Campomatic WD13TX User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
Washer Dryer / User Manual
WD13TX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD13TX and is the answer not in the manual?

Questions and answers

Related Manuals for Campomatic WD13TX

Summary of Contents for Campomatic WD13TX

  • Page 1 Washer Dryer / User Manual WD13TX...
  • Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...

  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................2 1.2. During Use ........................7 1.3. Packaging and Environment..................8 1.4. Savings Information .......................8 2. TECHNICAL SPECIFICATIONS ..................10 3. OVERVIEW OF YOUR MACHINE ...................11 3.1. General Appearance ....................11 4. SETTING UP YOUR MACHINE ..................11 4.1.

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS Operating voltage / frequency (V/Hz) (220-240) V~/50Hz Total current (A) Water pressure (Mpa) Maximum 1 Mpa / Minimum 0.1Mpa Total power (W) 2200 Drum Capacity 61 lt • Do not install your machine on a carpet or such grounds that would prevent the ventilation of its base.

  • Page 5: General Safety Warnings

    contact the following address: “washingmachine@ standardtest.info”. In your e-mail, please provide the model name and serial number (20 digits) which you can find on the appliance door. To ensure your safety and the safety of others, please read the following safety precautions before using or installing your Washer Dryer.
  • Page 6 • Lints must not to be allowed to accumulate around the washer dryer. • Residue may build up on detergent and softeners exposed to air for a long period of time. Only put softener or detergent in the drawer at the beginning of each wash.
  • Page 7 use of fabric conditioner or any similar products that you intend to use in your Washer Dryer. • Do not stop your Washer Dryer before the drying phase of a programme has been completed. If you have to do so, quickly remove all of your laundry and immediately spread the items on an appropriate surface to allow them to cool.
  • Page 8 • A damaged power cord/plug can cause fire or give you an electric shock. When damaged it must be replaced, this should only be done by qualified personnel. • Never remove the plug from the socket by pulling the cord. Always hold the plug. •...
  • Page 9 beginning a washing or drying programme. • Laundry which has been cleaned with industrial chemicals. • Laundry that has a high amount of sponge, foam, rubber or rubber-like parts and accessories. • Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the drying process of the...

  • Page 10: During Use

    people move your Washer Dryer. Child Safety • Do not allow children to play with the machine. • Do not leave children unattended near the machine. They might lock themselves in the machine. • The door glass and machine surface can become extremely hot during operation.

  • Page 11: Packaging And Environment

    • This appliance can be used by children aged from 8 years and above and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 12 lightly soiled laundry will save electricity and water consumption. CE Declaration of conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.

  • Page 13: Technical Specifications

    2. TECHNICAL SPECIFICATIONS Drum Capacity 61 lt Spin speed (rpm) 1400 Number of programmes Operation voltage / Frequency (v/hz) 220-240 / 50 Maximum: 1 Water pressure (mpa) Minimum: 0.1 Dimensions (HxWxD) (mm) 845x597x582 * You should not put dry laundry in your machine for drying. Energy consumption (washing, spinning, drying) (kWh/cycle) 6.12 Energy consumption (only washing and spinning) (kWh/cycle)

  • Page 14: Overview Of Your Machine

    3. OVERVIEW OF 6. Door YOUR MACHINE 7. Pump Filter Cover 8. Power Cord 3.1. General Appearance 9. Drain Hose 10. Transport Screws 11. Adjustable Feet 12. Plastic Drain Hose Holder: (Do not remove the holder; the operation of the machine will be affected).

  • Page 15: Placing The Machine And Adjusting The Feet

    transport screws should be stored for future • Turn the feet clockwise to increase the use. height of the machine. Turn the feet anti- clockwise to decrease the height of the 4. Insert the plastic blanking caps from the machine. accessories bag into the gaps left by the transit screws.

  • Page 16: Water Inlet Connection

    • If in any doubt, consult a qualified NOTE: plumber. Operating your machine with low voltage will cause the life cycle • Turn the cold water supply on and check of your machine to be reduced and its for any leaks. performance to be restricted.

  • Page 17: Control Panel Overview

    your machine into a container, bucket or 5.1. Detergent Drawer General View bathtub. • Make sure that the water drain hose is not bent, buckled, crushed or extended. 5. CONTROL PANEL OVERVIEW 1. Detergent drawer 2. Programme Dial / On-Off button: Use the programme dial to select the washing / drying programme for your laundry.

  • Page 18: Sections

    5.2. Sections 5.3. Programme Dial Main wash detergent compartment: This compartment is for liquid or powder • To select the desired programme, turn detergents or limescale remover. The fluid the programme dial either clockwise or detergent level plate is supplied inside your anti-clockwise until the marker on the machine.

