29.6V Flexi-Stick Vacuum
K852
v001: 14/09/22
Please read and retain these instructions for future reference
The Enterprise
Department
Dimensions
(H) 129 x (W) 23 x (D) 22cm
Folded Dimensions: 75 X 26 CM
Length of mains lead: 135cm, can be fed into charging mount to
make shorter
Material: ABS, Iron, Aluminium
Weight: 2.53kg
•
FLEXI-STICK VACUUM HELPS YOU TO REACH ALL THE HARD TO
REACH AREAS
•
REDUCES BENDING
•
2 IN 1 CYCLONIC STICK AND HANDHELD VAC
•
CORDLESS AND RECHARGEABLE
•
TWO SPEED CONTROL
•
0.6L DUST TANK
•
SUPERIOR MESH COVER FILTER HELPS REMOVE THE
SMALLEST PIECES OF DUST
•
ERGONOMIC COMFORT HANDLES
•
WALL MOUNTED STORAGE AND CHARGING BASE.129 X 23 X
22 CM
•
INCLUDES CHARGING BASE, POWER ROLLER BRUSH, 3 IN-1
NOZZLE, FOLDABLE METAL TUBE,
•
LED LIGHTS ON THE MAIN HEAD (LED NOT REPLACEABLE)
Protection class .................................................................................... III
Input: ....................................................................................... DC 29.6V
Protection class ..................................................................................... II
Input: .............................................. AC 100–240V, 50/60Hz, 0.5A MAX
Output ........................................................................... DC 35V, 500mA
Rechargeable battery ........................................ 29.6V, 2200 mAh Li-Ion
Operating time .......... 30 minutes(high speed), 55 minutes (Eco Mode)
Charging time ............................................................. approx. 4.5 hours
UK Head Office, 11 Bridge Street, Bishop's Stortford, CM23 2JU
Tel: 0330 331 0300
Fax: 01279 756595
www.coopersofstortford.co.uk
EU address: D.S.B. LD, 160 Bd. de Fourmies, 59100 Roubaix, France
Tel: (+44) 1279 701269
Technical Data
Power Adapter
Advertisement
Related Manuals for Bergstrom K852
Summary of Contents for Bergstrom K852
- Page 1 29.6V Flexi-Stick Vacuum K852 v001: 14/09/22 Please read and retain these instructions for future reference Dimensions (H) 129 x (W) 23 x (D) 22cm Folded Dimensions: 75 X 26 CM Length of mains lead: 135cm, can be fed into charging mount to...
- Page 2 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 WARNINGS AND SAFETY INSTRUCTIONS: WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED: • READ ALL INSTRUCTIONS BEFORE USE. •...
- Page 3 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Parts 1. Indicator lights 2. On/Off button 3. Rechargeable battery pack 4. Dust container 5. Max button 6. Combined tube 7. Folded sucking pipe 8.
- Page 4 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Rechargeable Lithium-Ion Batteries (Li-Ion) The appliance is equipped with rechargeable Li-ion batteries. This results in numerous advantages compared to other batteries and accumulators: •...
- Page 5 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Unpacking the Appliance 1. Remove the appliance from its packaging. 2. Check the delivery scope for completeness. 1. Check the appliance for any transport damage, in order to prevent hazards.
- Page 6 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 CAUTION: You cannot replace the LEDs. • Stick the lower end of the suction pipe onto the connector on the floor nozzle. Note the contact pins on the floor nozzle.
- Page 7 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Please take a look at the following Figure: Charging the Rechargeable Battery CAUTION: Do not charge the rechargeable battery unsupervised. 1. Turn off the appliance.
-
Page 8: Maintenance
Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 You can use the appliance as a floor vacuum cleaner or as a handheld and upright vacuum cleaner (basic unit). 1. Disconnect the appliance from the power adapter. - Page 9 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Proceed as follows to clean the filter unit Emptying the Dust Collector 1. Disconnect the appliance from the power adapter. 1. If necessary, remove the suction tube or the nozzle attachment from the appliance.
- Page 10 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Outlet Filter The appliance is also equipped with an exhaust filter. It is located at the top of the motor housing. CAUTION: You cannot remove this filter.
- Page 11 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Counterclockwise. Flip the cover open. 3. Pull out the brush roller. 4. Remove threads and hair wound to the brush. please use the small hook(with the blade) WARNING: it is dangerous for children to touch the small hook, because it has a tiny blade for cutting the hair wound to the brush.
-
Page 12: Troubleshooting
Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 Troubleshooting Problem Possible cause Remedy The appliance does not The power adapter is Disconnect the appliance from the power function. connected. adapter. - Page 13 Instructions for Use 29.6V Flexi-Stick Vacuum K852 Please read and retain these instructions for future reference v001: 14/09/22 This appliance is supplied with a mains adaptor/charger with BS1363 plug pins. DO NOT use If the socket outlets in your home or office are not suitable for this product’s mains adaptor/ charger plug pins.
