- Page 1 180 Gallon Deck Box Owner’s Manual MODEL: DB23004 EASTOAK.COM OWNER’S MANUAL...
- Page 2 Questions? Comments? Reach out to us for expert support! support@eastoak.com eastoak.com 1-833-EAST-OAK ( USA ) ( 1-833-327-8625 ) Follow eastoakliving on Claim your 3-year warranty Please scan the QR code to view the installation video at eastoak.com/warranty 180 GALLON DECK BOX EASTOAK.COM OWNER’S MANUAL...
-
Page 3: Important Caution
IMPORTANT CAUTION PARTS LIST Once installed, the product cannot be detached. Please strictly follow each step in the installation manual. • Please check all parts and components to ensure that there are no damages or missing items before starting the construction of the product. If you have any problems or discover any missing parts, please contact customer service support@eastoak.com •... - Page 4 ASSEMBLY INSTRUCTIONS Align 2 Rubber Plugs R with the hole and install it on Bottom Panel C. The letter marks on the A/A+Logo /B/C/J/F (X2) (X2) panels should face inward when installing. Rubber Plug Hydraulic Rod Plastic Hinge Lock Bracket-1 (X2) (X2) (X2)
- Page 5 Install 2 Side Panels A(without logo): Insert 2 Put the assembled Side Panel A on the flat ground, and then buckle Reinforced Metal Rods D to the end and then the Bottom Panel C in. buckle 2 panels together. Please note that the directions of the arrows are (X2) consistent.
- Page 6 Please note that the directions of the arrows on Panel A Attach 6 Partition Panel Buckles Y to 2 Side Panels A. and B are consistent. (X6) (X2) (X1) CLICK +logo +logo Install 2 Plastic Strips T and Lock Bracket-2 I to Panel A (with logo) with 5 Screws.
- Page 7 Please install the Lid Conecters Assemble Reinforced Bridge P to Lid Panel. G1,G2 and 2 Reinforced Metal (X1) Rods D to Lid Panel F. (X1) (X1) (X1) Please insert the grooved part of Reinforced Bridge P into the Panel first. (X2) CLICK Please install Lock Bracket-1 G to Lid...
- Page 8 Tighten 2 Plastic Hinges E with 8 Screws. Assemble 2 Hydraulic Rods H1 to Lid Panel with 4 Screws. M4*16 M4*16 (X8) (X2) (X4) +logo Gently pull the side panel and align Partition Panel A1 with the card slot. Assemble 2 Hydraulic Rods H1 to Side Panel B with 6 Screws.
- Page 9 Installation completed. 180 GALLON DECK BOX EASTOAK.COM OWNER’S MANUAL...
-
Page 10: What's In The Box
Padlock WARRANTY POLICY GUARANTEED 3-YEAR WARRANTY Thank you for choosing East Oak. This product is covered by our company warranty for up to 3 years from its original purchase date. CLAIM WARRANTY If you’d like to claim your product’s warranty, register your new product on our website at www.eastoak.com/warranty. - Page 11 support@eastoak.com eastoak.com 1-833-EAST-OAK (USA) 180 GALLON DECK BOX...
