Acrow POWERSHORE 30 Technical Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TECHNICAL GUIDE
ACROW POWERSHORE 30
FALSEWORK & SHORING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWERSHORE 30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acrow POWERSHORE 30

  • Page 1 TECHNICAL GUIDE ACROW POWERSHORE 30 FALSEWORK & SHORING...
  • Page 2 Neither all nor part of this document may be reproduced or transmitted in any way by any electronic or mechanical procedure, including photocopy, magnetic recording or any other form of information storage or retrieval system without the written permission. ©COPYRIGHT BY ACROW 2023 DOCUMENT NO: ACROWPOWERSHORE30_SEPT2023_ISSUEA...
  • Page 3 POWERSHORE 30 Technical Manual Release Notes This page is intended to record all changes to the POWERSHORE 30 technical manual pages. Changes or additions to this manual will be itemised with a brief description and date when the amendments were made.

  • Page 4: Table Of Contents

    Purpose of the Document Safety Information Important Information Disclaimer Applicable Codes and Standards 2. GENERAL PRODUCT INFORMATION Powershore 30 Components Powershore 30 Components 3. WORKING LOAD LIMITS (WLL) Geometrical Considerations Summary of Load Charts Example Top Unrestrained & Bottom Restrained 2 Horizontal Frame Levels Top Unrestrained &...
  • Page 5 POWERSHORE 30 Dismantling the Tower Dismantling the Tower 6. TRANSPORT & HANDLING Powershore Standards Stillage Horizontal Bracing Frames Stillage Corner Braces / 600 Tie Bar / Connectors Stillage Adjustable Bases Stillage Wedge Jack Stillage Base Plate / U-head Attachment Stillage 7.

  • Page 7: Technical Specifications

    1. Technical Specifications System Description The Acrow POWERSHORE 30 is a high load shoring system that provides a fast, efficient and versatile supporting structure. The simplicity of the coupling of strong vertical Standards joined together by Horizontal Bracing Frames enables towers to be easily and safely erected.

  • Page 8: Safety Information

    The illustrations in these assembly configurations are minimum guidelines only. The combined use of the POWERSHORE 30 system with equipment from other suppliers may entail performance issues and therefore requires a design check and/or verification by Acrow Engineering or a qualified experienced engineer.

  • Page 9: General Product Information

    POWERSHORE 30 2. GENERAL PRODUCT INFORMATION...

  • Page 10: Powershore 30 Components

    1800 Standard APSS18 39.0 2400 Standard APSS24 52.0 3000 Standard APSS30 65.0 Acrow Powershore Horizontal Bracing Frames 900 Hoz. Bracing Frame APSF09 24.0 1200 Hoz. Bracing Frame APSF12 31.0 1800 Hoz. Bracing Frame APSF18 41.0 2400 Hoz. Bracing Frame APSF24 51.0...

  • Page 11: Powershore 30 Components

    POWERSHORE 30 2. General Product Information Powershore 30 Components PRODUCT PRODUCT DESCRIPTION MASS (kg) CODE Acrow Powershore Adjustable Base Adjustable Base APSSJ 51.0 Acrow Powershore Hop Up Bracket Hop-up Bracket APSHUB...

  • Page 13: Working Load Limits (Wll)

    POWERSHORE 30 3. WORKING LOAD LIMITS (WLL)

  • Page 14: Geometrical Considerations

    Single Leg Props: When Acrow Powershore 30 is used as a single leg prop the boundary conditions at the top & bottom of the prop are considered as being restrained. The chart on page 19 provides working load capacities for prop...

  • Page 15: Summary Of Load Charts

    In the top unrestrained condition (ie. case 1) the stability of the load to be supported by Acrow Powershore 30 must be considered to ensure that it does not have adverse effect on the load capacity of the Acrow Powershore 30 towers. Generally, overall height is measured from top to bottom of the tower including adjustable bases.

  • Page 16: Example

    3. Working Load Limits (WLL) Example Case: Top unrestrained, bottom restrained PowerShore 30 Tower overall height (including jacks and unrestrained load) = 8.0m Plan dimension: 1.80 x 2.40m • Height 8.0m — 5.80 < 8.0m < 8.80m — 3 horizontal frame levels •...

  • Page 17: Top Unrestrained & Bottom Restrained 2 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top Unrestrained & Bottom Restrained 2 Horizontal Frame Levels Height from 4.60m - 5.80m Tower Height (m)

  • Page 18: Top Unrestrained & Bottom Restrained 3 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top Unrestrained & Bottom Restrained 3 Horizontal Frame Levels Height from 5.80m - 8.80m Tower Height (m)

  • Page 19: Top Unrestrained & Bottom Restrained 4 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top Unrestrained & Bottom Restrained 4 Horizontal Frame Levels Height from 8.80m - 11.80m Tower Height (m)

  • Page 20: Top Unrestrained & Bottom Restrained 5 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top Unrestrained & Bottom Restrained 5 Horizontal Frame Levels Height from 11.80m - 14.80m Tower Height (m)

  • Page 21: Top & Bottom Restrained 2 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top & Bottom Restrained 2 Horizontal Frame Levels Height from 4.60m - 5.80m Tower Height (m)

  • Page 22: Top & Bottom Restrained 3 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top & Bottom Restrained 3 Horizontal Frame Levels Height from 5.80m - 8.80m Tower Height (m) 3.10...

