- Page 1 PointWrite User Manual...
-
Page 2: Table Of Contents
Table of contents Shipping contents....3 Attaching the PointWrite to the projector....4 Connecting the PointWrite to PC ....5 Pen action......5 Exchanging the pen tip ......5 Driver Installation....6 Configuration setting ..8 The PointWrite configuration....8 Alignment View .........9 PointWrite Calibration......10 Running the PointWrite ...... -
Page 3: Shipping Contents
Shipping contents The PointWrite is a built in Interactive Whiteboard on the projector. To use the PointWrite correctly, please find the standard accessories below and follow the instructions in this manual. PointWrite Installation CD Quick manual Two PointWrite pens Mini USB cable Two sets of batteries Extra pen tips Screws... -
Page 4: Attaching The Pointwrite To The Projector
Attaching the PointWrite to the projector Attach the PointWrite to the projector as illustrated and tighten the screw to secure the PointWrite. Attach the PointWrite to the projector as illustrated. Tighten the screw to secure the PointWrite. Attaching the PointWrite to the projector... -
Page 5: Connecting The Pointwrite To Pc
Connecting the PointWrite to PC Use the USB cable to connect the PointWrite to PC. Plug the USB mini-B end into the PointWrite and plug the USB type-A end into PC. Pen action The PointWrite Pen provides the following 4 actions: Click: Touch an icon or a menu on the screen. -
Page 6: Driver Installation
Driver Installation Insert the PointWrite CD into your CD/DVD-ROM driver. The Installation assistant will run automatically. Follow the instructions on the screen. If the assistant does not run automatically, double click on the “setup.exe” under CD/DVD-ROM directory and the Installation assistant will display. Click Install PointWrite in the installation assistant. - Page 7 Click Install, the installation begins. The installation ends and a dialog box will appear. Click “Finish. After the installation is finished, • The PointWrite icon will be created on the desktop. • The installation folder will be created on C: directory. •...
-
Page 8: Configuration Setting
When the projector is placed on the table, do not click this item. • Rear Screen Mode: If the projector is installed on the rear screen system, click this item. Select Update Server: Please visit local BenQ Website for more support. Configuration setting... -
Page 9: Alignment View
Alignment View The PointWrite Alignment function is to set the orientation of the PointWrite to the screen. Alignment View: When clicking on the “Alignment View”, the screen image is displayed on the alignment view box (central black box). If the screen image is not in the center, the calibration will fail. Please make sure the PointWrite module is attached to the projector properly. -
Page 10: Pointwrite Calibration
PointWrite Calibration PointWrite provides two kinds of calibration methods: auto calibration and manual calibration. Auto calibration : click on and the calibration process will run automatically. When you choose this method, white image is shown on the screen and the pattern image is displayed. - Page 11 Manual calibration: Click on and the calibration window will be projected on the screen. Use the PointWrite pen to click on the center of calibration cursor immediately after it appears. Then the next cursor will display. Repeat this process until the last calibration cursor disappears.
-
Page 12: Running The Pointwrite
PointWrite pull-up menu Running the PointWrite After you double click on the PointWrite icon on the desktop, the PointWrite will initiate and the PointWrite icon will be created on the system tray area. Right click on the PointWrite icon on the system tray area and a pull-up menu appears. Configuration: Choose this when you want to change the installation position of the projector. -
Page 13: Specifications
Storage Temperature -20°C ~ 60°C Operating Temperature 5°C ~ 40°C Dimensions 71 mm x 29 mm x 15.5 mm Weight 32 g Compatible model Selected BenQ short throw models PointWrite Pen Power AAA Battery*2 Length 176 mm Diameter 15 mm Weight...
