User Instruction & Installation Manual
L560 Remote Control 2/3Kw
Tungsten Halogen Searchlight
Product Reference Number:
A2651 – Variable Speed Motor Unit 2/3Kw 115/240v
Manufacturers details:
Francis Searchlights Ltd
Union Road, Bolton
Lancashire, BL2 2HJ, UK
Tel:
+44 (0) 1204 558960
Fax:
+44 (0) 1204 558979
http://www.francis.co.uk
E-mail: sales@francis.co.uk
Manual Part Number: C21514
Get other manuals https://www.bkmanuals.com
Distributor details:
Issue : 5
Advertisement
Table of Contents
Summary of Contents for Francis A2651
- Page 1 User Instruction & Installation Manual L560 Remote Control 2/3Kw Tungsten Halogen Searchlight Product Reference Number: A2651 – Variable Speed Motor Unit 2/3Kw 115/240v Manufacturers details: Distributor details: Francis Searchlights Ltd Union Road, Bolton Lancashire, BL2 2HJ, UK Tel: +44 (0) 1204 558960...
-
Page 2: Table Of Contents
CONTENTS - Introduction - Safety Precautions - Technical Information - Unpacking and Installation Instructions - Electrical Installation - Operating Instructions - Fault Finding - Maintenance and Servicing - Wiring Diagram & General Assembly - Spare Parts List Get other manuals https://www.bkmanuals.com... -
Page 3: Introduction
For your future reference please keep this manual in a safe place. Thank you for specifying a product from the Francis Searchlights range. All Francis products are designed to give complete customer satisfaction and are manufactured to the highest engineering standards in order to ensure optimum performance and service life. -
Page 4: Safety Precautions
2 - Safety Precautions The following instructions must be adhered to, in order to ensure a safe working environment and the safety of the user. Note: When unpacking or manoeuvring the searchlight into its fixing position, suitable lifting points must be used in order to prevent damage to the equipment or personal injury. Prevent rain, snow, condensation and water droplets from contacting the lamp as this may cause bulb failure and possible shattering;... -
Page 5: Technical Information
3 - Technical Information This product has been designed to operate in accordance with the product specification. The L560RC searchlight has the following features: All marine grade materials and fixings; Parabolic formed aluminium reflector; Powder coated / Stove enamel paint finish; 385°... -
Page 6: Unpacking And Installation Instructions
4 - Unpacking and Installation Instructions The following instructions should be read and fully understood prior to installing the equipment to ensure that the correct procedures are followed and all safety precautions are observed. Note: If the equipment has been in storage for a considerable amount of time, it is advisable to conduct a routine maintenance check on all parts before installation. -
Page 7: Electrical Installation
5 - Electrical Installation For safety purposes, only competent personnel should perform the electrical installation. All equipment should be installed to current Electrical Regulations and Standards. In order to obtain the maximum light output from the searchlight, it is essential that the full operating voltage of the lamp fitted be applied to the lampholder contacts. - Page 8 Installation Guidelines A typical installation and connection routine for the L560RC 2/3Kw searchlight is as follows: Referring to wiring diagram C22978, a supply is fed to the control panel, which then provides a common feed to the motor gearbox and the searchlight. Cables required to be connected by the customer: - 4 core 1.5mm cable from the Motor Gearbox to the Control Panel.
-
Page 9: Operating Instructions
6 - Operating Instructions This equipment is designed for use out of doors, in free air. Never place anything on, or cover the searchlight when in use as this may present a hazard. The searchlight can be remotely positioned via the joystick control panel, with the facility for movement up, down, left and right. - Page 10 weaken the bulb material. Should the bulb be inadvertently touched, remove fingerprints with methylated spirit and a clean, soft paper towel. The bulb should then be wiped with distilled water. NOTE: ALWAYS WEAR MASK AND GLOVES DURING CLEANING); In all circumstances the lamp manufacturers data should be referred to when dealing with lamps. When fitting the lamp: Always isolate the equipment from the supply when inserting a lamp;...
-
Page 11: Fault Finding
Replace lamp ensuring all precautions and instructions previously outlined in this manual are adhered to. NOTE: If a fault occurs on the pan and tilt gearbox, the unit should be returned to Francis Searchlights Limited for fault evaluation and repair. -
Page 12: Maintenance And Servicing
8 - Maintenance and Servicing In order to prolong the service life and performance of your searchlight, the following maintenance guidelines are recommended: Maintenance checks should be conducted before very voyage or at least every three months; Before checking, disconnect the equipment from the supply; Visually inspect the condition of the equipment;... -
Page 13: Wiring Diagram & General Assembly
9 - Wiring Diagram and General Assembly Drawing Number Description C22978 Wiring Diagram Lite Range Variable Speed 20 Amp A2651 L560RC 2/3Kw 115/240v Variable Speed General Assembly drawing Control Panel Assembly Get other manuals https://www.bkmanuals.com... - Page 14 Get other manuals https://www.bkmanuals.com...
- Page 15 Get other manuals https://www.bkmanuals.com...
- Page 16 Get other manuals https://www.bkmanuals.com...
-
Page 17: Spare Parts List
Pedestal Cover Gasket In order to prolong the life and performance of your product, we recommend that you only specify Francis Searchlights spare parts. This will ensure that any warranties on your equipment will not be invalidated. When ordering spare parts please contact the Sales Department at Francis Searchlights Limited.
