- Page 1 175-Lb. Drywall and Panel Hoist Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #57502 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Bannon™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Panel Lifter ........................7 Assembly Instructions .......................... 8 Before Each Use ..........................11 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use The Bannon 175-Lb. Drywall and Panel Hoist can lift plasterboard in every position: horizontal (ceiling installation), angled (sloping ceiling installation), and vertical (wall installation). It’s the only panel and drywall hoist that can be operated manually and automatically with power drill assistance. Its rack and pinion system allows you to lift plasterboards with less effort than others panel and drywall hoists. - Page 5 safety and could affect the life of the product. There are specific applications for which the product was designed. Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger industrial equipment.
-
Page 6: Specific Operation Warnings
Secure the work with clamps or a vise instead of your hand when practical. This safety precaution allows for proper tool operation using both hands. ⚠CAUTION HOIST USE AND CARE Do not force the hoist. Products are safer and do a better job when used in the manner for which they are designed. -
Page 7: Main Parts Of Panel Lifter
Be sure the winch components are clean and dry before operation. Inspect the tool for wear or damage. Pay special attention to any wear or damage to the wire rope. Carefully inspect the hoist before operating. Do not grease or oil the rack, pinion, or the gear. -
Page 8: Assembly Instructions
Reference Subassembly Integrated extension Support base for power drill Wooden platform Side foot Middle foot Balance bar with wheels 3/4’’ screw 1/4’’ screw 5/8’’ screw 1/8’’ screw Assembly Instructions 1. Attach the balance bar with wheels (10) to the main body (4) with the two 3 "... - Page 9 HORIZONTAL CEILING SETTING AND SLOPING CEILING : VERTICAL SETTING : Page 9 of 24...
- Page 10 STORAGE/MOVING POSITION : The top rack (3) must be in low position while changing the feet position. 4. Insert the 3.28 Ft extension (5) in the frame and lock it in the selected hole with the removable pin. The extension has 3 different height positions: 11.48 Ft – 13.12 Ft and 14.76 Ft. 5.
-
Page 11: Before Each Use
6. Assemble the arms (1) with the two 1 " screws (11) and nuts (15), using a 1/2" flat wrench and a 1/4" hex wrench. Be sure the arm marks match: R with R and L with L. 7. Insert the arms (1) in the top rack (3) according to the position selected. When you are in front of the steering wheel, put the R arm on your right and the L arm on your left. - Page 12 Do not obstruct the wheels while operating. It may cause the device to malfunction. Do not put your hand through the steering wheel while the top rack is lowering. It may cause hand or finger injuries. Do not remove the hoist’s safety labels. ...
- Page 13 3. Block the 2 wheel brakes, and then load the board. 4. Pull the handle to position the board on the chosen configuration. 5. Unlock the 2 wheel brakes and turn the steering wheel while pushing the main brake lever to lift the board.
- Page 14 Once the board is lifted to the required height, it has to stay in position when the safety brake is unlocked. If the board goes down, tighten the main brake by turning the knurled nut clockwise. If the board is heavier than a standard board (more than 55.12 lb.), turn the knurled nut clockwise to increase the spring power.
- Page 15 3. A. CEILING SETTING: Once the board is loaded, pull the top rack handle to put the board in horizontal position. Position the panel hoist with the steering wheel in front of the wall to lift the board along the wall. B.
- Page 16 4. Turn the steering wheel while pushing the main brake lever to lift the board up to the ceiling. VERTICAL LIFTING AND VERTICAL SLOPING CEILING SETTING 1. Insert the arms in the vertical tubes; the retractable pin must be locked in the selected hole according to the board dimensions.
- Page 17 VERTICAL LIFTING: Once the board is loaded, position the hoist along the vertical wall. Pull out the removable pins from the 2 lateral feet and open them up to the 2nd hole of the frame base. Insert the removable pins to lock the feet. Pull out the removable pin from the top rack in order to angle the board completely on vertical position, while pushing the hoist along the wall with help of the top rack handle.
- Page 18 Automatic Use Assisted by Power Drill 1. You must use the power drill support base for safety reasons. Set up the hoist according to the selected setting configuration 2. Insert the hex bit in the power drill chuck. 3. Adjust the power drill support base according to the power drill dimensions. 4.
-
Page 19: After Each Use
After Each Use After each use, the hoist should be stored in a dry, secure place, out of the reach of children. Maintenance Maintain the product by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures. It is recommended that the general condition of any tool be examined before it is used. -
Page 20: Troubleshooting
Troubleshooting Use the table below to troubleshoot problems before contacting service personnel or your local dealer. If the problem continues after troubleshooting, call your local dealer for assistance. Failure Possible Cause Corrective Action Tighten the main brake by turning the knurled nut clockwise. The top rack goes down instead of The main brake is not... -
Page 21: Parts Diagram
Parts Diagram Parts List Reference Part Number Part Description Quantity Brake lining Metallic cable Wheel with brake Wheel without brake Hex bit for using with power drill Wooden platform Page 21 of 24... -
Page 22: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ... -
Page 23: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only ("You" or ''Your'') that the Bannon product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 24 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in Taiwan Page 24 of 24...
