ASSEMBLY INSTRUCTIONS
PowerTek Inc. - Vertical LOG SPLITTERS
OWNER/OPERATOR'S INFORMATION FOR POWERTEK
IT IS THE OPERATORS RESPONSIBILITY TO:
1. Carefully read and understand the entire Operation & Maintenance Manual along with the
Assembly Instructions.
Be certain that all assembly procedures are followed as described in the following Assembly
2.
Instructions.
3. Fill equipment with the proper fluids before starting as described in the Operation &
Maintenance Manual and the engine manufacturer's manual.
Operate the log splitter according to the safe operating procedures as spelled out in the
4.
Operation & Maintenance Manual and these Assembly Instructions.
Perform all required maintenance as directed in the Operation & Maintenance Manual, the
5.
engine manufacturer's manual, and these Assembly Instructions.
UNPACKING LOOSE PARTS:
Using care, remove the cover and sides from the pallet. The log splitter assemblies and parts
are secured with bands. Carefully cut the bands. Remove all parts from the skid and layout in a
clear unobstructed working area. Use the parts list below to assure all parts are accounted for. Do
not discard packing material until assembly is complete to insure that no required parts are
accidentally discarded
Tools required: Adjustable wrench and socket set.
ASSEMBLY:
This unit must be assembled before use. Care must be taken in assembly to insure the proper
Functioning and reliability of the unit. Assembly must be done in a dry and clean area.
1. Attach Hitch Tongue Assembly (51604), to Motor Axle Plate Assembly (51614), with (4)
3/8-16 x 3-1/2 Hex Head Bolts, 3/8-16 Hex lock Nut, and 3/8 Flat Washer. Tighten.
2. Lift frame and attach wheel assemblies. Move from crate.
3. Lift cylinder end of beam to vertical position and back platform unit to beam. Slide pin thru
then lower beam to horizontal position.
5. Attach (2) color coded hoses to top of valve. Attach reservoir hose (1 ½") to pump and
tighten clamps.
6. Fill Hydraulic Reservoir with Dextron III Automatic Transmission Fluid. (Approximately 3
gal.)
7. Fill engine with proper amount and type of motor oil. See Operation & Maintenance Manual
for further details.
8. Start engine and cycle Ram to full extent & return to fill cylinder. Refill Hyd. Reservoir.
Shipped Partially Assembled
LOG SPLITTER RESPONSIBILITY
.
2
POWERTEK
