Summary of Contents for Security systems CP155B
- Page 1 CP155B Weather Resistant Keypad With Prox Security Systems Installer Reference Guide Security System...
-
Page 2: Installation
Keypad Addressing 1 x 2mm Hex Key Each keypad fitted to the system must be assigned a unique address on the LAN. The CP155B includes a DIP switch for quick address selection. The following table Installation shows the address setting for each keypad as well as the number of keypad devices each panels can support. -
Page 3: Keypad Operation
The CP155B also includes an egress input and lock out- put which can be used to control door access if required. Step 7) Carefully hook the keypad to the backplate and fit the 2 Hex screws using the allen key supplied. - Page 4 Hold Down Functions LED Operation For Area Control Condition Meaning The CP155B keypad supports the following hold down functions. These functions will only work if the keypad Area All On has been assigned to an area. When keypads are in-...
- Page 5 The keypad volume lev- is disarmed. el cannot be adjusted on the CP155B however it can be Table 7: Keypad Tones turned off via panel programming by setting the keypad volume to the lowest level.
-
Page 6: Configuration Examples
6) Set output event assignment. 7) Assign users to the area. 8) Assign users to the door. Examples show how to configure the CP155B to control a door. Consult the control panel installation manual for further programming information. Bosch Security Systems 02/18 CP155BIRG FTR1.2... -
Page 7: Connection Diagram
Dimensions: 83mm(W), 30mm(D), 129mm(H) Environment: -10˚ to 55˚C RH 5 to 93% non-condensing IP65. The CP155B should be mounted on a sturdy vertical wall using fixtures appropriate for the wall Fixing Method: construction type. Warranty: 3 years from date of manufacture (return to base). - Page 8 Bosch Security Systems Level 2, 21 Solent Circuit Baulkham Hills, NSW 2153 Australia Phone: 1300 026 724 www.boschsecurity.com.au © 2018 Bosch Security Systems CP155BIRG Issue FTR1.2...
