M300WS Installation Guide
Ceiling Mounted and Desktop
Diagrams and Distance Charts
The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of
installation.
Distances are in inches. For millimeters multiply by 25.4.
Ceiling Mounted
Distance Chart for popular 16:10 screens
Image Size (16:10)
(16:10) screen
Diagonal
Width(W)
inches
inches
57
48
60
51
70
59
79
67
91
77
100
85
104
88
Note:
For screen sizes not indicated on the projection
table, use the formulas on page 1.
www.necdisplay.com
on a
B
Height (H)
inches
inches
30
18
32
19
37
22
42
25
48
29
53
32
55
33
NEC Display Solutions of America, Inc.
Desktop
C
inches
23
25
28
32
37
41
42
M300W S
Rev 1.2
α
D
inches
degrees
3
38.0
3
38.0
4
38.0
4
38.0
5
38.0
5
38.0
6
38.0
Page 2 of 6
