ENGLISH

USER MANUAL

How to get the best out of your gobandit camera

Model name:gobandit LIVE GBZ0500

Model name:gobandit RACE GBZ0300

Table of Contents

Need help?

Do you have a question about the LIVE GBZ0500 and is the answer not in the manual?

Questions and answers

Summary of Contents for gobandit LIVE GBZ0500

Page 1 ENGLISH USER MANUAL How to get the best out of your gobandit camera Model name:gobandit LIVE GBZ0500 Model name:gobandit RACE GBZ0300...
Page 2: About The Camera
ABOUT THE CAMERA 1. Set Button 2. Status Display 3. Status LED 4. Mode Button Power Button when pressed for 3 seconds 5. GPS Antenna 6. Record Switch 7. Camera Rails 8. Rotatable Lens 1080p 9. USB Door 10. USB Port 11.
Page 3 3. Upper display 4. Screen: elapsed time/remaining time 5. Lower display 6. Wi-Fi On (only gobandit LIVE camera) 7. Video mode km/h 8. 1080p, HD or SD video resolution 9. Picture mode 10. SD card error / SD card full warning...
Page 4: Getting Started
GeTTING STARTeD: To activate the battery: · Open the front door of the camera by pulling the clamp at the bottom of the camera. · Pull the isolation stripe labeled with “REMOVE” - if stripe can not re- moved easily, take out the battery for this purpose: open battery latch and take out battery ·...
Page 5 Note: Camera accepts up to 32GB microSD. Use High Speed cards – at least class 6 SDHC cards. For a list of compatible microSD cards visit www.gobandit.com/sd Always turn camera off before removing microSD card and/or battery. If you have problems with your microSD card, format the card using the Settings menu: SET >...
Page 6: Mounting Your Camera
/ fog in the lens, you can replace the insert (desiccant strip) in the anti fog inserts department. For further detail see Anti Fog Inserts user guide supplement. Please visit www.gobandit.com/shop for purchasing anti fog inserts. MOUnTIng YOUR CAMERA Mount your camera using the Flat surface mount, Goggle mount or the Universal mount: 1.
Page 7: Safety Leash
BEFORE USING THE CAMERA WITH ANY MOUNT IN YOUR ACTIVITIES, DETERMINE IF THE HOLDING POWER OF THE MOUNT IS APPROPRIATE AND SAFE. THE CAMERA COULD CAUSE INJURY OR HARM IN THE EVENT THAT IT COMES LOOSE FROM THE MOUNT. GOBANDIT DOES NOT WARRANTEE LOST OR DAMAGED CAMERAS. SAFETY LEASH You can additionally use the Safety leash to secure the camera, in case it comes loose from the mount.
Page 8 IN THE EVENT THAT IT COMES LOOSE FORM THE MOUNT AND REMAINS TETHERED BY THE LEASH. BY ATTACHING THE LEASH YOU AGREE TO WAVE ANY CLAIMS AGAINST GOBANDIT GMBH AND ANY OF ITS AFFILIATES, AGENTS, EMPLOYEES, OFFICERS OR DIRECTORS ARISING FROM THE USE OF THE LEASH.
Page 9 Note: The GPS performance is better when GPS antenna (underneath Record switch) looks towards the sky. POwER On · Press and hold the button for a minimum of 3 seconds. · Display shows GO and counting up while starting · Camera beeps once and the rear LED blinks in green when ready. ·...
Page 10: Camera Firmware
Visit www.gobandit.com/start to download gobandit STUDIO software for Windows PC or Mac. Connect the camera using the USB cable. gobandit STUDIO will recognize when a new firmware for your camera is available and will update your camera’s firmware if...
Page 11: Start Recording
RECORDIng Start Recording: · Slide the “Record” switch forward. · The rear LED turns blue or red, depending on camera model (GPS fix solid, otherwise flashing) · Camera beeps as soon as recording starts: once if GPS fix is acquired, or twice if not ·...
Page 12: Stop Recording
GPS track– even while not recording a video. You can retrieve the GPS track from the Camera to your Computer using gobandit STUDIO – as well as switch off this feature if you don’t require this.
Page 13: Battery Status
Note: Alternatively you can use the optional gobandit Car Charger or the gobandit Wall Charger – or charge your battery outside the camera using the optional gobandit Battery Charger. Please visit www.gobandit.com/shop for purchasing chargers and extra batteries. Tip: camera battery charges faster when camera is switched off while...
