Solarever Tecnologia de America S.A.de C.V.
Autopista Mexico-Queretaro KM 71.9, S/N Noxtongo Tepeji del
Rio de Ocampo C.P. 42885, Hidalgo Mexico
Tel.: +55 4364 0437
E-mail: contacto@solarever.com.mx
SE-BAT Lithium-ion Battery
Copyright Declaration
The copyright of this manual belongs to Solarever Tecnologia de America S.A.de C.V. Any
corporation or individual should not plagiarize, partially or fully copy it (including software, etc.),
614.00748.00
and reproduction or distribution in any form or by any means shall not be allowed. All rights
reserved. Solarever Tecnologia de America S.A.de C.V. reserves the right of nal interpretation. The
information contained herein is subject to change without notice.
50Ah
User Manual
UL
www.solarever.com.mx
Advertisement
Table of Contents
Troubleshooting
Summary of Contents for SOLAREVER SE-BAT SYS-HV
- Page 1 Copyright Declaration Rio de Ocampo C.P. 42885, Hidalgo Mexico The copyright of this manual belongs to Solarever Tecnologia de America S.A.de C.V. Any Tel.: +55 4364 0437 corporation or individual should not plagiarize, partially or fully copy it (including software, etc.), E-mail: contacto@solarever.com.mx...
-
Page 2: Table Of Contents
3.1 PRODUCT OVERVIEW............................7 3.1.1 DIMENSION AND WEIGHT........................7 3.1.2 APPEARANCE..............................8 3.2 BASIC FEATURES..............................10 3.2.1 FEATURES..............................10 3.2.2 CERTIFICATIONS............................10 3.3 SPECIFICATIONS..............................11 3.3.1 SE-BAT SYS-HV CONFIGURATION LIST..................11 3.3.2 PERFORMANCE............................11 4 INSTALLATION..................................12 4.1 INSTALLATION PREREQUISITES......................12 4.2 SAFETY GEAR...............................12 4.3 TOOLS..................................13 4.4 INSTALLATION..............................13 4.4.1 CHECK FOR TRANSPORT DAMAGE..................13 4.4.2 UNPACKING..............................13... -
Page 3: Note On This Manual
5.3 STATUS INDICATORS...............................35 NOTE: There are 4 models for SE-BAT system, which includes BMS and battery 5.3.1 BMS ....................................35 pack(s). Please refer to section 3.3.1 SE-BAT SYS-HV Con guration List on page 11 for detailed models. 5.3.2 BATTERY PACK..............................36 5.4 SHUTTING DOWN SE-BAT SYSTEM......................36 Target Group 6 TROUBLESHOOTING................................37... -
Page 4: Safety
–Do not place any objects on top of the battery pack. SE-BAT SYS-HV can be used only in the household energy eld . It is not allowed to be used in other industries, such as the medical equipment and automotive... -
Page 5: Response To Emergency Situations
If the battery pack seems to be damaged, they are not t or use and may pose a danger to people or property. Danger of high voltages. Please pack the battery in its original container, and then return it to Solarever or Danger to life due to high voltages in the battery system! your distributor. -
Page 6: Product Introduction
For safety reasons, installers are responsible for familiarizing themselves with the contents of this manual and all warnings before performing installation. All operations of SE-BAT SYS-HV relating to electrical connection and installation must be carried out by quali ed personne. -
Page 7: Appearance
3. Product Introduction 3. Product Introduction Section view of SE-BAT-SL H 5.8 Ÿ 3.1.2 Appearance Section view of SE-BAT-MA H 5.8 Ÿ Ⅴ Ⅵ Ⅵ ’ Ⅶ Ⅰ Ⅱ ’ Ⅰ XPLUG YPLUG BAT- BAT+ YPLUG Ⅴ ’ Ⅳ RS485 I RS485 II Ⅲ... -
Page 8: Basic Features
Speci cations 3.2.1 Features 3.3.1 SE-BAT SYS-HV Con guration List The SE-BAT SYS-HV is one of the advanced energy storage systems on the market Model Battery Pack Energy(kWh) Voltage (V) today, incorporating state-of-the-art technology, high reliability, and convenient SE-BAT-MA H 5.8*1 control features shown as below: SE-BAT H 5.8... -
Page 9: Installation
WARNING! Please strictly follow the installation steps. Solarever will not answer for any hurting or loss arising by incorrectly assembling and operation. Insulated gloves Safety goggles... -
Page 10: Accessories
RS485cable*1 4. Installation 4. Installation 4.4.3 Accessories SE-BAT-SL H 5.8: SE-BAT-MA H 5.8: A(Red cable) B(Black cable) D(Black cable) The table below lists the number of each component. The table below lists the number of each component. Object Description Quantity Power line between Inverter and SE-BAT-MA H 5.8 (+) ( 6.56 ft/2.00 m) Object... -
