- Page 1 Oil Debris Sensor Quickstart Guide Sensor with display Sensor without display 4212-PK-145 4212-PK-148 4212-PK-146 4212-PK-149 4212-PK-147 4212-PK-150 4212-PK-151 gillsc.com 4212-30-362 Iss 6 © 2023 Gill Sensors & Controls Limited...
- Page 2 Thank you for purchasing this sensor. The WearDetect Oil Debris Sensor is a high precision device designed to give accurate results and long service. The following guidance will allow initial set-up after which Gill recommend downloading the full user manual and optimising operation by using the WearDetect software www.gillsc.com/support.
- Page 3 Note: For voltage devices, the analogue output is limited by the supply voltage provided to power the sensor and a minimum 0.7V power supply headroom above the desired analogue output is recommended for stable sensor output. gillsc.com © 2023 Gill Sensors & Controls Limited...
- Page 4 Oil Debris Sensor Fitting the sensor head • Fitting the sensor to the equipment requires a thread adaptor available separately from Gill sized to fit the thread size of the equipment and is mandatory for all installations. • Secure the thread adaptor into the equipment then fit the sensor head using the grub screws provided.
