- Page 1 Installation, Operation and Maintenance Instructions Controller Manual 3216 Controller 3216 Controller MEN-3216_CTRL (07-10-2021)
-
Page 2: Table Of Contents
Contents This manual is for guidance on the use of the Carbolite Gero product specified on the front cover. This manual should be read thoroughly before unpacking and using the furnace or oven. The model details and serial number are shown on the back of this manual. - Page 3 1.8.2 Digital Communications - RS485 1.8.3 Comms Address 1.8.4 Alarm Option Temperature Controller Replacement 1.10 3216 Controller Navigation Diagram...
-
Page 4: 1.0 3216 Controller
1.0 3216 Controller PID control This controller uses PID (Proportional Integral Derivative) temperature control. This type of control uses a complex mathematical control system to adjust the heating power and achieve the desired temperature. 3216P1 The 3216P1 is a digital temperature controller which uses PID algorithms to give excellent temperature control. -
Page 5: Keys
1.4.2 Keys The page key is used to access level 2 when held down Page Key for 3 seconds. Scroll Key The scroll key is used to scroll through parameters. When pressed simultaneously the ACK function is used Page and Return to the Home Menu Scroll Acknowledge an alarm if activated. -
Page 6: Understanding User Levels
1.5.4 Understanding User Levels There are two user levels in the controller; Level 1 (Operator) and Level 2 (Supervisor). Level 1 (Operator) is for the day to day operation of the controller. These parameters are not protected by a security code. Level 2 (Supervisor) provides access to additional parameters. -
Page 7: Setting Up The Controller
If while navigating the controller, a parameter has been passed or you need to access parameters which would be at the end of a scroll list, press and hold scroll and use to return to a previous parameter. Setting up the Controller Before using the controller (or during its lifetime) certain parameters may have to be set, depending on specific requirements. -
Page 8: Customer Calibration
Press and hold the page for three seconds until “GOTO” is displayed. Press scroll until the display shows. TEXT <ENABLE/ DISABLE SCROLLING TEXT> Use the up and down keys to select ON or OFF. 1.6.6 Customer Calibration The 3216 Controller series are calibrated for life at manufacture, there may however be sensor or other system errors, which affect the accuracy of the measured temperature. -
Page 9: Holdback
1.6.7 Holdback If the temperature ramp rate of the program is quicker than the product can achieve, the program will wait until the temperature of the product catches up. e.g. If a holdback value of 10 is set and the program is set to ramp to a setpoint of 600 °C, the program will reach 600 °C, then go into a hold state;... -
Page 10: Programming
Programming 1.7.1 Creating a Program Programs can be created in level 1 or level 2 of the 3216P1 and 3216P5. Each program contains 8 Ramp/ Dwell pairs. Note: A currently active program cannot be altered. Go into 'Reset' mode before starting to create or modify a program 1.7.2 Program Number (3216P5 Only) -
Page 11: Running A Program
If not all the segments are used for a program, the Ramp & Dwell of each of the subsequent segments should be set to OFF. A program will end in one of two ways, either revert to the control setpoint or dwell at the temperature set in the last segment used. - Page 12 Working Output Power From the home display, press scroll until the display shows WRK.OP <WORKING OUTPUT POWER>. This shows the power being used as a percentage. Time Remaining Press scroll until the display shows T.REMN <TIME REMAINING>. This shows the dwell time remaining for the current segment.
- Page 13 Program Example The following sequence of entries creates and runs the program shown graphically below. 1. Press scroll until the display shows RAMP.U <SP RAMP UNITS>. Select MIN. 2. Press scroll until the display shows DWELL.U <DWELL UNITS>. Select MIN. 3.
-
Page 14: Controller Options
RMP.1= 5°C/Min RMP.1= 4°C/Min RMP.1= OFF RMP.1= 3°C/Min RMP.1=5°C T.SP1= 600°C T.SP1= 400°C T.SP1= 600°C T.SP1= 800°C T.SP1= 400°C Dwel.1= 30 Min Dwel.1= 30 Min Dwel.1= 60 Min Dwel.1= OFF Dwel.1= 480 Min Controller Options As options can be ordered in a variety of combinations and for a variety of purposes, exact instructions are not given here. - Page 15 address value, access the level 2 list. In level 2 press the page key until the COMMS parameter is displayed. Press up down to select the address value. 1.8.4 Alarm Option When an alarm board is fitted, which consists of a relay with voltage free contacts, for operator use, the contacts are taken to a panel plug on the control panel, wired as indicated: Temperature Controller...
- Page 16 Hold the Page key for 3 Level 1 Press the Scroll Key seconds Press the Scroll Key mul- Locked - password Level 2 tiple times required Access If configured Unlocked Black = Progress Do not raise the power limit (if Dashed = Through mul- accessible) above the design level Multiple Program Only...
- Page 17 Notes Service Record Engineer Name Date Record of Work...
- Page 18 The products covered in this manual are only a small part of the wide range of ovens, chamber furnaces and tube furnaces manufactured by Carbolite Gero for laboratory and industrial use. For further details of our standard or custom built products please contact us at the address below, or ask your nearest stockist.
