Summary of Contents for Futureglass AST-SLDK48
- Page 1 AST-SLDK- 48"- 72" Shower Enclosure Installation Guide Astro Square Slider Shower Hardware Kit...
- Page 2 Included in your purchase Shipped in 2 separate boxes G Fixed Panel Floor Clip, Screw Slider Panel Edge Strip Floor Bracket & Screw Slider Panel Weather Strip & Wall Anchor Slider Panel Rollers C Fixed Panel Weather Strip H Fixed Panel Brackets M Roller Guides D Shower Rod N Aluminum Floor Strip Cap...
- Page 3 Thank you again for choosing Future Glass! Best Regards, The Team at Future Glass (760) 203 6255 info@futureglass.us Caution: Prohibited Products *Note these may damage the treatment and void any warranty • Avoid the use of any abrasives or polishes including water spot removers, toothpaste, polishes, rough, or gritty substances •...
- Page 4 Installation Guide ⁄ " ¼" Tools required for install. G Hacksaw Note: Silicone is not provided and will need to be Silicone and caulking gun Power drill H Utility knife purchased separately. We recommend using a clear, C Phillips head screwdriver Level mold resistant silicone which can be purchased at D Pencil...
-
Page 5: Before You Start
Confirm you have the correct model size. Model numbers and corresponding size range: AST-SLDK48 = 44" - 48" AST-SLDK52 = 48" - 52" AST-SLDK56 = 52" - 56" AST-SLDK60 = 56" - 60"... - Page 6 Glass Fabrication If fabricating custom glass for the Astro Square Slider Shower Hardware Kit, please use the specs below for the Sliding Door Panels. Astro Square Slider Kits 4 ⁄ ˝(120mm) 4 ⁄ ˝(120mm) 48" - 60" Door Panel 2˝(51mm) 2˝(51mm) Dimensions ⁄...
- Page 7 Astro Square Slider Kits 4 ⁄ ˝(120mm) 4 ⁄ ˝(120mm) 64" - 72" Door Panel 2˝(51mm) 2˝(51mm) Dimensions ⁄ ˝(16mm) 2 ⁄ ˝(59 mm) 2 ⁄ ˝(59 mm) Diameter Holes • Designed for Use With ⁄ ˝(10mm) 5⁄16" (8 mm) Monolithic Diameter Holes Tempered Glass...
- Page 8 Glass Fabrication If fabricating custom glass for the Astro Square Slider Shower Hardware Kit, please use the specs below for the Fixed Panel. Astro Square Slider Kits 3 ⁄ ˝(80mm) 3 ⁄ ˝(80mm) 48" - 72" Fixed Panel 3 ⁄ ˝(82mm) 3 ⁄...
- Page 9 Astro Square Slider Shower Hardware Kit skus. For example: If you are purchasing an AST-SLDK-48 Hardware Kit, you would need a Door Panel (SQ-SL-D-48) and a Fixed Panel (SQ-SL-F-48) to complete your project. To view the complete collection, visit our website: futureglass.us/collections/glass-panels Astro Square Slider Full Height Astro Square Slider Bath Height...
- Page 10 Center of threshold Place Slider Panel inside shower. Mark the threshold and Fixed Panel wall. Before starting the installation process, place the Slider Measure the width of threshold tile where shower door Panel inside the shower on cardboard to protect the is to be installed, this needs to be a minimum of 2 "...
- Page 11 Center of threshold 75" Mark the vertical line on Slider Panel wall. Mark the hole to drill on Fixed Panel wall. On the opposite wall where the Slider Panel will close Along the drawn level line, mark 75" from threshold. towards, measure to the center of the threshold tile and draw a vertical line using a level.
- Page 12 Drill the hole for the first Shower Rod Bracket. Install first Shower Rod Bracket. Using a 1⁄4" drill bit, drill a hole and install the Wall Anchor. Place Shower Rod Bracket over hole and drill screws Trim excess from the Wall Anchor hanging out of hole into Wall Anchor to secure Bracket.
- Page 13 47" your rod length should be 46". Use a hacksaw and allen screws. cut your Shower Rod to the correct length. Model numbers and corresponding size range: AST-SLDK48 = 44" - 48" AST-SLDK64 = 60" - 64" AST-SLDK52 = 48" - 52" AST-SLDK68 = 64" - 68"...