  • Page 23: Top & Bottom Restrained 4 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top & Bottom Restrained 4 Horizontal Frame Levels Height from 8.80m - 11.80m Tower Height (m) 3.11...

  • Page 24: Top & Bottom Restrained 5 Horizontal Frame Levels

    POWERSHORE 30 3. Working Load Limits (WLL) Top & Bottom Restrained 5 Horizontal Frame Levels Height from 11.80m - 14.80m Tower Height (m) 3.12...

  • Page 25: Single Prop - Top & Bottom Restrained

    POWERSHORE 30 3. Working Load Limits (WLL) Single Prop - Top & Bottom Restrained Height from 2.80m - 10.00m Tower Height (m) 3.13...

  • Page 26: Hop Up Wll

    POWERSHORE 30 3. Working Load Limits (WLL) Hop Up WLL 5.0 kN/m Ensure tower is designed for cantilever loads 900mm gate 3.14...

  • Page 27: System Details

    POWERSHORE 30 4. SYSTEM DETAILS...

  • Page 28: Heights & Horizontal Bracing Frames

    POWERSHORE 30 4. System Details Heights & Horizontal Bracing Frames 2 Horizontal Frame Levels 3 Horizontal Frame Levels...

  • Page 29: Heights & Horizontal Bracing Frames

    POWERSHORE 30 4. System Details Heights & Horizontal Bracing Frames Single Props 4 Horizontal Frame Levels 5 Horizontal Frame Levels...

  • Page 30: Single Props

    POWERSHORE 30 4. System Details Single Props Ø Internal Ø120.4 Length Product Code 1200 Standard APSS12 APSS18 1800 Standard APSS24 2400 Standard 3000 Standard APSS30 Adjustable Base Wedge Jack M16 Tapped Holes Height : 80 - 130...

  • Page 31: Assembly Details

    POWERSHORE 30 5. ASSEMBLY DETAILS...

  • Page 32: Assembling The Powershore Shoring System - Method A

    POWERSHORE 30 5. Assembly Details Assembling the Powershore Shoring System - Method A Before commencing, ensure the area set aside to erect the towers is sufficiently large enough to allow for clear access around the tower segments. There must also be an area in which the completed tower segments can be stored near the assembly area.

  • Page 33: Assembling The Powershore Shoring System - Method A

    POWERSHORE 30 5. Assembly Details Assembling the Powershore Shoring System - Method A 2400mm brace frame Place the remaining Standard over the remaining Adjustable Base and connect a 2400 Horizontal Bracing Frame to join up the fourth Standard. 1200mm brace...

  • Page 34: Assembling The Powershore Shoring System - Method B

    POWERSHORE 30 5. Assembly Details Assembling the Powershore Shoring System - Method B Standards Before commencing ensure the area set aside to erect the towers is sufficiently large enough to allow for clear access around the tower segments. There must also be an area in which the completed tower segments can be stored near the assembly area.

  • Page 35: Assembling The Powershore Shoring System - Method B

    POWERSHORE 30 5. Assembly Details Assembling the Powershore Shoring System - Method B 2400mm brace frame Connect the remaining 2400 Horizontal Bracing Frame to complete the base section of the tower. Connect the 2 Powershor Corner Braces in opposing corners.

  • Page 36: Method A/B Continued

    POWERSHORE 30 5. Assembly Details Method A/B Continued This process is repeated to construct the mid section of the tower (but without the Adjustable Bases) and the top section of the tower taking care to install the Corner Braces in opposite corners to the lower section of the tower so that the tower when assembled will have alternating corner braces.

  • Page 37: Dismantling The Tower

    POWERSHORE 30 5. Assembly Details Dismantling the Tower Soffit The Powershore towers supporting the slab soffit formwork were put in place as a completed tower, however each segment of the tower will have to be individually removed. Lower the U-head Adjustable Bases sufficiently to allow plywood, joists and bearers to be removed.

  • Page 38: Dismantling The Tower

    POWERSHORE 30 5. Assembly Details Dismantling the Tower Remove Top Section Using mechanical means such as a forklift, lift the top section of the tower clear of the Standard Connectors of the lower section and remove it to a dismantling area.

  • Page 39: Transport & Handling

    POWERSHORE 30 6. TRANSPORT & HANDLING...

