Technical Guide – KIRK Wireless Server 500 1G9
How to Register a MASTER Handset:
When turning on the KIRK Wireless Server 500 1G9, it will automatically go into regi-
stration mode for a period of 15 min. In this period you can register the MASTER
handset (it's only possible to login 1 MASTER on each system. The first handset is
automatically the MASTER handset).
It is now possible to register the first handset (it will automatically be configured to
channel 00).
1. Press the menu key.
Press the < key twice
2.
The menu will now show "LOGIN "
3.
Press the
4.
Press the > key once – then press
5.
show: Subscription search ID:
The handset will start searching for "your" KIRK Wireless Server 500. When the
handset finds a system, a number will appear in the display.
The handset might detect more than one number (This only happens if the handset
detects another system nearby. It does not mean that your- or the other system
communicates! There are no safety problems attached to this indication)
If the handset detects more than one system, a black triangle will appear in the bott-
om of the display, indicating that you can press the < key or the > key.
It is now possible to scroll between the numbers in the display by pressing the < or
the > key.
It is important that the number shown in the display is identical to the number which
you find on your KIRK Wireless Server 500. The number is indicated as an ARI (indi-
cated on the label on the back of the base station).
When you are certain to have indicated the correct number, press the
handset will be configured as the MASTER handset of the system.
Now you have to allocate an extension number to the handset:
key – the menu will show "Select login "
- the menu will now
key and the
Advertisement
Table of Contents
Related Manuals for Kirk Wireless Server 500 1G9
Summary of Contents for Kirk Wireless Server 500 1G9
- Page 1 Technical Guide – KIRK Wireless Server 500 1G9 How to Register a MASTER Handset: When turning on the KIRK Wireless Server 500 1G9, it will automatically go into regi- stration mode for a period of 15 min. In this period you can register the MASTER handset (it’s only possible to login 1 MASTER on each system.
- Page 2 You can now enter the Serial Number of the new handset (found inside the handset ) 1. Press the ”menu” key. Press the > key once. The menu must now show ”EXT. Service” Press the key. The menu will now show ” Clip Stack ” Press the <...
- Page 3 Repeater deployment note on the CD-ROM for further information on different types of Repeaters). In general terms, KIRK Wireless Server 500 1G9 contains 6 available speech chan- nels in the coverage area of the base station. There are 2 simultaneous speech channels in the coverage area of each Repeater.
- Page 4 When 6 handsets are ” in the air ” the system sends out a busy signal. On KIRK handsets this is indicated by a flashing antenna icon in the lower left corner of the display. How to Register a Repeater to the System:...
- Page 5 Safety Instructions Important Safety Instructions and Product Information Before using your telephone equipment, you should always follow basic safety instru- ction to reduce the risk of fire, electrical shock and injury to persons, and damage to property. Read and understand all instructions Follow all warnings and instructions including those marked on the product Unplug this product before cleaning.
- Page 6 15 This telephone will not operate in the event of a blackout. Please keep a backup phone for emergencies Intrinsic safety Do not use the handset in conditions where there is a danger of electrically ignited explosions. Exposure to sunlight, heat and moisture Do not expose the cordless phone to direct sunlight for long periods.
- Page 7 Your telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the proper functioning of your telephone system, If they do and it is possible, you will be notified in advance to give you an opportunity to maintain uninterrupted telephone service.
- Page 8 days or (b) the remainder of the original one (1) year warranty period, whichever is longer. This warranty does not apply to the defects outside of our control, including but not limited to acts of God, fire, flood and damage while in transit to service facility. We do not warranty that the product will be compatible with any telephone equipment, systems or party lines.
