SonicAire ZCK Owner's Manual

ZONE CONTROL KIT (ZCK)
OWNER'S MANUAL
The Zone Control Kit (ZCK) allows a user
to limit the active cleaning area of any fan
by turning the main fan motor on and off
using magnetic targets and a proximity
sensor during a normal fan rotational
cycle. The active cleaning zone created
by magnetic targets can range from 30°
to 270° (expandable to 330°).
The ZCK is normally installed in the
factory, but is also available as a field
installed kit coupled with the installation
of a 3 phase gear motor replacement
where a Reverse Control Kit (RCK) had
formerly been used.
The end user will need to mount the
Magnetic Targets in their proper positions
for desired cleaning angle segments,
which can be done easily by using this
manual as a reference.
Installation and electrical wiring must be completed by qualified persons in accordance with all applicable codes
and standards.
Ensure installation securement does not penetrate walls or ceilings where electrical components or wiring could
be potentially damaged.
Use this unit only in the manner intended by SonicAire.
1.336.712.2437
The Zone Control Kit allows you to limit the active fan cleaning
area by utilizing magnet targets and a proximity switch.
partsandservice@sonicaire.com
If you have purchased an ZCK for an
existing unit and have questions about
installing this kit please contact SonicAire.
NOTE:
incompatible with the use of a Variable
Frequency Drive, and should therefore
NOT be used in conjunction with a
SonicAire Command15 control panel.
NOTE: If you are using the ZCK in a
compact location, note that the fan
shroud will rotate a full 360 degrees.
Care should be taken to ensure that
the rotational path of the SonicAire fan
does not interfere with any obstruction
prior to turning the fan on. Your PRO
Series shroud may be longer than that
of your prior legacy fan. Check fan
manual for clearance details.
