TITAN HEAVY DUTY RANGES
TITAN BAKING AND ROASTING OVENS
MODELS: JTRH and JTRHE Series
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
NOTE: Instructions must be posted in a prominent location, which will instruct the user in the event that
he/she detects the smell of gas. This information shall be obtained from your local gas company.
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operating and maintenance instructions
thoroughly before installing or serving this equipment.
Adequate clearances must be provided in front, rear and at sides of appliance for servicing. The
appliance area must be kept free and clear from combustibles. There must be no material or obstacles
obstruction the flow of combustion and ventilation air.
P/N 24-132 REV A 7/00
Jade Range LLC, A Middleby Company
2650 Orbiter Ave.
Brea, CA 92821
Telephone (714) 961-2400
FAX (714) 961-2550
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
• Open windows
• Do not touch electric switches
• Extinguish any open flame
• Immediately call your gas company
WARNING
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Page 1
Advertisement
Table of Contents
Related Manuals for Jade JTRH Series
Summary of Contents for Jade JTRH Series
- Page 1 Jade Range LLC, A Middleby Company 2650 Orbiter Ave. Brea, CA 92821 Telephone (714) 961-2400 FAX (714) 961-2550 TITAN HEAVY DUTY RANGES TITAN BAKING AND ROASTING OVENS MODELS: JTRH and JTRHE Series INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS NOTE: Instructions must be posted in a prominent location, which will instruct the user in the event that he/she detects the smell of gas.
- Page 2 CLEARANCES and VENTILATION This appliance is design-certified for installation with the following conditions: MINIMUM CONSTRUCTION CLEARANCES FROM COMBUSTIBLE MATERIALS: Side Rear Floor With 6” High Legs 4 inches 2 inches 6 inches Without 6” High Legs 4 inches 2 inches 0 inch Without 6”...
-
Page 3: Preparation For Installation
PREPARATION FOR INSTALLATION Safe and satisfactory operation of your equipment depends to a great extent upon its proper installation. Installation must conform with local codes, or in the absence of local, with the National fuel code, ANSI Z233.1-1988 or later. Electrical installation must conform with all applicable state and local codes and be in compliance with the National Electrical Code, ANSI/NFPA 70-1990. - Page 4 LIGHTING AND RELIGHTING INSTRUCTIONS TOP SECTION: The top sections of your appliance are equipped with constant burning lighters. Lighters and burners should be manually lighted immediately after the gas is turned on. Adjustments can be make through the observation openings in front valve cover. Using a screwdriver, lighter flames can be adjusted by turning the lighter adjustment screw* clockwise or counterclockwise.
-
Page 5: General Information
7. Check pilot flame (still ignition). 8. Replace oven kick plate. 9. To operate – set thermostat to desired temperature. 10. Push rocker switch to “AUTO” position to turn on oven blower. CAUTION: TO OPERATE THE PILOT REIGNITOR, THE MASTER ELECTRIC SWITCH (TOGGLE SWITCH LOCATED AT THE TOP OF THE PANEL) MUST BE IN THE ‘ON’... - Page 6 With gas connections and necessary piping correctly installed to and at the appliance according to the latest National Fuel Code and with the wiring correctly installed to the latest electrical codes – proceed as follows: 1. Turn on main electrical power to the appliance (circuit breakers). 2.
-
Page 7: Service And Maintenance
The Jade Convection Oven described within these instruction sheets under the “Titan Convection Oven-Gas Controls” can also be equipped with electric ignition. SERVICE AND MAINTENANCE Contact the factory, factory representative or a local service company to perform maintenance and repairs. - Page 8 This appliance is serviceable to the front. It is suggested to provide at least 36 inches to the front of the appliance for servicing and for proper operation. When the appliance is equipped with casters, the installation shall be made with a connector that complies with the standard for Connectors for Movable Gas Appliances, ANSIZ21.69-1987, and Addenda, Z21.691989, and a quick-disconnect device that complies with the Standard for Quick-Disconnect Devices for Use With Gas Fuel, ANSIZ21.41-1989.
- Page 9 INSERT -- Restraining device picture. P/N 24-132 REV A 7/00 Page 9...
- Page 10 INSERT -- ELECTRIC DIAGRAM CONVECTION OVEN NOTE: A WIRING DIAGRAM CAN BE FOUND ON THE INSIDE OF THE OVEN KICK PLATE. CAUTION: In the event of prolonged power failure, DO NOT attempt to operate appliance. P/N 24-132 REV A 7/00 Page 10...
- Page 11 P/N 24-132 REV A 7/00 Page 11...
