- Page 1 LightSpeed Technologies™ MV-4K-4X1 4K 4x1 Seamless Multiview Processor User Manual Version: V1.0.0...
-
Page 2: Table Of Contents
Table of Contents Introduction ...................... 2 Overview ....................2 Features ....................2 Package Contents ..................3 Specifications ................... 3 Panel Description ..................5 Front Panel ..................5 Rear Panel ..................6 Installation and Wiring ..................7 Installation ....................7 Wiring ....................... 7 Layout Modes .................... -
Page 3: Introduction
Introduction Overview This product is a multi-screen video processor which supports 4K@60Hz input and output. It features up to 4 channels of 4K/UHD video signals to be simultaneously displayed on one 4K/UHD display. It also supports seamless switching between 4 input signals, and supports multiple screen layouts including Original, Dual-view, H mode, Master mode, PIP mode and Quad mode to meet different image display needs. -
Page 4: Package Contents
Package Contents 1 x Video Processor 1 x DC 12V Power Adapter with US Pins 1 x Phoenix Male Connector (3.5mm, 3 Pins) 1 x IR Remote 1 x IR Receiver Cable 4 x Mounting Brackets (with Screws) ... - Page 5 Technical Control Front Panel Buttons, IR Remote, RS232 General Operating Temperature 0°C to 45°C (32°F to 113°F) Storage Temperature -20°C to 70°C (-4°F to 158°F) Humidity 10% to 90%, non-condensing Human-body Model: ESD Protection ±8kV (Air-gap discharge)/ ±4kV (Contact discharge) Power Supply DC 12V 2A Power Consumption (Max)
-
Page 6: Panel Description
Panel Description Front Panel Name Description On: The device is powered on. POWER LED Off: The device is powered off. 1~4 buttons: Press the button to enter Original mode and switch to the corresponding HDMI IN INPUT SELECT source. -
Page 7: Rear Panel
Rear Panel Name Description DC 12V Connect to the DC 12V power adapter provided. HDMI IN 1~4 Connect to HDMI sources. HDMI OUT Connect to an HDMI display. Connect to an audio device for de-embedding audio AUDIO OUT output from HDMI OUT. RS232 Connect to a RS232 control device for API control. -
Page 8: Installation And Wiring
Installation and Wiring Installation Note: Before installation, please ensure the device is disconnected from the power source. Steps to install the device on a suitable location: Attach the installation bracket to the enclosure using the screws provided in the package separately. The bracket is attached to the enclosure as shown. - Page 9 Connect HDMI displays (e.g., TV, LED/LCD display, etc.) to HDMI OUT port of the device. Connect for additional control options: Audio de-embedding output: Connect an audio receiver such as a speaker to AUDIO OUT port of the device. RS232 Control: Connect to a control PC or control system to RS232 port of the device.
-
Page 10: Layout Modes
Layout Modes Layout Mode Introduction The device supports 6 layout modes on the connected display, including Original mode, Dual-view mode, PIP mode, H mode, Master mode, and Quad mode. The processor supports seamless switching of input sources in the same layout mode. -
Page 11: Input Video And Audio Source Switching
Figure 1: Original Mode Figure 2: Dual-View Mode Figure 3: PIP Mode Figure 4: H Mode Figure 5: Master Mode Figure 6: QUAD Mode Input Video and Audio Source Switching After one layout mode is selected, users can circularly switch video and audio sources in the layout mode through front panel or IR remote, or respectively select input source through API commands (please refer to the separate document “API Command Set_MV-4K-4X1”... -
Page 12: Screen Stretch Mode Switching
1 to stretch full screen, send command “SET VIDIN_STRETCH 1 0 <CR><LF>”, and input 1’ s image will be shown as figure 2. More detail API information, please refer to the separate document “API Command Set_ MV-4K-4X1”. Figure 1 Figure 1... -
Page 13: Front Panel Control
Users can control the device through front panel buttons, IR remote, and RS232 (API Commands). Front Panel Control Users can switch among the four inputs or input groups and six modes through front panel buttons. Operations are as follows: Press “LAYOUT” button to select one layout mode to display. Press continuously to switch layout modes as the following sequence: Original →... - Page 14 Button Function The button can mute/unmute the HDMI output and send CEC command power off/on connected display simultaneously. Note: When mute the display, it will show black screen. Press the button to switch output resolution between 4K@60Hz and 1080P@60Hz. Press to switch to original mode, and select HDMI IN 1/2/3/4 as signal source.
-
Page 15: Rs232 Control
RS232 Control Advanced users may need to control the device through RS232 serial communication. Connect a control PC or control system to the RS232 port of the processor. API command for RS232 control is available in the separate document “API Command Set_MV-4K-4X1”. A professional RS232 serial interface software (e.g., Serial Assist) may be needed as well. - Page 16 LightSpeed Technologies 24551 Production Circle, Suite 2 Bonita Springs, FL 34135 www.lightspeed-tech.com...