Page 14 3 seconds. If you have linked gobandit certified ANT+® accessories, like a Heart Rate belt to a gobandit LIVE camera, further display modes may be displayed, e.g.
Page 15: Video Format Selection
Video Format selection: Your gobandit camera can shoot videos at various resolutions and at vari- ous frame rates. The most used frame rate is 30 frames per second (fps), however you can also choose e.g. 60 or 120 fps for a slow motion playback.
Page 16 <TODO: correct table and add further video resolutions> Picture timer selection: In addition to shooting videos, your gobandit camera can shoot still pictures. While the Record switch is slid forward, the camera takes a sequence of pictures until you switch back the Record switch. The Picture timer determines, how many pictures are taken, i.e.
Page 17 · Press the button shortly · Push the button quickly to toggle through the available picture timers: 1, 2, 5, 10, 30 or 60 SEC – for a picture every 1, 2, 5, 10, 30 or 60 seconds - or 10 /SEC for 10 pictures per second – default is a picture timer of 2 seconds ·...
Page 18: Field Of View
Tip: User Settings can be configured through gobandit STUDIO or gobandit MOBILE. To configure using gobandit STUDIO connect the camera to your PC/Mac using the USB cable. To configure using gobandit MOBILE connect the gobandit LIVE camera to your iPhone / Smartphone using Wi-Fi®.
Page 19 · Press the button shortly · Push the button quickly and toggle through the available field of view’s. · Press the button shortly to select desired field of view · Confirm your choice by pushing the button shortly – display shows: Note: In Full HD (1080p) resolution, only 170°...
Page 20: Phone Connection
Wi-Fi hotspot to facebook, YouTube and the gobandit COMMUNITY. Further you can use your mobile phone as a remote control and configure your camera settings using gobandit MOBILE.
Page 21 Wi-Fi will be switched off on your camera. Default password is 1234 - change the password using the settings function of gobandit MOBILE or gobandit STUDIO if you want to prevent others accessing your camera. Once you have changed your password...
Page 22 Wrist Remote Control or Heart Rate belt. For a list of supported devices and a user guide supplement, please visit www.gobandit.com/antplus gobandit STUDIO - TRANSFeRRING VIDeOS TO YOUR COMPUTER / SHARE VIDEOS gobandit STUDIO is a free Windows PC / Mac software application 22 22...
Page 23 … · Trim / Edit the video, i.e. modify starting and ending position of the video · Share videos to the gobandit COMMUNITY, facebook, YouTube, twitter … or email to your friends · Change settings of your camera Create a free account on the gobandit COMMUNITY: go to www.gobandit.com/community - and click on “Sign up”.
Page 24: Status Led
STATUS LED COLOR STATUS SOLID BLInKIng BLInKIng FAST Green Camera on GPS fix No GPS signal Camera off Battery charging Blue/ Video/Picture Recording GPS fix No GPS signal SD card error Camera off After battery charging - battery full CHECK TABLE BUZZER SOUnD STATUS...
Page 25: Need Help
Camera. Read all safety information and operating instructions of the “Product Information and Safety Guide” before using the gobandit Camera to avoid injury. For detailed operating instructions and thelatest Important Product Infor- mation Guide, go to: www.gobandit.com/support...
Page 26 © 2012 gobandit GmbH. All rights reserved. Technical specifications, features, designs and colors are subject to change without notice. gobandit is a trademark of gobandit GmbH. All other trademarks and registrations are the property of their respective owners. Internet connection required. Patent Pending.
Page 28 CE Mark: ...
Page 29 FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
