1 、VRX Glass Accessory List
Countersunk
Glass clamp
head screw
glass
clamp
1.Use countersunk head
screws to lock glass clamp on
the VRX show case body .
Knurled screw
4.Assemble the foot frame on the inside of
glass panel and fix it with knurled screws.
VRX Glass Assemble Instruction
Silicone
protective cover
glass locking set
screw
glass
Countersunk
head screw
2.Place the two side glass and back glass
into the glass clamps separately.
foot frame
Knurled
foot
screw
frame
glass clamp
0
Glass
locking
set screw
Silicone
Glass hole
protective cover
3.Insert the Silicone
protective cover into
the glass hole.
5.Secure the top glass with knurled
screws fixed on the installed foot
frame.