  • Page 19: Explanation Of Washing Symbols

    6.2. Explanation of Washing Symbols materials on your laundry or in the pockets; if so, remove them. Maximum ironing WARNING: Machine wash temperature Any malfunction 110°C occurring due to foreign materials damaging Machine wash, permanent press your machine are not covered by the Do not iron warranty.

  • Page 20: Choice Of Detergent And Placing Into The Machine

    • You can use liquid detergent in all programmes without pre-washing. Insert the liquid detergent apparatus in compartment II of the detergent drawer and adjust the liquid detergent amount (follow the instructions on the liquid detergent packaging). Do not exceed the MAX level..

  • Page 21: Half-Load Detection System

    washing programme. 2. Spin speed selection • Your machine has progressed too far into the selected programme for the Spin Speed additional function to be possible. • The additional function you have chosen is not compatible with another additional function you have already selected.
  • Page 22 is displayed. Table: Recommended drying durations for load amounts: • Option 2 “ ”: 135 min. : Recommended for laundry that requires hanging. To 1 - 2 kg 3 - 4 kg 5 - 6 kg select the “ ” drying option, press the Option 1 drying option button until the “...
  • Page 23 4. Drying option selection: SELECTABLE/ DRYING FACTORY PROGRAMME SELECTABLE OPTIONS PROFILE PRESET SELECTABLE Cotton Cotton dry Option 1 Option 2 Option 3 Cotton eco Cotton dry Option 1 Option 2 Option 3 Eco 20°C Cotton dry Option 1 Option 2 Synthetics Gentle dry Option 1...

  • Page 24: Cancelling Programme

    5. Delayed Start 7. Child Lock Delay Timer The Child Lock function allows you to lock • Press the Delay button once. the buttons so that the wash cycle you have chosen cannot be changed unintentionally. • “1 h” will appear on the display. To activate child lock, press and hold •...

  • Page 25: Finishing Programme

    7.3. Finishing Programme Your machine will stop by itself as soon as the programme you have selected finishes. • “END” will flash on the electronic display. • You can open the machine’s door and remove the laundry. • Leave the door of your machine open to allow the inner part of your machine to dry.

  • Page 26: Programme Table

    8. PROGRAMME TABLE Programme Laundry type / Descriptions Heat resistant, cotton and linen textiles. COTTON 90° C 90° (Underwear, bed sheets, tablecloths Heat resistant, cotton and linen textiles COTTON ECO 60°e (Underwear, bed sheets, tablecloths Lightly soiled, cottons and linen textiles ECO 20°...

  • Page 27: Maintenance And Cleaning Of Your Machine

    9. MAINTENANCE 9.2. Water Inlet Filters AND CLEANING OF YOUR MACHINE 9.1. Warning Water inlet filters prevent dirt and foreign materials from entering your machine. We recommend that these filters are cleaned when your machine is unable to receive sufficient water, although your water supply is on and the tap is open.

  • Page 28: Pump Filter

    accumulated residue. The pump filter system in your Washer Dryer prolongs the life of the pump by To remove the detergent drawer: preventing lint from entering your machine. • Pull the drawer forwards until it is fully We recommend that you clean the pump extended.

  • Page 29: Flush Stopper / Body / Drum

    10. FLUSH STOPPER / BODY / DRUM 1. Flush stopper Remove the detergent drawer and disassemble the flush stopper. Clean thoroughly to completely remove any softener residue. Refit the flush stopper after cleaning and check that it is seated properly. 2.

  • Page 30: Troubleshooting

    11. TROUBLESHOOTING Repair of your machine should be carried out by an authorised service company. If your machine requires repair or if you cannot solve an issue with the information provided below, then you should: • Unplug your machine from the mains power supply. •...

  • Page 31: Automatic Fault Warnings And What Needs To Be Done

    FAULT POSSIBLE CAUSE TROUBLESHOOTING There is detergent residue Non-dissolving particles of some Perform an extra rinse, or clean your laundry with on your laundry after detergents may appear on your a brush after it dries washing laundry as white spots. There is detergent residue There is untreated oil, cream or Use the amount of detergent as instructed on the...

  • Page 32: Describing The Energy Label And Saving Energy

    13. DESCRIBING THE ENERGY LABEL AND SAVING ENERGY Energy and water consumption may vary based on water pressure, water hardness, water temperature, ambient temperature, amount of laundry, additional function selection and/or voltage fluctuations. To reduce energy and water consumption, do not exceed the maximum laundry amounts for the selected programme, wash your laundry when it is lightly soiled or wash your daily laundry in short programmes.
  • Page 33 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 34 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 35 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 36 52370869...
