Wayne-Dalton 3995 Installation Instructions

P.O. Box 67 Mt. Hope, OH 44660
1-800-676-7734
IMPORTANT NOTICE!
Read these instructions carefully before installing the
antenna extension kit. Pay close attention to all warnings
and notes. This manual should be retained for future
reference.
Package Contents:
1.12' Antenna Cable
2. Connector
3. Antenna Bracket with Rubber Grommets
4. Manual
4.
© Copyright 2005 Wayne-Dalton Corp.
Antenna Extension Kit
Installation Instructions for Model 3995
for use with Wayne-Dalton
1
sure electrical power is
disconnected before
proceeding with
installation.
a. Remove antenna, if installed,
from external receiver and
retain for installation in step 4.
b. Connect antenna cable to
jack on external receiver.
2
If receiver is installed in a
garage with metal siding, stucco
over metal lath, or thermal
reflective Tyvek, route the
antenna cable through the wall
to the exterior of the garage.
Ensure antenna cable is
secured and routed away from
3.
any moving parts.
3
Locate a suitable flat mounting
surface on outside of building
to mount the antenna bracket
vertically.
Use screws (not included) or
other fastening means to attach
the antenna bracket to the
2.
mounting surface.
NOTE: When mounting to metal
buildings, make sure rubber
grommets are in place and the
antenna bracket does not touch
the metal mounting surface.
This will ensure electrical (RF)
isolation and maximum signal
transmission range.
4
1.
Thread connector onto antenna
and thread antenna cable onto
connector as shown.
Mount antenna straight. For
best reception, keep antenna
(not included) away from metal.
323126
®
Radio Receivers
WARNING: To prevent
electrical shock, be
Receiver
Mounting
Surface
Rubber
Grommets
Mounting
Surface
Antenna
Bracket
Receiver
Antenna Cable
Metal Enclosure
Antenna
Bracket
Screws
(Not Included)
Antenna
(Not Included)
Nut from
Conntector
Connector
Antenna
Cable
New 5/17/2005
