Gigawave INCAM-G Operator's Manual

Wireless camera transmitter

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

The information contained in this manual remains the property of Gigawave and may not be used,

disclosed or reproduced in any other form whatsoever without the prior written permission of

Gigawave.

Gigawave reserves the right to alter the equipment and specification appertaining to the equipment

described in this manual without notification.

INCAM-G

Wireless Camera Transmitter

OPERATOR'S MANUAL

CABK-ASOM-735x-01

INCAM-G Operator's Manual

Page 1 of 25

Table of Contents

Need help?

Do you have a question about the INCAM-G and is the answer not in the manual?

Questions and answers

Summary of Contents for Gigawave INCAM-G

Page 1 The information contained in this manual remains the property of Gigawave and may not be used, disclosed or reproduced in any other form whatsoever without the prior written permission of Gigawave. Gigawave reserves the right to alter the equipment and specification appertaining to the equipment described in this manual without notification.
Page 2: Table Of Contents
Maximum RF Power Density Limits ................. 5 Document Issue Status....................5 Introduction ..........................6 Specifications .......................... 8 Installing the INCAM-G onto the camera ................10 INCAM-G operation ....................... 11 On / Standby / Off switch ....................11 Connectors and Pin outs ....................11 5.2.1 Rear Connectors......................
Page 3: General Information
For details contact your local authority/recycling centre. Environmental The INCAM-G is IPxx rated and it must be protected from dripping or splashing water/fluids. When installed in a camera and used outdoors the unit should be protected by the rain cover which is normally used to protect the camera.
Page 4: Health & Safety
It is important to note that the guidelines adopted differ throughout the world and are from time-to-time re-issued with revised guidelines. For Gigawave use, a maximum power density limit (w) of 1w/m² is to be applied when calculating minimum safe working distances.
Page 5: Maximum Rf Power Density Limits
Different power density / frequency characteristics are presented in the two documents. To avoid complexity and to avoid areas of uncertainty, Gigawave recommends the use of a single power density limit across the frequency range 100 kHz to 300 GHz. The 1w/m² power density limit we recommend satisfies the most stringent of the guidelines published to date.
Page 6: Introduction
2 Introduction The INCAM-G is a Wireless Camera Transmitter built into the rear housing of the Grass Valley LDX series cameras. The system includes a UHF data receiver unit for camera. Features include:  Includes built in wireless camera control receiver module.
Page 7 Typical INCAM-G system configurations COFDM video link triax MVL-HD3 series 2/4 way diversity L2174 series 2 or 4 way diversity Dual RF head, single triax receiver Choice of OCPs OCP5 or OCP400 CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 7 of 25...
Page 8: Specifications
Transmit Power Switchable in steps 10 to 200mW (frequency band dependant) Linear distortion pre-correction of RF COFDM carrier, for improved spectral re-growth. Transmit Antenna Gigawave Omni Directional 4dBi gain (nom.) Modulation Switchable DVB-T 2K  LMS-T, single and double COFDM carriers (factory option) ...
Page 9 12 - 16VDC, 18 Watts Mechanical Interface Mounts inside the camera rear housing Weight Rear housing weight with transmitter fitted 2.3kg Environmental Temperature: to +50 Altitude: 4500m Humidity: 95% humidity long term CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 9 of 25...
Page 10: Installing The Incam-G Onto The Camera
3. Mating Holes 4. Tightening Screws To install the Incam-G rear housing to the LDX series camera, join the two parts together with the Mating Plugs (5) inserting into the Mating Holes (3). Next fasten the Retaining Screws (1) at the top of the camera into the Retaining Screw Holes (2).
Page 11: Incam-G Operation
