Titan Attachments 70SPREAD Operator's Manual

70lb walk-behind spreader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
70 LB WALK-BEHIND SPREADER
70SPREAD
191361
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70SPREAD and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Attachments 70SPREAD

  • Page 1 70 LB WALK-BEHIND SPREADER 70SPREAD 191361 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!

  • Page 2: General Warnings

    GENERAL WARNINGS READ and UNDERSTAND this manual completely before using Push Spreader. Operators must read and understand all safety and warning information, operating instructions, maintenance, and storage instructions before operating this equipment. Failure to properly operate and maintain the push spreader could result in serious injury to the operator or bystanders.
  • Page 3 ASSEMBLY IS REQUIRED This product requires assembly before use. See “Assembly” section for instructions. Because of the weight and/or size of the push spreader, it is recommended that another adult be present to assist with the assembly. INSPECT ALL COMPONENTS closely upon receipt to make sure no components are missing or damaged.
  • Page 4 ABOUT YOUR PUSH SPREADER This push spreader is designed to spread a wide range of materials (Fertilizer, Grass Seed, and Ice melt). Materials such as Powders, Manure, Topsoil, Gravel, and Mulch have the wrong physical characteristics and should not be used with this spreader. Never exceed the rated load capacity of 70lbs when operating the spreader.
  • Page 6 ASSEMBLY INSTRUCTIONS STEP 1: INSTALLING THE SUPPORT LEG 1. Attach the support leg (#29) to the installation tube assembly (#14) using step bolt M6x40 (#28), camber washer (#21) and nylon lock nut M6 (#13). 2. Attach the left and right support tube (#27) to the installation tube assembly (#14) using step bolt M6x40 (#28), camber washer (#21) and nylon lock nut M6 (#13).

  • Page 7: Step 2: Installing The Handle

    STEP 2: INSTALLING THE HANDLE 1. Attach the handle connecting tube (#31) to the left and right support tube (#27) using step bolt M6x45 (#47), camber washer (#21) and nylon lock nut M6 (#13). Tighten all the nuts. 2. Connect the lower adjustment lever (#30) to the connecting rod fixed plate (#12) using hex bolt M6x16 (#11), nylon washer (#2) and nylon lock nut M6 (#13).

  • Page 8: Using Your Spreader

    OPERATION INSTRUCTIONS USING YOUR SPREADER 1. Inspect your spreader before each use. Make sure the wheels turn easily, and the gearbox moves when the spreader is pushed. The hopper should be clean and free from cracks. 2. Spreader is designed to spread a range of materials (Fertilizer, Grass Seed and Ice melt). Materials such as Powder, Manure, Topsoil, Gravel, and Mulch have the wrong physical characteristics and should not be used with your spreader.

  • Page 9: Adjusting The Flow

    ADJUSTING THE FLOW CONSISTENT COVERAGE To ensure consistent coverage, make sure each broadcast pattern slightly overlaps the previous broadcast pattern as shown in figure below. The approximate broadcast widths for different materials are shown in the application chart.

  • Page 10: Maintenance And Storage

    MAINTENANCE AND STORAGE MAINTENANCE • After each use clean material out of hopper and off of the impeller. • Rinse/dry inside and outside of the spreader after each use. • Before operating make sure the tires have the RECOMMENDED TIRE PRESSURE 20 PSI. •...
  • Page 11 PARTS DIAGRAM & EXPLODED VIEW...
  • Page 12 Ref# Drawing No. Description NB04-00001-HO Hopper BS1200-00009 Nylon Washer 9104-06040-BXG Inner Hex Screw M6x40 9504-05013-YH Open Type Blind Rivet M5x13 9301-05000-BXG Flat Washer Ø5 9504-05008-YH Open Type Blind Rivet M5x8 N512-00009 Revolving Shaft Sleeve BS1200-00001-PG Fixed Adjustable Plate BS1200-00002-PG Active Adjustable Plate N512-00023-CD Torsional Spring Fixed Plate 9101-06016-CD...
  • Page 13 Drawing No. Ref# Description BS0700-01000 Handle Connecting Tube BS0700-00002 Handle Sleeve 9302-06000-CD Big Flat Washer Ø6 N512-00025-CD Torsional Spring 9101-08035-CD Hex Bolt M8x35 BS1200-00011 Graduated Plate CPR150B-00008-CD Spring 9302-08000-CD Big Flat Washer Ø8 9206-08000-CD Hex Lock Nut M8 BS1200-05000 Handle N570-00015 Adjustable Handle B 9118-04018-CD...
  • Page 14 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
  • Page 15 NEED HELP? CONTACT US FIRST. 1-800-605-7595 info@palletworks.com www.palletforks.com © 2023 Titan Brands...
