- Page 1 User Manual KNX Power Supply, 640mA_V1.2 BBPS-02/640.1 KNX/EIB Home and Building Control System...
- Page 2 Attentions 1. Please keep devices away from strong magnetic field, high temperature, wet environment; 2. Do not fall the device to the ground or make them get hard impact; 3. Do not use wet cloth or volatile reagent to wipe the device; 4.
-
Page 3: Table Of Contents
Contents Chapter 1 Introduction ------------------------------------------------------------------------------------------------- 1 Chapter 2 Technical Parameter ---------------------------------------------------------------------------------------2 Chapter 3 Dimension and Connection Diagram --------------------------------------------------------------------- 4 3.1. Dimension drawing ------------------------------------------------------------------------------------------- 4 3.2. Connection Diagram ------------------------------------------------------------------------------------------5 Chapter 4 Normal Working Test -------------------------------------------------------------------------------------- 6... - Page 4 Important safeguards 1) Before use, please read this instruction carefully and use the power supply strictly according to the instruction. 2) This power supply is for indoor use only and shall be installed in distribution box which can provide the protection mechanism for avoid electric shock. 3) Please keep this equipment from humidity.
-
Page 5: Chapter 1 Introduction
KNX/EIB KNX Power Supply, 640mAPower Supply Chapter 1 Introduction KNX power supply produces and monitors KNX system voltage. There are two connection terminal of the output, one for KNX bus supply and signal transmission, one for auxiliary power supply, can provide 30V DC voltage with terminal device.The bus connection terminal has integrated the reactor inside the power supply;... -
Page 6: Chapter 2 Technical Parameter
KNX/EIB KNX Power Supply, 640mAPower Supply Chapter 2 Technical Parameter Power supply Input voltage 100-240V AC, 50-60Hz Efficiency ≥80% Output KNX output 1 fold with integrated choke KNX nominal voltage 30+1V/-2V DC, SELV Auxiliary voltage output 1 fold without integrated choke Auxiliary voltage 30±1V DC, SELV KNX nominal current... - Page 7 KNX/EIB KNX Power Supply, 640mAPower Supply Temperature Operation 5 °C ... + 45 °C Storage 25 °C ... + 55 °C Transport 25 °C ... + 70 °C Environment Humidity <93%, except dewing Mounting On 35mm mounting rail 90×72×64mm Dimension Weight 0.3kg Plastic, Beige...
-
Page 8: Chapter 3 Dimension And Connection Diagram
KNX/EIB KNX Power Supply, 640mAPower Supply Chapter 3 Dimension and Connection Diagram 3.1.Dimension drawing... -
Page 9: Connection Diagram
KNX/EIB KNX Power Supply, 640mAPower Supply 3.2.Connection Diagram ①Reset push button ②Reset indicator LED ③KNX Bus connection terminal ④Auxiliary voltage connection terminal ⑤Main supply ⑥Current level indicator ⑦Output voltage normally indicator ⑧Overload/short circuit indicator Switch mode power supply unit Non-inherently short-ciruit-proof-safety isolating transformer... -
Page 10: Chapter 4 Normal Working Test
KNX/EIB KNX Power Supply, 640mAPower Supply Chapter 4 Normal Working Test has been correctly installed, When power supply switch on the main power supply for the bus the green LED “ON”, the circuit level indicator LEDs up according to the range of loads, power, and and the other LEDs are switched off, that is, the device function correctly.
