Summary of Contents for ASTEL MARINE EQUATOR MSR0640
- Page 1 EQUATOR MSR0640 UNDERWATER LIGHT Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Preface ............................... 3 Features ............................. 3 Precautions ............................3 Controls and Connectors ........................4 Installation ............................5 Controls .............................. 7 Appearance ............................9 Technical Specifications ........................9 Warranty ............................10 Declaration of Conformity ......................... 11 _________________________________________________________________________________... -
Page 3: Preface
PREFACE PRECAUTIONS The EQUATOR MSR0640 series of a compact • The underwater light has to be installed and ultra-thin underwater light with built-in driver is used in accordance with the instructions of designed to use the latest LED lighting this manual only. -
Page 4: Controls And Connectors
CONTROLS AND CONNECTORS (1) Optical window High-grade polycarbonate glass optical window. (2) Underwater light casing Aluminium bronze casing with fixing holes and cable gland. (3) Cable The 4-pole multi-core cable to connect the 12-24Vdc power supply and optional remote control or switch. -
Page 5: Installation
• 4 x fixing screw M6x80 with nut M6 and washer • Operating Instructions with Declaration of Conformity and Warranty conditions The EQUATOR MSR0640 has to be installed on a flat surface on the stern or both sides of the hull of the vessel. - Page 6 (not included). The power supply voltage has to be from 10 - 30Vdc. Note: • The main DC power supply of the vessel has to be switched off before installation. The underwater light has to be connected as described in the table below: EQUATOR MSR0640 FUNCTION wire colour + DC Power Supply...
-
Page 7: Controls
The multi-color underwater light can be controlled by using the momentary-switch. When the light is turned-off the color or mode of lighting can be changed sequentially by pressing the momentary switch for 2 seconds: EQUATOR MSR0640 Sequence of lighting Custom Color... - Page 8 Set default Press the momentary switch for min. 40 seconds or until the light is turned off. Synchronization When more than one multi-color underwater light is connected to the system the optional Synchronization Unit MSU08 is recommended to synchronize the colors of lighting at the Rainbow Color Spectrum mode of lighting.
-
Page 9: Appearance
APPEARANCE TECHNICAL SPECIFICATIONS Power supply 12 – 24 Vdc, max. 680 mA/12 Vdc or 380 mA/24 Vdc Lens angle 60° Optical window High-grade polycarbonate glass Luminous flux 950 lm White color temperature 6.000 - 10.000 K ASTEL protocol default address Operating temperature -10°C - +50°C Casing... -
Page 10: Warranty
WARRANTY 1. The equipment manufactured by ASTEL d.o.o. is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 11: Declaration Of Conformity
Manufacturer's Address: Dutovlje 138 6221 Dutovlje Slovenija declares that the products Item, Product Name and Model Number: 1. Underwater Light EQUATOR MSR0640 conform to the following Product Specifications: EMC: EN 55015:2006 + A1:2007 EN 61547:1995 + A1:2000 + A2:2009 EN 61547:2009... - Page 12 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 info@astel-marine.com E-mail: www.astel-marine.com Web:...
