  • Page 1 Smart Scene Panel Featuring LoRaWAN ® WS136 & WS156 User Guide...
  • Page 2 Safety Precautions Milesight will not shoulder responsibility for any loss or damage resulting from not following the instructions of this operating guide. The device must not be modified in any way.  In order to protect the security of the device, please change device the password when first ...
  • Page 3 Revision History Date Doc Version Description Oct. 19, 2021 V 1.0 Initial version 1. Change insulating sheet place Aug. 1, 2022 V 1.1 2. Change RX2 setting place 1. Add Single-Channel Mode; Jan. 16, 2023 V 1.2 2. Add Milesight D2D LoRa Uplink feature;...

  • Page 4: Table Of Contents

    Contents 1. Product Introduction ......................... 5 1.1 Overview ...........................5 1.2 Features ........................... 5 2. Hardware Introduction ........................5 2.1 Packing List ..........................5 2.2 Hardware Overview ......................... 6 2.3 Dimensions (mm) ........................6 2.4 LED Patterns ..........................6 3. Operation Guide ..........................6 3.1 NFC Configuration ........................

  • Page 5: Product Introduction

    1. Product Introduction 1.1 Overview WS136 & WS156 is a LoRaWAN ® based smart panel for wireless controls, triggers and alarms. Without any additional cable, WS136 & WS156 can be easily installed anywhere and control devices via LoRaWAN or Milesight D2D communication protocol. Besides, it’s equipped a user-definable E-ink screen to suit different scenes.

  • Page 6: Hardware Overview

    2.2 Hardware Overview Note: For WS136, the E-ink screen is replaced by PVC sticker and the icons on the sticker supports customization. 2.3 Dimensions (mm) 2.4 LED Patterns Indicator Action Indication Always on until the button is Button Light...

  • Page 7: Lorawan Settings

    2. Download and install “Milesight ToolBox” App from Google Play or App Store. 3. Enable NFC on the smartphone and open Milesight ToolBox. 4. Attach the smartphone with NFC area to the device to read device information. 5. Basic information and settings of the device will be shown on ToolBox if it’s recognized successfully.
  • Page 8 Parameters Description Device EUI Unique ID of the device which can also be found on the label. App EUI Default App EUI is 24E124C0002A0001. Application Port The port is used for sending and receiving data, the default port is 85.
  • Page 9 If frequency is one of CN470/AU915/US915, enter the index of the channel that you want to enable and make them separated by commas. Examples: 1, 40: Enabling Channel 1 and Channel 40 1-40: Enabling Channel 1 to Channel 40...

  • Page 10: General Settings

    Allow network server to adjust datarate of the device. This only works with ADR Mode Standard-Channel Mode. Tx Power Transmit power of the device. Note: 1) Please contact sales representative for device EUI list if there are many units.

  • Page 11: E-Ink Screen Display Settings

    3. Enable one of WS136 & WS156 button mode and configure a 2-byte hexadecimal command (This command is pre-defined in Milesight D2D agent device). When you press this button, WS136 & WS156 will send the control command to corresponding Milesight D2D agent devices.

  • Page 12: Maintenance

    Note: 1) WS156 e-ink screen will show below fixed icons: Icon Description Battery level The device joins the network. The device fails to join the network. 2) WS156 do a full-screen refresh once a week in order to remove ghosting.

  • Page 13: Backup

    2) Only Android version ToolBox supports the upgrade feature. 3.6.2 Backup WS136 & WS156 supports configuration backup for easy and quick device configuration in bulk. Backup is allowed only for devices with the same model and LoRaWAN frequency band.

  • Page 14: Reboot And Reset

    3.6.3 Reboot and Reset Via Hardware: Hold on the button inside the device for 3s to reboot, 10s to reset. Via ToolBox App: Go to Device > Maintenance to tap Restart or Reset, then attach smartphone with NFC area to the device to complete reboot or reset.

  • Page 15: Device Payload

    Fixed by 3M Tapes: Paste 3M tape to the back of the panel, then tear the other side and place it on a flat surface. Please note the screen direction when installing. Fixed by 86 Box: Remove the back cover of the panel, screw the back cover to the 86 box with two M4 mounting screws, then install back the panel.

  • Page 16: Button Message

    Example: ff0bff ff0101 ff166592b32851010013 ff090100 ff0a0102 Channel Type Value Channel Type Value ff (Reserved) 01 (V1) (Power On) (Protocol Version) Channel Type Value Channel Type Value 16(Device 6592b328510 0100 10013 (Hardware version) (V1.0) Channel Type Value 0102 (Software (V1.2) version) 5.2 Button Message...
  • Page 17 Channel Type Description 03 (Set Reporting Interval) 2 Bytes, unit: s 35 (Set Milesight D2D Key) 8 Bytes, other bytes are fixed as 0. 36 (Set Milesight D2D Byte 1: Spreading factor...