5 INCAM-G operation On / Standby / Off switch The integral transmitter is independently powered form the camera, and is turned on using the three-way switch at the back of the camera (as shown below for item 4 in section 5.2.1). The switch can be set to off (no power to transmitter), standby (power to transmitter but not transmitting) and on (powered and transmitting).
Page 12: Video Out (2)
This switch powers the integral transmitter (see section 5.1 above) 5.2.1.5 Steadicam Tally (5) This connector provides CVBS and Tally drive levels for an external tally box when used in steadicam configuration (Gigawave part number UNGA-CATA-7001). Connector type: 5 pin Lemo Function +Vbatt Protected with 0.5A Polyfuse...
Page 13: Remote Configuration (8)
Cold 5.2.1.8 Remote Configuration (8) Used to connect to PC for configuration using a TTL to USB converter cable (Gigawave part number CABK-ASSY-2205 and CABK-ASSY-2207) Connector type: Binder 719 Sockets Function TTL RXd TTL TXd nENABLE 5.2.1.9 RF Antenna (9)
Page 14: Side Connectors
2. SDI Out 5.2.2.1 Return In (1) SDI Input from an external return video receiver Connector type: 75Ω BNC 5.2.2.2 SDI Out (2) This connector provide HD-SDI/SDI video out. Connector type: 75Ω BNC CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 14 of 25...
Page 15: Transmitter Configuration Via Windows Pc Application
 the setup routine.  Connect the INCAM-G to a USB port on the PC using the communication cable provided. On the PC select the COM port that is being used and click “connect” on the task bar’; “unit ...
Page 16  The current configuration of the INCAM-G will now show in the lower part of the window as illustrated above To make a change, click on the drop-down “setting” list, change the value using the ...
Page 17: Camera Control
MVL-HD3 2 or 4 way diversity Choice of OCPs Dual RF heads Grass Valley or Gigawave OCP5 Note: In this system the Interface Unit shown in section 6.2.4 is not required. The function of the Interface Unit is built into the MVL-HD3 receiver control unit CABK-ASOM-735x-01 INCAM-G Operator’s Manual...
Page 18: Mvl-Hd3 Receiver With Separate Camera Control Tx
6.2.2 MVL-HD3 receiver with separate Camera control TX Note: In this system the Interface Unit shown in section 6.2.4 is required only when a Grass Valley OCP is in use. It is not required for the Gigawave OCP5. RS232 triax...
Page 19: Mtv-Hd3 Receiver
6.2.3 MTV-HD3 receiver Note: In this system the Interface Unit shown in section 6.2.4 is required only when a Grass Valley OCP is in use. It is not required for the Gigawave OCP5. RS232 CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 19 of 25...
Page 20: Interconnection Details, When Interface Unit
6.2.4 Interconnection details, when Interface Unit Note: Grass Valley OCP only, not required for Gigawave OCP5 CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 20 of 25...
Page 21: Arrangement For Multiple Ocps And Cameras, Using A Single Data Tx
6.2.5 Arrangement for multiple OCPs and Cameras, using a single Data TX Note: Use with Gigawave OCP5 only In this arrangement all cameras are controlled from a single Data Transmitter. Control data is multiplexed onto a single narrow band RF carrier, requiring provision of only a single carrier frequency.
Page 22: Preparing For Operation
The Receiving Equipment The INCAM-G transmitter may operate in conjunction with a variety of Gigawave receivers, including MTV-HD3 receiver, MDR multi-channel receiver, MVL-HD2, MVL-HD3 two or four way diversity systems and Link L2174 receiver.
Page 23: Table Of Cofdm Bit Rates
14.73 22.11 6.63 13.27 19.89 9.04 18.09 27.13 8.29 16.59 24.88 7.45 14.92 22.39 10.05 20.11 30.16 9.21 18.43 27.64 8.29 16.59 24.88 10.55 21.11 31.67 9.67 19.35 29.03 8.71 17.41 26.12 CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 23 of 25...
Page 24: Lms-T Bit Rates
SINGLE PEDESTAL, 1/8 GI Bandwidth: QPSK 2.76 3.69 4.61 5.53 6.45 7.37 9.22 11.06 16QAM 5.53 7.37 9.22 11.06 12.90 14.75 18.43 22.12 Dual pedestal rates are double the equivalent Single pedestal values CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 24 of 25...
Page 25: Internal Architecture Block Diagram
9 System Block Diagram CABK-ASOM-735x-01 INCAM-G Operator’s Manual Page 25 of 25...
