OWNER'S MANUAL
TRINITY 32" BAMBOO AND METAL KITCHEN CART
Model # TSCPWH-1413 / TSCPDG-1413
Important / Important / Importante
FOR 3D ASSEMBLY INSTRUCTIONS
Intelligent Instructions
Directives intelligentes
POUR DES DIRECTIVES D'ASSEMBLAGE 3D
Instrucciones Inteligentes
PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSCPWH-1413 and is the answer not in the manual?

Questions and answers

Related Manuals for Trinity TSCPWH-1413

Summary of Contents for Trinity TSCPWH-1413

  • Page 1 OWNER’S MANUAL TRINITY 32” BAMBOO AND METAL KITCHEN CART Model # TSCPWH-1413 / TSCPDG-1413 Important / Important / Importante FOR 3D ASSEMBLY INSTRUCTIONS Intelligent Instructions Directives intelligentes POUR DES DIRECTIVES D’ASSEMBLAGE 3D Instrucciones Inteligentes PARA INSTRUCCIONES DE ENSAMBLAJE EN 3D...

  • Page 2: Parts List

    PARTS LIST Your TRINITY 32” Bamboo and Metal Kitchen Cart should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com.
  • Page 3 Carefully turn over partially assembled unit from step 1 onto other side. Repeat step 1 to assemble remaining two legs. Put assembled cart upside down as shown. Fully tighten all (24) BOLTS (F) with provided HEX KEY (G). © 2023 TRINITY - 800.985.5506...
  • Page 4 Note: Use provided WRENCH (H) to tighten all casters completely. Failure to do as instructed could result in caster stem breaking. Stand cart right side up. Place BAMBOO TOP (I) on top of cart. © 2023 TRINITY - 800.985.5506...
  • Page 5 Unscrew (8) BOLTS (F) and (8) WASHERS (E) unfastening middle shelf from legs. Tilt middle shelf diagonally to move it up or down to your desired height. Attach middle shelf to LEGS (B) with (8) BOLTS (F) and (8) WASHERS (E). Fully tighten BOLTS (F) with hex key. © 2023 TRINITY - 800.985.5506...

  • Page 6: Service Parts List

    SERVICE PARTS LIST TSCPWH-1413 / TSCPDG-1413 – TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description ONA-20-009-3220 Bamboo Top ZSV-99-033-3010 Non-locking Caster ZSV-01-007-0613 Washer XXX-97-002-0008 Wrench ZSV-01-002-0615 Bolt XXX-97-001-0003 Hex Key PWH-04-061-3200 Leg (white) PWH-03-104-3018...
  • Page 7 12. Make sure that the casters are LOCKED when using the bamboo top as a cutting or work surface. 13. Load the product evenly and place the heaviest items on the lower shelves. 14. Do NOT leave knifes or sharp objects on the bamboo top unattended. © 2023 TRINITY - 800.985.5506...

  • Page 8: Care And Maintenance

    Clean up any spills immediately to prevent stains from forming on bamboo top. • Do not put hot items directly on bamboo top to prevent damaging and discoloring bamboo surface. • The product is designed for indoor use. outdoor use is not recommended. © 2023 TRINITY - 800.985.5506...

  • Page 9: Product Registration

    PRODUCT REGISTRATION Thank you for purchasing a TRINITY 32” Bamboo and Metal Kitchen Cart. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com.
  • Page 10 © 2023 TRINITY - 800.985.5506...

  • Page 11: Year Limited Warranty

    Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period. All replaced parts and Products become the property of Trinity and must be returned to Trinity.
  • Page 12 WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com Monday through Friday 5:00 AM –...
