Autonics AFS Series Product Manual

TCD210097AB
Interface Terminal Block
AFS Series
PRODUCT MANUAL
For your safety, read and follow the considerations written in the instruction
manual, other manuals and Autonics website.
The specifications, dimensions, etc. are subject to change without notice for product
improvement. Some models may be discontinued without notice.
Features
• Screw type connection for stable and reliable connection
• Ideal for PLCs and motion device I/O
• Compact, space-saving design
• Excellent environment resistance against dust and debris by hinged cover
• DIN rail mount and screw mount installation
※  A utonics CH/CO series I/O terminal block cables are recommended for best
performance.
ᜢ᜽ᜨᜫ
Safety Considerations
• Observeall'SafetyConsiderations'forsafeandproperoperationtoavoidhazards.
• ᜸symbolindicatescautionduetospecialcircumstancesinwhichhazardsmayoccur.
᜸ Warning
Failuretofollowinstructionsmayresultinseriousinjuryordeath.
01. Fail-safe device must be installed when using the unit with machinery that
may cause serious injury or substantial economic loss. (e.g. nuclear power
control, medical equipment, ships, vehicles, railways, aircraft, combustion
apparatus, safety equipment, crime/disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or
fire.
02. Do not use the unit in the place where flammable/explosive/corrosive gas,
high humidity, direct sunlight, radiant heat, vibration, impact, or salinity
may be present.
Failure to follow this instruction may result in explosion or fire.
03. Do not connect, repair, or inspect the unit, or remove connector while
connected to a power source.
Failure to follow this instruction may result in fire or electric shock.
04. Do not disassemble or modify the unit.
Failuretofollowthisinstructionmayresultinfireorelectricshock.
᜸ Caution
Failuretofollowinstructionsmayresultininjuryorproductdamage.
01. Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
02. Use dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in fire or electric shock.
03. Keep the product away from metal chip, dust, and wire residue which flow
into the unit.
Failure to follow this instruction may result in fire or product damage.
04. Do not use the product when a screw of terminal is loosened.
Failuretofollowthisinstructionmayresultinfireorproductdamage.
Cautions during Use
• Followinstructionsin'CautionsduringUse' . Otherwise,itmaycauseunexpected
accidents.
• Keepawayfromhighvoltagelinesorpowerlinestopreventinductivenoise.
Incaseinstallingpowerlineandinputsignallineclosely,uselinefilterorvaristorat
powerlineandshieldedwireatinputsignalline.
Donotuseneartheequipmentwhichgeneratesstrongmagneticforceorhigh
frequencynoise.
• Thisunitmaybeusedinthefollowingenvironments.
-Indoors(intheenvironmentconditionratedin'Specifications')
-Altitudemax.2,000m
-Pollutiondegree2
-InstallationcategoryII
