CEILING FAN
INSTALLATION INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
Designer Series
Model: SUN672D XX6MB(LED)
FAN RATING AC 120V. 60Hz
UL LISTED MODEL: YU-Q5800CF (SUN672D)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Designer Series and is the answer not in the manual?

Questions and answers

Related Manuals for HOMEnhancements Designer Series

Summary of Contents for HOMEnhancements Designer Series

  • Page 1 CEILING FAN INSTALLATION INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS Designer Series Model: SUN672D XX6MB(LED) FAN RATING AC 120V. 60Hz UL LISTED MODEL: YU-Q5800CF (SUN672D)

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: a. Blade set (6) b. Hanger bracket c.

  • Page 3: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, insure 9. To avoid personal injury or damage to the electricity has been turned off at the circuit fan and other items, be cautious when working around or cleaning the fan. breaker or fuse box before beginning.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing UL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit Outlet box breakers. Secure the outlet box directly to the building structure. Use appropriate fasteners and building Figure 1 materials.

  • Page 5: Hanging The Fan

    5. HANGING THE FAN Ceiling ETL Listed hanger electrial bracket REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Washers Step 1. Pass the 120-volt supply wires through Mounting screws 120V Wires (supplied with the center hole in the ceiling hanger bracket electrical box) Figure 5...

  • Page 6: Make The Electric Connections

    6. MAKE THE ELECTRIC ground wire directly to one of the screws from the outlet box. CONNECTIONS ● Carefully tuck the connected wires inside the WARNING: To avoid possible electrical shock, junction box. Secure the transmitter with the be sure electricity is turned off at the main two screws provided.

  • Page 7: Finishing The Installation

    7. FINISHING THE INSTALLATION Outlet box Step 1. Tuck connections neatly into ceiling Hanger outlet box. bracket Screws Step 2. Slide the canopy up to hanger bracket and place the key hole on the canopy over the screw on the hanger bracket, turn canopy until Canopy it locks in place at the narrow section of the key holes.

  • Page 8: Attaching The Mounting Plate

    9. ATTACHING THE MOUNTING PLATE Step 1. Remove the 1 of 3 screws from the mounting ring and keep it for future use. Loosen the other 2 screws. (Do not remove) Step 2. Place the key holes on the light kit mounting plate over the 2 screws previously loosened from the mounting ring, turn light kit mounting plate until it locks in place at the...

  • Page 9: Installing The Wall Control

    11. INSTALLING THE WALL CONTROL WARNING: Hook up in "series only" do not connect the hot and neutral wires of electric circuit to the transmitter wall switch - damage to the switch and possible fire could occur. Step 1. Remove the existing wall plate and switch from the wall junction box.
  • Page 10 12. OPERATING E. "D" and "ON" dip switch: The "ON" selection is the light dimmable INSTRUCTIONS selection and is to be used with all bulbs execpt for CFL bulbs. The "D" selection is the light on only (no dimmable function) Your DC brushless motor is equipped with an and is to be used with CFL and LED bulbs automatically learned type remote control.
  • Page 11 Pairing Process WARM/COOL WEATHER OPERATING With the fan’s power off, arrange code switches INSTRUCTIONS to desired code setting only if the factory pre-set Speed settings for warm or cool weather code (all 4 dip switches in “ON” position) will depend on factors such as the room size, not be used.
  • Page 12 13. OPERATING INSTRUCTIONS Here are some suggestions to help you maintain your fan 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. (It is not necessary to remove fan from ceiling.) 2.

  • Page 13: Troubleshooting

    14. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency.