  • Page 40: Powershore Standards Stillage

    6. Transport & Handling Powershore Standards Stillage The Acrow stillage is used to store a set number of items per a stillage. Items should be stored in a particular way to prevent them from falling off the stillage. The recommended method and process is: •...

  • Page 41: Horizontal Bracing Frames Stillage

    6. Transport & Handling Horizontal Bracing Frames Stillage The Acrow stillage is used to store a set number of items per a stillage. Items should be stored in a particular way to prevent them from falling off the stillage. The recommended method and process is: •...

  • Page 42: Corner Braces / 600 Tie Bar / Connectors Stillage

    Corner Braces / 600 Tie Bar / Connectors Stillage The Acrow stillage is used to store a set number of items per a stillage. Items should be stored in a particular way to prevent them from falling off the stillage.

  • Page 43: Adjustable Bases Stillage

    6. Transport & Handling Adjustable Bases Stillage The Acrow stillage is used to store a set number of items per a stillage. Items should be stored in a particular way to prevent them from falling off the stillage. The recommended method and process is: •...

  • Page 44: Wedge Jack Stillage

    6. Transport & Handling Wedge Jack Stillage The Acrow stillage is used to store a set number of items per a stillage. Items should be stored in a particular way to prevent them from falling off the stillage. The recommended method and process is: •...

  • Page 45: Base Plate / U-Head Attachment Stillage

    6. Transport & Handling Base Plate / U-head Attachment Stillage The Acrow stillage is used to store a set number of items per a stillage. Items should be stored in a particular way to prevent them from falling off the stillage.

  • Page 47: Maintenance & Inspection

    POWERSHORE 30 7. MAINTENANCE & INSPECTION...

  • Page 48: Powershore Adjustable Base

    POWERSHORE 30 7. Maintenance & Inspection Powershore Adjustable Base The Powershore Adjustable Base is used at the bottom of a Powershore tower to provide height adjustment. It can also be used at the top with or without an attached U-Head to provide adjustment for the formwork.

  • Page 49: Powershore Base Plate

    POWERSHORE 30 7. Maintenance & Inspection Powershore Base Plate Concrete deposits. Remove all despoits Check stem is straight. If bent isolate and send to Workshop for repair Check welds not cracked or Plate is bent or twisted. If bent broken. If cracked or broken, isolate...

  • Page 50: Powershore Brace Frame

    POWERSHORE 30 7. Maintenance & Inspection Powershore Brace Frame The Powershore Brace Frame provides the horizontal connection between Powershore Legs when constructing a Powershore tower. Concrete deposits on Brace Frame. Clean deposits off truss Check welds for breaks or cracks. If...

  • Page 51: Powershore Connector

    POWERSHORE 30 7. Maintenance & Inspection Powershore Connector Concrete deposits on Connector. Check welds are intact. If not isolate Clean deposits off connector. and send to workshop for rewelding Check washer is flat and at right Check connector is straight. If bent or angles to stem.

  • Page 52: Powershore Corner Brace

    POWERSHORE 30 7. Maintenance & Inspection Powershore Corner Brace The Powershore Corner Brace is used to stiffen up a tower and keep it square in plan profile. Check couplers are intact and in working Concrete deposits on Corner Brace. Clean...

  • Page 53: Powershore Tie Bar

    POWERSHORE 30 7. Maintenance & Inspection Powershore Tie Bar Check couplers are intact and in Concrete deposits on Corner Brace. working order If not intact and/or are Clean concrete off Corner Brace ensuring not able to be tightened isolate and...

  • Page 54: Powershore U-Head

    POWERSHORE 30 7. Maintenance & Inspection Powershore U-Head The Powershore U-Head is a detachable unit which can be bolted to the Powershore Base to convert it into an adjustable U-Head to support formwork beams. Check sides and bearing surface Concrete deposits on U-Head are not bent.

  • Page 55: Powershore Wedge Jack

    POWERSHORE 30 7. Maintenance & Inspection Powershore Wedge Jack Check both spring assemblies holding the top and bottom segments together are in place and Concrete deposits on intact. If not in place and intact Powershore Wedge Jack. isolate and send to workshop for...

  • Page 56: Powershore Leg

    POWERSHORE 30 7. Maintenance & Inspection Powershore Leg The Powershore Leg is the main vertical support member of a Powershore tower. Concrete deposits on Powershore Leg. Clean concrete deposits off Powershore Leg paying particular attention to ensure connecting brackets Check end of standard are clean.
  • Page 57 2a Mavis Street Geebung QLD 4034 Moonah TAS 7009 Revesby NSW 2212 07 3265 2266 03 6277 1212 1300 138 362 info@acrow.com.au 2 Morrison Lane 65 Boland Street Beenleigh QLD 4207 Launceston TAS 7250 NEW SOUTH WALES 07 3807 9800...
