Sielox Trove2SL2 Installation Manual

Trove2 enclosure with altronix/sielox backplane

Hide thumbs

Trove2SL2

- Trove2 enclosure with Altronix/Sielox backplane (TSL2)

TSL2

- Altronix/Sielox backplane only

Installation Guide

SIGNALING

All registered trademarks are property of their respective owners.

Rev. THC080520

Installing Company: _________________________ Service Rep. Name: __________________________________________

Address: _________________________________________________________ Phone #: _________________________

Access & Power Integration

Table of Contents

Need help?

Do you have a question about the Trove2SL2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sielox Trove2SL2

Page 1 Access & Power Integration Trove2SL2 - Trove2 enclosure with Altronix/Sielox backplane (TSL2) TSL2 - Altronix/Sielox backplane only Installation Guide SIGNALING All registered trademarks are property of their respective owners. Rev. THC080520 Installing Company: _________________________ Service Rep. Name: __________________________________________ Address: _________________________________________________________ Phone #: _________________________...
Page 2 1. Remove backplane from enclosure prior to mounting (do not discard hardware). 2. Trove2SL2 (Pg. 4): Mark and predrill holes on the wall to line up with the top three keyholes in the enclosure. Install three upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s upper keyholes over the three upper screws;...
Page 3 PD8UL/PD8ULCB, MOM5, PDS8(CB) or VR6. 2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 2, 2a, pg. 2). 3. Mount Sielox AC-1700 modules into the correct positions (Fig. 2, pg. 2). Note: Sielox AC-1700 boards have one (1) RJ45 jack each.
Page 4 TSL2: Configuration of Sielox AC-1700 Modules 1. Fasten spacers (provided) to pems that match the hole pattern for Sielox AC-1700 modules, see below (Fig. 3, pg. 4). 3. Mount Sielox AC-1700 modules into the correct positions (Fig. 3, pg. 4).
Page 5 Notes: Trove2SL2 / TSL2 Installation Guide - 5 -...
Page 6 - Programmable via USB or web browser - includes operating software and 6 ft. USB cable. LINQ2 Mounts Inside any Trove Enclosure LINQ2 Module Network Connection: Installation, Programming and Monitoring Altronix eFlow Power Supply - 6 - Trove2SL2 / TSL2 Installation Guide...
Page 7 TSL2 Dimensions (H x W x D): 25.375” x 19.375” x 0.5” (644.6mm x 492.1mm x 12.7mm) 19.375” (492.1mm) 2.2” (55.9mm) 2.2” (55.9mm) 0.156” ( 3.96mm) 1.0” (25.4mm) 1.0” (25.4mm) 7.5” (190.5mm) 7.5” (190.5mm) 9.2” (233.7mm) 9.2” (233.7mm) Trove2SL2 / TSL2 Installation Guide - 7 -...
Page 8 Trove2SL2 Enclosure Dimensions (H x W x D): 27.25” x 21.75” x 6.5” (692.15mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...

This manual is also suitable for:

Tsl2