- Page 14 Move Slider Panel side Door Stopper over. Level Shower Rod and mark Rod Bracket position. Slide Slider Panel side Door Stopper all the way over to Slide Fixed Panel side of Shower Rod into first Shower other side to accommodate level in next step. Rod Bracket.
- Page 15 Mark hole to drill for second Shower Rod Bracket. Drill the hole for second Shower Rod Bracket. Remove Shower Rod from first Bracket and remove Using a 1⁄4" drill bit, drill a hole and install the Wall Anchor. second Shower Rod Bracket from Shower Rod and Trim excess from the Wall Anchor hanging out of hole mark the hole to be drilled on wall.
- Page 16 Install Shower Rod Bracket interior. Remove Shower Rod Bracket from interior. Screw in Shower Rod Bracket on Slider Panel side wall. Use Allen key to loosen Shower Rod Bracket from Bracket interior. Slide Shower Rod Bracket off of Bracket interior.
- Page 17 Slide Shower Rod Bracket on to Shower Rod. Install Shower Rod. Slide second Shower Rod Bracket on to Shower Rod Slide Fixed Panel Side of Shower Rod into first Shower past the cut end. Rod Bracket. Align Shower Rod and slide second Shower Rod Bracket onto Bracket interior on wall.
- Page 18 3 ⁄ " ⁄ " Mark hole to drill for Fixed Panel Floor Clip. Drill hole for Fixed Panel Floor Clip. On Fixed Panel Side of shower threshold, measure Using a 1⁄4" drill bit, drill hole and install Anchor 3 1⁄2" from wall. Then measure 5⁄8" over towards outside (see important message below).
- Page 19 Position grub screw to inside of shower 3 " Fixed Panel width from wall Install Fixed Panel Floor Clip and Rubber Block. Unscrew Fixed Panel Brackets. Install Fixed Panel Floor Clip and place a 1⁄16" rubber block Unscrew Fixed Panel Brackets from front...
- Page 20 Set the Fixed Panel in place. Align Fixed Panel and fasten Brackets. Gently slide the Fixed Panel down into the Fixed Panel Check to make sure the glass is level. If not, adjust by Floor Clip and on to the Rubber Block. Line up the holes adding thinner 1⁄16"...
- Page 21 Set Fixed Panel into Floor Bracket and mark hole. Install Floor Bracket. Make sure both of the bottom corners of the Fixed Using a 1⁄4" drill bit, drill hole and install Floor Anchor Panel measure the same distance from the front of the (see important message below).
- Page 22 Install Sliding Panel Rollers and Handle. Install the Slider Panel. Carefully install the Slider Panel Rollers. Then install the Lift the door and slowly lower the Rollers onto the Slider Panel Handle on the Slider Panel. Be sure that Shower Rod. When lowering the Panel be sure the Slider Panel is sitting on folded cardboard to avoid bottom of the Slider Panel slides into the floor bracket.
- Page 23 Adjust Slider Panel Stoppers. Level and adjust Slider Panel Rollers. If Slider Panel is not level when hung from Rollers you Important: Slide door gently when can use the Roller Adjustment Tool to level it up. testing door stops so as not to damage Slightly loosen the allen bolt on back of Slider Panel the door or the fixed panel.
- Page 24 Install the Roller Guides. Install Aluminum Floor Strip in line with Fixed Panel and optional Cap. Install Roller Guides on Slider Panel to prevent the door from being able to come off Rollers. Make sure Install Aluminum Floor Strip to prevent water there's no more than a 1⁄8"...
- Page 25 Trim Rubber Block. Apply silicone to seal Fixed Panel. Trim the Rubber Block with a utility knife so that Apply silicone around the wall and floor surface of the it is flush with the Glass Panel resting on top. The Fixed Panel.
- Page 26 Install Weather Strips. Once silicone has cured, you're done! Install the plastic weather strip on panels. The shortest Please register your warranty using the instructions on Weather Strip goes on the edge of the Fixed Panel. The the back cover of this document. longest bubble shaped piece goes on the outer edge of the Slider Panel near the handle.
