P a g e
| 1
PRODUCT MODEL NUMBER:
TL-HWR-13 1200Mbps
Dual Band Smart Wireless Router
ABOUT THIS
MANUAL
DISCLAIMER
No part of this document may be reproduced in any form without the written permission of the copyright
owner.
The contents of this document are subject to revision without notice due to continued progress in
methodology, design and manufacturing. TRANSLITE GLOBAL LLC shall have no liability for any error or
damage of any kind resulting from the use of this document.
COPY WARNING
This document includes some confidential information. Its usage is limited to the owners of the
product that it is relevant to. It cannot be copied, modified, or translated in another language
without prior written authorization from TRANSLITE GLOBAL LLC
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TransLite TL-HWR-13
Summary of Contents for TransLite TL-HWR-13
- Page 1 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. TRANSLITE GLOBAL LLC shall have no liability for any error or damage of any kind resulting from the use of this document.
-
Page 2: Table Of Contents
P a g e INDEX TABLE OF CONTENTS CHAPTER 1 OVERVIEW ......................3 1.1 INTERFACE ..........................3 1.2 LED LIGHTS ..........................3 1.3 CONNECT ROUTER WITH PC ....................4 CHAPTER 2 LOGIN TO THE WEB ....................5 CHAPTER 3 WEB GUI CONFIGURATION .................. -
Page 3: Chapter 1 Overview
P a g e CHAPTER 1 OVERVIEW INTERFACE P1 Router Interface LED LIGHTS LED Indicator Instruction Status Description Power LED Blue Power On Green Ethernet Connected Green LAN Connected Internet Green/Blue Internet Link Up: Green; Internet Link down: Blue... -
Page 4: Connect Router With Pc
P a g e CONNECTING ROUTER WITH PC User can connect the PC with wireless router by Wireless SSID and LAN cable: The diagram of wireless connection showed as follow: Please note: the default SSID is Wireless2.4G, SSID’s password is 66666666 Connect router with PC in Wi-Fi The diagram of LAN cable connection showed as follow: Connect router with PC in LAN Port... -
Page 5: Login To The Web
P a g e CHAPTER 2 LOGIN TO THE WEB 2.1 Power on this wireless router, connect PC with wireless router as chapter 1 connection. 2.2 Click Internet Explorer and input 192.168.188.253 on the address bar, then press Enter, following page will pop up. Click Experience to go on, the router will pop up a window ask for select router mode –... - Page 6 P a g e When you choose Gateway mode, it will scan the Internet connected method at first If the scan fails, the user will be prompted to wither detect the connection or skip the step.
- Page 7 P a g e If the user skips the testing process, the following is the next step where the connection method will have to be chosen: Click Next to continue to the Wi-Fi setting: Apply to finish, a login page will pop up, input Device Password, then click Login to Enter.
-
Page 8: Web Gui Configuration
P a g e CHAPTER 3 WEB GUI CONFIGURATION Once logged in, the following home page will be displayed: Home page Click ‘I know’ to continue: The below topics show how to configure User Manager, Setup Wizard, Wi-Fi Setting, LAN Setting, WAN Setting, URL Filter, Timed Reboot and advanced functions. -
Page 9: User Manager
P a g e 3.1. User Manager In user manager section, one can manage the network behavior of family members and visitors. Config: To control the Ethernet behavior or Ethernet time, configuration showed as follow... -
Page 10: Setup Wizard
P a g e | 10 3.2. Setup Wizard There are three operation modes in this router: Gateway, Wi-Fi Repeater and AP Mode. 3.2.1 Gateway Mode The device is supposed to be connected to internet via ADSL/Cable Modem; for this part, please check more information from Chapter 2. - Page 11 P a g e | 11 Please note: different LED colors indicate different status, kindly refer to following table. LED Light Power On Internet Work Internet not Mesh Mesh work Connecting Connected Gateway Blue Color, Green Color, Green color Blue Color, Mode Flash Flash...
- Page 12 P a g e | 12 Please press the reset button for one second of mesh wireless router in gateway mode, it will search and connect with the mesh wireless router in sub node mode. When connecting, the LED light will blink in green and blue color. When connected, LED light flash in blue color. Once the two mesh wireless routers are connected, then login using 192.168.188.253 as IP address, it will provide access into the mesh wireless router in Gateway mode.
-
Page 13: Wifi Settings
P a g e | 13 Wi-Fi Settings This includes basic wireless setting, advanced wireless settings, TX Power. 3.3.1 Basic The basic wireless settings, includes master and visitors network. User can configure the data based on their requirements as shown in the following picture: There is a Wi-Fi analyzer tool in this router, which can help user to choose the best channel, and avoid the Wi-Fi interference. - Page 14 P a g e | 14 3.3.2 This is a MAC filter. To control the user access, one can add/delete the user’s MAC address based on requirement: 3.3.3 Mesh Settings The user can enable or disable the mesh function. 3.3.4 Advanced Under Advanced, the user can set the right country code, client count, coverage threshold based on requirement:...
