- Page 1 S A F E T Y S L A T T E D A U T O M A T I C C O V E R Roll Easy INSTALLATION NOTICE Installation / Use / Maintenance / Safety Advice www.delbrece.com.ua S W I M M I N G P O O L D E V E L O P M E N T A N D I N N O VAT I O N...
-
Page 2: Parts Included In The Delivery
THIS NOTICE MUST BE GIVEN TO THE POOL OWNER PLEASE READ CAREFULLY AND KEEP IN A SAFE PLACE PARTS INCLUDED IN THE DELIVERY Roll-Easy (2 boxes - Supports + Tube) Motor Free side Anodised aluminium tube Ø130 mm 4 mm thick Electric control panel support support... - Page 3 NECESSARY TOOLS - (INSTALLATION - 2 PERSONS) n°13 n°17 Ø8 - 12 - 20 INFORMATION For pools up to 5 x 11 m + Ø3 m step unit The motor is located in the tube and must be installed on the support equipped with the key switch. The electrical supply comes 35,2 from the electric control...
-
Page 4: Tube Mounting
TUBE MOUNTING Take the door of the motor side support off Tube Motor side Automatic stops are located upwards MOTOR INSTALLATION Insert the motor and move it around until it fits inside the motor bearing Screw TFHC M5x20 Allen key n°4 Tube adjustment 5 mm 5 mm... -
Page 5: Tube Installation
TUBE INSTALLATION Locate the motor side support as per your order A = B Motor side Middle of the pool Adjust according to the pool corners and safety locking kits. With strap locking kits, Lock-it and Push-lock With Quick-lock Min A = 15 cm Max A = 60 cm 60 cm corners... -
Page 6: Electrical Drawing
ELECTRICAL DRAWING Key switch Torque limiter device Plug Electric control panel 2 x 4 mm² - Up to 16 m long. Electrical supply 230 V 2 x 6 mm² - From 16 to 25 m long. 2 x 10 mm² - From 25 to 50 m long. The electric control panel must be installed in a dry plant room. -
Page 7: Cover Installation
COVER INSTALLATION Install the slats on the water and clip them together. Take care with the direction of Allen key the cover over the pool. n°4 Cut out female male Fit the slats along the whole length. “CLAC” 35 cm Repeat wiggling/handling of the slats may be needed. - Page 8 ELECTRIC CONTROL CHECKING Cover opening If the electric control is installed incorrectly, reverse cables 1 and 2 outside the motor (See page 6). Cover closing maintained contact AUTOMATIC STOP ADJUSTMENT Red arrows indicate the direction of the cover. Turn the key in the direction to increase the movement in the direction of the arrow.
- Page 9 CARD ADJUSTMENT (SWITCH REGLAGE) Roll-Easy 1 2 3 4 CONTROL TIME ADJUSTMENT (SWITCH REGLAGE) = pool length step unit included L > 12 m L <= 12 m 1 2 3 4 1 2 3 4 60 seconds 30 seconds ADJUSTEMENT OF THE SENSITIVITY (SWITCH PROG) = pool width <= 10 m...
- Page 10 OPTIONAL SAFETY LOCKING KITS Push-lock Insert mounted Surface mounted Hanging mounted Quick-lock Insert mounted Surface mounted Hanging mounted Lock-it Surface mounted Hanging mounted Insert mounted Strap locking Hanging mounted Insert mounted Surface mounted LOCKING KIT POSITIONING With side step With straight Without step With Roman unit...
- Page 11 PUSH-LOCK INSTALLATION A water top level is mandatory Insert mounted model For concrete pools Wall unit Washer Ø16 5 cm Screw VBA TF Z pozi inox A4 Ø6 x 60 Acceptable limit of level variation 5 cm recommended water level 5 cm Screw cap Hanging mounted model...
- Page 12 QUICK-LOCK INSTALLATION A water top level is mandatory. Insert mounted version For concrete pools Wall unit Washer Ø16 Screw VBA TF Z pozi 5 cm inox A4 Ø6 x 60 Adjustment Acceptable limit of level variation 5 cm recommended water level 5 cm Hanging mounted model Screw...
- Page 13 LOCK-IT INSTALLATION A water top level is mandatory. Insert mounted model For concrete pools Wall unit 5 cm Washer Ø16 Screw VBA TF Z pozi inox A4 Ø6 x 60 8 cm Acceptable limit of level variation 5 cm recommended water level 5 cm Hanging mounted model...
-
Page 14: Strap Installation
STRAP INSTALLATION A water top level is mandatory. Insert mounted model Wall unit For concrete pools 5 cm Washer Ø16 Screw VBA TF Z pozi inox A4 Ø6 x 60 Acceptable limit of level variation 5 cm recommended water level 5 cm Hanging mounted model Screw... - Page 15 INSTALLATION OF THE STRAP ANCHOR Anchor for concrete deck The anchor head must be higher than the pool deck surface between 25 Ø20 and 40 cm Depth: 5 cm Do not force the anchor in a hole where the diameter is smaller. Anchor for wood deck Middle of the bracket Screw Ø4 x 25...
- Page 16 - Make sure there is no bather or foreign bodies in the pool before and during the closing action. - When using an automatic cleaner under the cover, check that the hose does not affect the movement of the slats when opening and closing the cover. - It is essential to remove floating objects when opening and closing the cover.
- Page 17 Locking check the system is with tool locked Releasing with tool The cover must not exit the Quick Lock before you activate the key switch. Locking Releasing www.delbrece.com.ua...
- Page 18 Locking Install the strap between the wall The strap must and the bracket be under tension and must be through the bracket Lock the anchor Releasing Remove the strap from around the bracket and put it on the cover Release the anchor 1 - In the event of an explained stoppage during opening : (unreleased locking kits or other...) - Closed the cover for more than 3 seconds, until the tension of the cover is completely released.
- Page 19 - The water level has to be maintained at the correct level to avoid damage and repeated activa- tion of the torque limiter device .(For more comfort, use a water level regulator). - If the water level is too high, it might come from leaves in the skimmer. - If the water level is too low, it might cause malfunction of the cover.
- Page 20 AT LEAST ONE ADULT MUST SUPERVISE THE POOL WHEN IT IS OPEN WIMMING POOL BUILDER ZA La basse croix rouge 35530 Brécé FRANCE - tel : +33 2 99 00 25 62 - fax : +33 2 99 04 28 70 - E-mail : del.export@delbrece.fr www.delbrece.com.ua...
