Sony SSC-G103A Specifications

SSC-G103A
Analog Color Fixed Camera
540 TV Line Security Camera
with High Sensitivity
Horizontal resolution of up to 540 TV lines
High sensitivity 0.15 lx (F1.2, 50 IRE, Color)
Optional CS mount lens available
Compact design
KEY FEATURES
• High resolution (540 horizontal TV lines) and high
sensitivity (0.15 lx, F1.2, 50 IRE) achieved by an
1/3-type Super HAD CCD II™ sensor and Sony's
new digital signal processor, Effio-E™.
• Electrical Day/Night function to switch to Day or
Night mode depending on the light level.
• Low power consumption: 1.4 W (Max.).
• Dip SW Control for easy mode setting.
• ATR-Lite (Adaptive Tone Reproduction
Lite) to compensate for gradation of
subjects to an optimum level.
• iBLC to compensate for exposure
levels in dark scenes to help improve
subject visibility.
• ATW (Automatic Tracing White)
balance which automatically adjusts
the camera's white balance to adapt
to sudden changes in lighting
conditions.
• Internal lock, and line lock selectable.
• 2D noise reduction employed.
• AC 24 V / DC 12 V operation (±10 %).