- Page 15 P a g e | 15 3.3.5 TX Power In this part, user can adjust the router’s TX power to control the wireless signal range. 3.3.6 Wi-Fi Timer Off In this part, user can enable/disable wireless signal in central time to save energy.
-
Page 16: Lan Settings
P a g e | 16 LAN Settings This includes LAN settings and Static DHCP settings. 3.4.1 LAN Setting: IP address: The controller’s IP address Subnet Mask: To set the subnet of LAN STP: Spanning Tree: Enable this feature to show the assigned IP list in DHCP list DHCP Server: Enable this feature to assign IP address automatically. -
Page 17: Wan
P a g e | 17 3.4.2 Static DHCP Static DHCP: 3.5. 3.5.1 WAN Setting: The WAN Setting includes DHCP, Static IP, PPPoE, as showed in the following picture:... - Page 18 P a g e | 18 3.5.2 Advanced Setting: The Advanced Setting mainly displays MAC Clone and Remote Management features. MAC Clone: When enabled, it can scan the connected devices’ MAC address, choose the MAC address needed to be cloned, then apply; Or the user can input the indicated MAC address to be cloned.
-
Page 19: Url Filter
P a g e | 19 3.6. URL Filter When enabled, the URL filter will prohibit the users to visit specified URLs at a certain specified time range. After selecting the URL filter, please setup the URL rule, add the time group, configure the limited time range and input URL to finish. -
Page 20: Time Reboot
P a g e | 20 Advanced Settings Advanced Settings includes Device settings, Common settings, Network settings and Security Settings. 3.8.1 Device: Device settings includes router configuration, Reboot, Modify Password, Upgrade, Time, Log and USB storage. 3.8.1.1 Configure This includes the broadband router backup, restore, and reset default. Backup By saving the WLAN controller configuration file in the computer, the user can restore to the same configuration by using the saved file. - Page 21 P a g e | 21 3.8.1.3 Modify Password Modify the login password of the broadband router 3.8.1.4 Firmware Upgrade This feature allows upgrading firmware of the device. Note: Upgrading software may cause local network outage. While upgrading the firmware, do not power off the device, doing so may damage the broadband router! 3.8.1.5 Device Time Displays the broadband router’s time.
- Page 22 P a g e | 22 3.8.1.6. Device Log Device Log helps to trace the router’s working status. Can be copied for further technical support. 3.8.1.7. USB Storage There is a USB port on the product as it supports the USB storage function 3.8.2 Common: This includes Setup Wizard, WiFi Analyzer, User Manager, Flow Control, Behaviour,...
- Page 23 P a g e | 23 3.8.2.1 Setup Wizard Please refer to Chapter 3.2. 3.8.2.3 Wi-Fi Analyzer Please refer to Chapter 3.3.1 3.8.2.4 User Manager Please refer to Chapter 3.1 3.8.2.5 IP/Time Group IP Group: The user can add the IP groups, if required.
- Page 24 P a g e | 24 Time Group: The user can add time group based on requirement. 3.8.2.6 Behavior This feature allows/rejects specific behaviors of end users based on rules.
- Page 25 P a g e | 25 3.8.2.7 Flow Control Flow Control means Ethernet speed limit, to limit end users Ethernet speed. 3.8.3 Network This includes Wi-Fi Settings, LAN Settings, WAN Settings and DDNS Settings. 3.8.3.1 Wi-Fi Settings: Please refer to Chapter 3.3 3.8.3.2 LAN Settings: Please refer to Chapter 3.4...
- Page 26 P a g e | 26 3.8.3.4 DDNS Settings: DDNS or Dynamic DNS, is a method of automatically updating a name server in the Domain Name System (DNS), often in real time, with the active DDNS configuration of its configured hostname, address or other information. 3.8.4 Security This includes port mapping, IP Filter, URL Filter, MAC Filter, MAC Filter, and DMZ.
- Page 27 P a g e | 27 3.8.4.2 IP Filter By enabling this function, the router will either allow or limit the specific IP address to access into the broadband router based on rules. 3.8.4.3 MAC Filter By enabling MAC filter, the router will allow or prohibit the MAC address to access this router based on rules.
- Page 28 P a g e | 28 3.8.4.4 Port Mapping Port Mapping, also called port forwarding , is an application of network address translation(NAT) that redirects a communication request from one address and port number combination to another while the packets are traversing a network gateway, such as a router or firewall.
- Page 29 P a g e | 29...
