Summary of Contents for Fiil CC nano
- Page 1 CC nano TRUE WIRELESS EARBUDS USER MANUAL...
-
Page 2: Important Safety Instructions
・ Keep this product dry and at room temperature, avoid long time exposure to high temperature or humidity environments; ・ Use accessories only provided by FIIL; ・ Excessive signal level may cause damaging overload; ・ Clean the product only with dry and soft cloth. - Page 3 ・ Please note that FIIL will accept no responsibility for any loss incurred by misuse. ・ FIIL CC nano is designed & made by Jiangxi Feier Technology Co., Ltd. • ‘ FIIL’ is a registered trademark® of Jiangxi Feier Technology Co., Ltd.
-
Page 4: What's In The Box
What's in the box Earbuds X2 Charging Case X1 (L/R) CC nano TRUE WIRELESS EARBUDS USER MANUAL USB- C Cable X1 User Manual X1... - Page 5 Main User Interfaces Earbud LED Indicator Charging Port ENC Microphone Call Microphone Touch Control Charging Case Charging Case Charging Indicator Left Earbud Earbud Charging Indicator Right Earbud USB-C Port...
- Page 6 Wear and Usage Get Started ease follow below steps t o a ctivate and start to use. Remove all protection films prior to using. It is recommended to charge the earbuds for at least 10 minutes with USB-C cable. How to Wear Call Microphone Toward mouth Slightly rotate earbuds after put in ears to make it stable, and pay...
-
Page 7: Bluetooth Connection
Bluetooth Connection Step 1: Bluetooth Pairing 1. For the first usage of brand new FIIL CC nano, please take the earbuds out of the charging case and the earbuds will automatically enter the Bluetooth pairing mode. 2. To connect with another mobile device, you can disconnect the earbuds from your current device, and the earbuds will automatically enter the Bluetooth pairing mode. - Page 8 Bluetooth Multipoint Step1: Activate multi-point function 1. Please connect with FIIL CC nano, download and install fiil+ App on mobile device. 2. From the fiil+ App, turn on "Bluetooth free connection" and switch to "Multi-point mode". Step 2: Connect the second device 1.
-
Page 9: Touch Control
Touch Control Power On Take earbuds out of charging case, they will automatically power on and reconnect cell phone, or you can press and hold earbuds for 2 se conds to turn it on manually , you will hear opening music and see the earbuds indicator light on in colour blue. - Page 10 Touch Control Reject Call When incoming call, please press and hold 2 seconds to reject a call. Hold for 2 sec Either earbud Play/Pause Tap twice to play or pause music . Double tap Either earbud Voice Assistant Hold for 2 seconds to activate voice assistant, like Siri etc. Hold for 2 sec Either earbud...
-
Page 11: Volume Up/Volume Down
Touch Control Volume Up/Volume Down Tap left earbud once to Vol+, tap 3 times to Vol-. Tap once / Vol+ Tap 3 times / Vol- Left earbud Note: Please enable full control mode from fiil+ App. Next /Prev.Track Tap right earbud once to play next, tap 3 times to play Pre. track. Tap once/Next Tap 3 times/Prev. -
Page 12: Charging Indicator
If the left and right earbuds can not recognize each other, please put them back in the charging case and wait more than 5 seconds, or you can consult FIIL customer service to learn how to manually reset the earbuds. -
Page 13: Product Parameters
Product Parameters Item Earbud weight ~4g/each Charging case weight ~31g User Mode Bluetooth True Wireless V5.2, supported protocols: HSP, HFP, A2DP, AVRCP Bluetooth BT range: up to 10 meters. Pairing code: 0000. iOS and Android devices are supported. Supported Code: AAC （for iOS） /SBC; Audio Frequency range: 15Hz-22kHz Rechargeable lithium-polymer battery;... -
Page 14: Warranty And Service
Please help us to contact the online or offline channel/store where you purchased from for support of after-sale service. You can also get support through FIIL's social media (FIIL Audio) including Facebook, Twitter, Instagram. Email: customer@fiil.com... -
Page 15: Troubleshooting
On your Bluetooth device: won’ t pair Turn the Bluetooth feature on and then off. ・ with Bluetooth Delete your FIIL CC nano earbuds from the ・ Bluetooth list on your device, pairing again. device Move your Bluetooth device closer to the ・... - Page 16 Problem Poor sound quality ・ ・ Disconnect the second device. ・ Move the Bluetooth device closer to the ・ earbuds, and away from any interference or obstructions. Clear any debris or wax build-up from the ・ earbuds and earbuds nozzles. Earbuds won’...
- Page 17 Please make sure to include these safety ease follow below steps t o a ctivate and start to use. 1. For the first usage of brand new FIIL CC nano, please take the earbuds 1. Please connect with FIIL CC nano, download and install fiil+ App instructions with the product when delivered to a third party.
