Summary of Contents for Hyundai Mobis MAR120
- Page 1 MAR120_77GHz Radar User Manual...
- Page 2 1. Specifications for Designing and Developing 1-1. Features and Main Specifications Vehicle Type Rear Lateral Radar Shape Rear Lateral Radar Assy • Solo SRR + Bracket Sensor • Solo SRR Main • Radar signal processor DSP SW Specifications • Warning Logic (BCW/RCCW) SW •...
- Page 3 1. Specification of Design Development 1-2. System Composition Outline of System Composition System Architecture Composition...
- Page 4 2. Rear Lateral Radar Detail of Function 1. Outline - Blind-Spot Collision Warning (BCW) and Blind-Spot Collision Avoidance Assist-Rear) (BCA-R) - Rear Cross-Traffic Collision Warning (RCCW) and Rear Cross-Traffic Collision Avoidance Assist (RCCA) - Safe Exit Assist(SEA) 2. System Composition Cluster...
- Page 5 2. Rear Radar Function Description 2-1. BCW (Blind Spot) Radar detects blind spot of vehicles to alert drivers - Warning method : Primary -LED lighting, Secondary - LED blinking + alert sound Function Alarm zone • Own speed above 20 kph Activation condition •...
- Page 6 3. Rear Radar Function Description 2-2. BCW (High speed approach) Radar detects fast approaching vehicles to alert drivers - Warning method : Primary -LED lighting, Secondary - LED blinking + alert sound Function Alarm zone • Own speed above 20 kph Activation condition •...
- Page 7 2. Rear Radar Function Description 2-3. BCA (Driving) Anti-collision assist function through control of braking in case of collision with adjacent vehicle during lane departure - Warning meth : LED lighting, alert sound - Control method : Braking Control via ESC Function •...
- Page 8 2. Rear Radar Function Description 2-4. BCA (Departure) Warning (sound/on screen) and control (Breaking) system that If there is a rear approaching object(Other vehicles, pedestrians and etc.) when vehicle is moving forward. - Warning meth : LED lighting, alert sound Function - Control method : Braking Control via ESC <Scenario of posterolateral BCA(Departure)>...
- Page 9 2. Rear Radar Function Description 2-5. RCCW Providing warning to driver via detecting side approach vehicles when reversing - Warning meth : LED lighting, Cluster is on screen, alert sound Function Activation • Gear is on Reverse, Own speed within 0kph ~ -10kph. condition •...
- Page 10 2. Rear Radar Function Description 2-6. RCCA A system that detects side approach vehicles when reversing and warns and controls them to prevent accidents - Warning meth : LED lighting, Cluster is on screen, alert sound - Control method : Control method : Braking Control via ESC Function •...
- Page 11 2. Rear Radar Function Description 2-7. SEA Warning and control system to prevent accidents when passengers get off after the vehicle stops - Warning meth : LED lighting, alert sound - Control method : When passenger attempt to get off, locked the door-lock Function •...
- Page 12 3. Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION TO USERS Changes or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate the equipment.
- Page 13 3. Statements Canada This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
