Sygonix 1898921 Operating Instructions

Operating Instructions
Sygonix Gateway
Item No. 1898921 / RSL / 433 MHz
Item No. 1898922 / RS2W / 868 MHz
Intended use
The product acts as a power socket and gateway and is equipped with a push button that turns
the power supply to attached loads on and off.
As a gateway is controls compatible and linked RS2W (868 MHz) and RSL (433 MHz) products.
The gateway is controlled through WLAN via mobile app, and additionally can be linked to
CONRAD CONNECT for additional functionality.
The product is intended only for the connection to a standard power socket with earth contact.
Refer to the technical data section to learn more about the maximum permissible loads.
The product is only designed for indoor use. Keep away from water and high-humidity sources
and the areas where these conditions occur (e.g. bathroom).
Please read the operating instructions carefully and do not discard them. If you pass the prod-
uct on to a third party, please hand over these operating instructions as well.
Any use other than that described above could lead to damage to this product and involves
the risk of short circuits, fire, electric shock, etc. No part of the product may be modified or
reconfigured! Please observe the safety instructions at all times!
This product complies with the legal national and European requirements. All names of compa-
nies and products are the trademarks of the respective owners. All rights reserved.
Package Contents
• Gateway (with socket)
• Operating Instructions
Application
There are compatible Android and iOS apps
available from the respective app stores.
Look for the "Sygonix RSL/RS2W" app and
download it onto your smart device.
An app instruction manual is available from
the URL listed in chapter „Up-to-date oper-
ating instructions".
Up-to-date operating instructions
Download the latest operating instructions via the link
www.conrad.com/downloads or scan the QR code.
Follow the instructions on the website.
Explanation of symbols
The lightning symbol inside of a triangle is used when there is a potential risk of
personal injury, such as electric shock.
This symbol indicates specific risks associated with handling, operation or use.
The arrow symbol indicates special tips and operating instructions.
The product is compatible with the
Conrad Connect IoT platform at
www.conradconnect.de
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe
these safety instructions! We do not assume any liability for any resulting
damage! We shall not accept liability for damage to property or personal injury
caused by incorrect handling or non-compliance with the safety instructions!
The warranty/guarantee will be void in such cases!
a) General
• The unauthorized conversion and/or modification of the product is not allowed for
safety and approval reasons. Do not open/disassemble!
• The product is designed in accordance with protection class I. Only a standard
grounding mains socket of the public supply grid (a wall socket, for example) may
be used as a power source.
• The mains socket into which the product is plugged must be easily accessible.
• The product is not a toy and should be kept out of the reach of children. Position
the product so it is out of the reach of children.
• The product is equipped with a child safety lock. An integrated mechanism will
release the holes of the receptacle only, if the two prongs of a power plug are
inserted into the two holes at once. Nevertheless, take special caution when chil-
dren are around. Children cannot recognize the danger arising from the incorrect
use of electrical devices. There is a risk of a life-threatening electric shock!
• Do not leave the packaging material lying around carelessly as it may be a danger
to children.
• Handle the product with care; it can be damaged by impacts, blows or falls even
from a low height.
b) Operating location
• The product may only be used in dry interiors; it must not get damp or wet! Never
position the product in direct vicinity of a bathtub, shower, bathroom, swimming
pool, or similar. Lethal hazard due to electric shock!
• The product must not be exposed to extremes of temperature, direct sunlight or
strong vibrations. Keep the product away from strong magnetic fields generated
by machines, electric motors or loudspeakers.
• Do not operate the device in environments where there are high levels of dust,
flammable gases, vapours or solvents. There is a danger of fire and explosion!
• Do not use this product in hospitals or medical institutions. Radiowaves may inter-
fere with medical equipment. The same may also apply to other areas.
c) Handling and Use
• Never plug in, unplug or operate the product when your hands are damp or wet.
There is a risk of a life-threatening electric shock! The same applies for the load
that is plugged into the socket of the product.
• Never connect the product to the power supply immediately after it has been trans-
ferred from a cold room into a warm one (e.g. during transport). The condensation
that forms might destroy the device. Moreover, there is danger of electric shock!
Allow the product to reach room temperature. Wait until the condensation has
evaporated. This might take several hours. Only then the product may be plugged
into the mains socket and put into use.
• Always use the gripping surface to pull a mains plug out of the product. Never
unplug a mains plug from a mains socket by pulling the cable.
• Never overload the product. Note the maximum permissible connected load in the
chapter 'Technical Data'.
• Do not connect in series! This can lead to an overload of the product! There is a
risk of fire!
• Do not operate while covered! At higher connected loads, the product becomes
warm, which can lead to overheating and potentially a fire if covered!
• Disconnect the product from the mains socket in thunderstorms for reasons of
safety.
• Volt-free only, if unplugged!
• Do not use the product if it is damaged. There is a risk of a life-threatening electric
shock! In this case, dispose of the product in an environmentally correct manner.
Safe operation can no longer be assumed if:
- the product shows visible signs of damage
- the product does not work at all or works poorly (leaking smoke or a smell of
burning, audible cracking noises, discolouration to the product or the adjacent
surfaces)
- the product was stored under unfavourable conditions
- it was exposed to heavy loads during transport
• Never pour any liquids above or next to the product. You run the risk of causing
a fire or a fatal electric shock. If any liquid has still managed to enter the device,
immediately switch off the power supply to the mains socket at which the product
is connected (turn off the fuse / circuit breaker / residual current operated circuit
breaker of the associated circuit). Only then can you unplug the product from the
mains socket and contact a specialist. Do not use the product any longer.
• Always pull the product out of the mains socket (e.g. wall socket) before cleaning it
or when the device will not be in use for a long time (e.g. for storage).
• Use the product only in a temperate climate, never in a tropical climate.
• If you have any questions that are not answered in this manual, please contact our
technical service or another specialist.
