Summary of Contents for RF-Tuote DRM-814M2
- Page 1 DRM-814M2 DVB-S/S2/T/T2/C HD or SD to AM scaling remodulator VSB A2 User Manual info@rf-tuote.fi www.rf-tuote.fi RF-Tuote Oy, Joensuunkatu 13, 24100 Salo, tel. +358-2736 6360, fax. +358-2-736 6360,...
- Page 2 CCIR channels. DRM-814M2 is supplied with a A2 stereo/dual/swap dual/multistandard mono modulator, which can be used on the adjacent channels (VSB modulation) from S2 to E69. DRM-814M2 is valid for both MPEG-2 and MPEG-4 and as well H.265 signals. The multistandard modulator supports BG, I, DK, L, MN standards.
- Page 3 14. RS-232 connection for SW updating DRM-814M2 is designed for standard 19” rack mounting. Do not cover the air passage holes. Power cord is connected to power input connector 100-240VAC on the rear panel of the unit. Signal from antenna is connected to LNB or Antenna input.
- Page 4 3.3 Set-up To start set-up, press Menu key. Main Menu will be displayed. Select “Settings” menu. “Settings” menu is displayed. info@rf-tuote.fi www.rf-tuote.fi RF-Tuote Oy, Joensuunkatu 13, 24100 Salo, tel. +358-2736 6360, fax. +358-2-736 6360,...
- Page 5 Press “Exit” in RCU and then select “Subtitle” menu. If there is subtitling in a channel, set “Subtitle” ON and select a language. Press “Exit” in RCU twice to exit from “Settings” menu. info@rf-tuote.fi www.rf-tuote.fi RF-Tuote Oy, Joensuunkatu 13, 24100 Salo, tel. +358-2736 6360, fax. +358-2-736 6360,...
- Page 6 There are two ways to search channels; “Automatic” and “Manual”. “Manual” search is recommendated as it is faster than “Automatic” mode. “Automatic” mode is used only if channel frequency is not known. info@rf-tuote.fi www.rf-tuote.fi RF-Tuote Oy, Joensuunkatu 13, 24100 Salo, tel. +358-2736 6360, fax. +358-2-736 6360,...
- Page 7 Select “Start scan” and press OK. When scanning is ready, press “Exit” three times to exit from menu. The program can be selected now with CH or CH pushbuttons. info@rf-tuote.fi www.rf-tuote.fi RF-Tuote Oy, Joensuunkatu 13, 24100 Salo, tel. +358-2736 6360, fax. +358-2-736 6360,...
- Page 8 Fore more information about where you can drop off your waste equipment for recycling, please contact your local city office, your house disposal service or the shop where you purchased the product. info@rf-tuote.fi www.rf-tuote.fi RF-Tuote Oy, Joensuunkatu 13, 24100 Salo, tel. +358-2736 6360, fax. +358-2-736 6360,...
