823-2 Wonsi-dong, Ansan-shi, Kyouggi-do, KOREA
Tel : Int+82-31-490-3000 Fax : Int+82-31-490-3019
ELECTRIC HAMMER DRILL
(Oil grease lubrication type)
PHD-38
PHD-3800
PHD-3800M
O h D - 4 0 0 0R
OhD-4000M
Please read this manual to the last
for safe and efficient operating
before using, keep well in place
can find easily.
2004.02.28
PHD-38
(Grease lubrication type)
(Grease lubrication type)
OhD-4000R
(Grease lubrication type)
M A N UA L
OhD-4000M
(Grease lubrication type)
www.keyang.com
PHD-3800
PHD-3800M
S D S - M A X
S D S - M A X
Advertisement
Related Manuals for Keyang PHD-38
Summary of Contents for Keyang PHD-38
- Page 1 ELECTRIC HAMMER DRILL PHD-3800 PHD-38 (Grease lubrication type) (Oil grease lubrication type) PHD-38 PHD-3800M (Grease lubrication type) PHD-3800 S D S - M A X PHD-3800M O h D - 4 0 0 0R OhD-4000M OhD-4000R (Grease lubrication type)
- Page 2 Safety Rules We, Keyang Electric Machinery Co., Ltd., would like to express our sincerest GENERAL SAFETY INSTRUCTIONS gratitude to you who always use 1. Keep your work area in order. our power tools. Distractions in the work area and workbench may cause accidents.
- Page 3 ■Never adjust the slip clutch torque without permission. at a Keyang Service Center. Do not use a tool when its switch is not functioning. The slip clutch is set in the specified slip torque for shipment at factory. Too hard fastening of the slip clutch torque may cause an accidental movement of the hammer drill.
- Page 4 3.5mm 100m Operation without oil may cause trouble. ■For oil lubrication type (PHD-38) tool, always run idling before the Damaged cord must be displaced or repaired immediately. ceiling operation. Always run a idling for two minutes or more by standing the hammer drill for the ceiling operation.
- Page 5 Use 110 V only tool in 220 V outlet can cause motor failure or electric shock. 1. Specifications 5. Switch M o d e l PHD-38 PHD-3800 PHD-3800M OhD-4000R OhD-4000M Items Single phase AC 50/60 Hz When you plug in the power supply with the tool switched on, sudden rotation of...
- Page 6 ・Outer diameter: 25, 29, 32, 35, 38, (3) Core bit 3. Special part(option) 45, 54, 64, 79, 94, 105mm. (4) Core bit shank ・Outer diameter of core bit: 25, 29, 32, 35, 38mm 1) Drilling (rotation & impact) ・Outer diameter of core bit: 38, 45, 54, 64, 79, 94, 105mm ・Anchor adapter for impact &...
- Page 7 The S shaped earth adapter is used only for our S shaped earth rod type special adapter of Oil gauge Dust cover Drill bit Keyang Electric Machinery Co., Ltd. S w i t c h R e t a i n e r H a n d l e...
- Page 8 4. Bit attachment detachment Operating Instructions Pull tool plug out of socket before attaching or detaching bit. 1. Hexagonal Sink (PHD-38, PHD-3800, OhD-4000R) 1. Using the stopper Attach/detach bit under condition where retainer has Holder bolt Stopper been raised up.
- Page 9 • Do not apply too much grease. This can cause a bad impact. to the wall or floor lightly and straightly. Start to • Only the special grease for Keyang Hammer Drill in low viscosity should be operate the tool with full surface of the core bit chip used.
- Page 10 Keep tools out of reach of children in dry area. 7. Malfunction or failure Disconnect the plug from the power supply before making maintenance. Troubleshooting or repairing by consumer is dangerous. Call for Keyang Service Center for the best solution.