Page 11: Battery Installation Steps
4. Installation 4. Installation 4.4.4 Battery Installation Steps It is recommended that the space between battery packs is more than 300mm. Steps (for SE-BAT-MA H 5.8 or SE-BAT-SL H 5.8): Make sure the wall is strong enough to withstand the weight of battery packs. Step 1: x the wall brac et (H or G1) on the wall Use the wall bracket as a template to mark the position of the 5 holes Ÿ... -
Page 12: Overall Installation
Overall Installation For SE-BAT-MA H 5.8 + 1~3 battery packs: It is recommended to protect the cables by using corrugated pipe. 1. Connect the cables at one end of the SE-BAT-MA H 5.8/SE-BAT-SL H 5.8. For SE-BAT-MA H 5.8: 2. Get the cables through theconduit. (conduit size: 1-1/2 in/12.7~25.4 mm) 1. -
Page 13: Cable Connection
4. Installation 4. Installation For 2~3 battery modules: 4.5.1 Cable Connection The power cable between battery modules (A1) is different from the one that between BMS and battery module (C). The other end of the power cable is black, Please refer to section 4.5 for the installation of conduit and cover plate, and and this color is connected to YPLG (Ⅴ’), which is on the right side of the battery then make connection. -
Page 14: Connecting Power Cables
4. Installation 4. Installation For SE-BAT-MA H 5.8 + 1~3 battery packs: 4.5.2 Connecting Power Cables Ⅵ 1. Connect “-” (Ⅴfor SE-BAT-MA H 5.8 or ’ for SE-BAT-SL H 5.8) on the right side For SE-BAT-MA H 5.8: to “+” (Ⅱ... -
Page 15: Connecting Power Lines
4. Installation 4. Installation 4.5.3 Connecting Power Lines 3. Pass the other end of the charging cable through the inverter's pipe.Insert the trip head of each wire into the hole. This step is going to connect power lines between Inverter and SE-BAT system. The default length of power lines are 6.56 feet/ 2 meters, so customers can... - Page 16 4. Installation 4. Installation Ø Disassembling Power Line (on BAT+, BAT-, “+”, XPLUG port) Ø Disassembling Power Cable (on ”-”, YPLUG port) Disassemble the power line by plugging the slot type screwdriver to the terminal Disassemble the power line by plugging the Power cable disassembling tool(L) groove of charging cable.
-
Page 17: Connecting Can Communication Cable
4. Installation 4. Installation 4.5.4 Connecting CAN Communication Cable 4.5.5 Connecting RS485 Communication Cable It is required for the BMS to communicate with the inverter for proper operation. For SE-BAT-MA H 5.8: There's no need to use RS485 communicaton cable. 1. -
Page 18: Connecting Ground Wire
4. Installation 4. Installation 4.5.6 Connecting Ground Wire Overview of Installation The following diagram is a complete SE-BAT system installation with The terminal point for GND connection is on the side of grooves as shown SE-BAT-MA H 5.8 + three battery packs. below (torque: 1.5 N·m): Cable size: 10AWG. -
Page 19: Commissioning
5. Commissioning 5. Commissioning Commissioning Commissioning Con guing Battery System The DIP switch is used to con gue the number of battery packs which are communicating to Inverter. The detailed con guration inormation is shown as follows: NOTE! When powering on the BMS, the system will start self-testing. If the buzzer bips, it means DIP con guration fault or communication failue occurs. -
Page 20: Status Indicators
5. Commissioning 5. Commissioning Commissioning Steps Status Indicators The LED indicators on the front panel of the battery pack are showing the If all the battery packs are installed, follow these steps to put it in operation. operating status. 1. Remove the upper cover board of SE-BAT-MA H 5.8; 2. -
Page 21: Battery Pack
After powering off the BMS, the LED lights of S1 and S2 will keep is interrupted correctly and well ashing in 20 minutes. connected. Please contact Solarever after- BMS_OverVoltage Battery over voltage sales service or your distributor directly. Shutting Down SE-BAT System... -
Page 22: 6. Troubleshooting
(XPLUG) of the BMS; BMS_Relay_Fault Battery relay fault 2. If the rst step still does not work, please contact Solarever after- sales service or your distributor directly. BMS_SelfChk_Fault BMS selfcheck Please contact Solarever after-sales fault service or your distributor directly. -
Page 23: Decommissioning
Please pack the BMS and battery packs with the original packaging. Solarever protects this product under warranty when it is installed and used as If it is no longer available, you can also use an equivalent carton that meets the listed in this manual.
