- Page 1 STUFFING MACHINE OPERATION MANUAL ENGLISH VERSION USER MANUAL Please read the instruction carefully before use.Parameters are subject to change without prior notice! INDEX 1 / 10...
- Page 2 FOREWORD Thank you for choosing our stuffing mixer machine. This manual describes the features and equipment composition of the cutter as fully as possible, but not all of the features are provided as standard. If there is any omission or error in this manual, please understand and correct it, we will revise and perfect it further. INDEX Ⅰ...
- Page 3 Model Power（W) Rotation Speed（r/min） Efficiency（kg/h） L×W×H FMH100 2200 1149X646X1014 1.3 OPERATING PRINCIPLE When the machine is working, please close the lid combination then put various ingredients such as roots, stems, leaf vegetables or meat into the stuffing pan. An angle of about 45 degrees is formed between the rotating shaft and the blades fixed on it.
- Page 4 Ⅱ . GENERAL DESCRIPTION Read the installation manual carefully before installation. Please keep the installation manual for later use. Fire prevention- Please ensure that there are no combustible and flammable objects around the electrical equipment.Please keep it away from the flammable objects. nstallation of equipment-Ensure that it is installed in a ventilated area to prevent hazards caused by the unignited ...
- Page 5 Individuals must be trained before use, and there must be a person looking after the machine when it is in operation. In case of malfunction or poor operation, turn off the electrical appliance. Do not use chlorine-containing products (even diluted) to clean the surface of the equipment, including sodium hypochlorite, hydrochloric acid, chlorination calculation, etc.
-
Page 6: Electrical Connection
Ⅳ .INSTALLATION Please carefully read the installation and repair steps in this manual before installing the machine. installation, maintenance must be effected by the manufacturer or authorized professional personnel. Failure to carry out proper installation and replacement steps may cause damage to the machine,as well as danger to the person , which will not be covered by the production warranty. - Page 7 To ensure equipment safety and personal safety, Zero wire and ground wire cannot be shared .Ground wire should be reliably grounded. The bolt with mark is EQUIPOTENTIAL point,please make sure it is well connected. 5.2 REQUIREMENTS FOR THE USE OF CABLES The external power cord of the equipment must be protected with metal or rigid plastic pipes,and the connection inlet must be reinforced by a special cable seal.
- Page 8 1、START——START BUTTOM 2、STOP——STOP BUTTON 3、CHANGEOVER SWITCH（FORWARD ——STOP——REVERSE） 4、E-STOP——E-stop button 6.2 COME INTO USE 6.2.1 Open the cover assembly and put in proper amount of food,ingredients, be careful not to be too full, better not touch the top cover. Large vegetables should be cut into small pieces first, do not put foreign material into the filling pot, otherwise it will damage the mixer assembly.
-
Page 9: Maintenance Plan
Electrical components are not submerged in water! Improper operation will permanently deform and cause damage to the normal operation of the machine! 7.1 EXTERNAL PART Use soapy water after use, remove dirt and residue from steel surface with or without detergent cloth or sponge, and thoroughly dry the surface after cleaning. -
Page 10: Electrical Diagram
Ⅸ ATTACHMENT 9.1 ELECTRICAL DIAGRAM SB1 Emergency Stop SB2 stop button SB3 start button FR1 thermal relay KM1 contactor SQ1 FWD/REV switch M motor 10 / 10...
