Mizuho MES-CK08-075-20EN-0 Instructions For Use

MES-CK08-075-20EN-0
PREPARED: (2023-07-26) (Version 6)

Warning

When using operating table accessories, always pay close attention to
the patient. Patients left in the same posture for an extended period
of time are at risk for developing nerve paralysis and/or bedsores.

Contraindication/Prohibition

This product is only validated for use with Mizuho operating tables.

Symbol mark for labeling

MD : Medical Device

Specifications

1.

Shape

08-075-23/23-UE/18-042-00/01
Be sure to read this instruction manual before using this product.
Keep this manual available for reference when needed.
Instruction for Use
Trade Name: Head Extension
(mm)
1/3
08-075-28/-R1/-R2
08-083-02/22/42/18-042-00/01
08-075-90/-R1/-R2
Code No. Product Description
Radiographic Top for Head
08-075-23
Extension *1
Radiographic Top for Head
08-075-23-UE
Extension (UE) *2
08-075-28 Head Extension for 5701 *3
08-075-28-R1 Head Extension (R1) *4
08-075-28-R2 Head Extension (R2) *5
⑩
(mm)
(mm)
Compon Wei
ents ght
⑦⑧⑨ 1.3 ㎏
⑦⑧⑨ 1.3 ㎏
①②③④
7.0 ㎏
⑤⑨
①②③④
7.0 ㎏
⑤⑨
①②③④
7.0 ㎏
⑤⑨
