . . . . . . . . . . . . AC 12V
Power Consumption . . . . . . . 6W
Operating Channels . . . . . . . 2
Device Inputs . . . . . . . . . . . . . Line: 2
Outputs . . . . . . . . . . . . . . . . . . Master, Headphones
Dimensions . . . . . . . . . . . . . . . 220 x 165 x 85mm
Weight . . . . . . . . . . . . . . . . . . . 4.2KG
ohms/300mW
+2dB
Phono: 2
USB: 1
Aux: 1
Mic: 1
9
